Front Suspension: Specifications Jeep Liberty II

Suspension Front 14 illustrations ~134 words

SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Front Shock Absorber Clevis Bracket Upper Nut10880
Front Shock Absorber Clevis Bracket Lower Nut150110
Front Shock Absorber Top (4) Mounting Nuts10880
Front Shock to Spring and Insulator Nut4130
Upper Suspension Arm Front Nut12290
Upper Suspension Arm Rear Nut12290
Lower Suspension Arm Front Nut170125
Lower Suspension Arm Rear Nut170125
Stabilizer Bar Clamp Nut149110
Stabilizer Bar Link Upper Nut11585
Stabilizer Bar Link Lower bolt10275
Hub/Bearing Bolt13096
Hub/Bearing Halfshaft Nut136100
Upper Ball Joint Nut Tighten to 41 N.m (30 ft lbs), make sure nut is seated to the knuckle. Rotate nut to an additional 90°41 plus Rotate nut to an additional 90°30 plus Rotate nut to an additional 90°
Lower Ball Joint Nut Tighten to 54 N.m (40 ft lbs), make sure nut is seated against knuckle. Rotate nut an additional 90°54 plus Rotate nut an additional 90°40 plus Rotate nut an additional 90°
Outer Tie Rod End Nut to Knuckle41 plus Rotate nut an additional 90°30 plus Rotate nut an additional 90°
Wheel Speed Sensor13.510

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: SPECIAL TOOLS
Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Raise and support the vehicle.
  2. Remove the wheel and tire assembly.
  3. Remove the stabilizer bar link (2). See «Front Suspension/Front/LINK, Stabilizer Bar - Removal»(ref-350031-S35928596702009121400000) .
  4. Remove the shock absorber lower clevis bolt (4). See «Front Suspension/Front/BRACKET, Clevis - Removal»(ref-350031-S05163340522009121400000) .
  5. Remove the lower ball joint nut (2). Separate ball joint from the steering knuckle (1) with Remover 8677 (3). NOTE: Marking the lower control arm pivot bolts front and rear will aid in the assembly procedure.
  6. Remove the control arm pivot bolts (3) and suspension arm from frame rail brackets (1).
  7. Remove the lower control arm (2) from the vehicle.
