INTERNATIONAL CONTROL AND DISPLAY SYMBOLS

Chrysler LLC uses international symbols to identify various systems on the vehicle.

The graphic symbols illustrated are used to identify various instrument controls, vehicle controls and service information references. The symbols correspond to the controls and displays that are located on the instrument panel and throughout the vehicle.

Scheme 3

Scheme 3: INTERNATIONAL CONTROL AND DISPLAY SYMBOLS
SYMBOLDESCRIPTIONSYMBOLDESCRIPTION
1115-Volt Power Inverter11Side Airbag
2USB Connector12Seat Belt
3Lighter13Airbag
4Fuel Fill Side14Supplemental Restraint System
5Spare Tire Winch15Power Steering Fluid
6Fuse16See Owner's Manual
7Key Activate (Power Outlet)17See Appropriate Service Information Section
8Warning18Emergency Release Handle
9Child Seat Tether Anchor19Jack/Jack Tools Location
10Lower Anchors and Tether for Children (latch)

INTERNATIONAL INFORMATION SYMBOL IDENTIFICATION

Scheme 4

Scheme 4
SYMBOLDESCRIPTIONSYMBOLDESCRIPTION
1Electronic Speed Control23Transmission Oil Temperature Light
2Hill Descent Control24Diesel Exhaust Brake
3Traction Control25High Beam
4Electronic Stability Program/Brake System Assist System26Front Fog Light
5Security Indicator27Rear Fog Light
6Turn Signals28Cargo Lamp
7Water In Fuel29Exterior Bulb Failure
8Low Fuel30Door Ajar
9Side Airbag31Liftgate Open
10Seat Belt Reminder32Brake System Warning Parking Brake
11Airbag Warning Light33All Wheel Drive
12Passenger Airbag Off34Four Wheel Drive
13Failure Of Anti-Lock Braking System35Four Wheel Drive Low
14HEV Brake Regenerative Light36Tow/Haul
15Electronic Throttle Control37Service Four Wheel Drive
16HEV Service Light38Service Four Wheel Drive
17Engine Oil39Cruise Indicator
18Battery Charging40Brake System Warning Parking Brake
19Glow Plug/Intake Air Heated41Tire Pressure Monitor
20Power Steering Fluid42Sway Bar Disconnect Indicator
21Engine Coolant Temperature43Front Axle Lock
22Malfunction Indicator Light44Rear Axle Lock

INTERNATIONAL INDICATOR SYMBOL IDENTIFICATION

Scheme 5

Scheme 5
SYMBOLDESCRIPTIONSYMBOLDESCRIPTIONSYMBOLDESCRIPTION
1Rear Window Wiper26Passenger Air Bag Off51Door Ajar
2Rear Window Intermittent Wiper27Electronic Speed Control52Liftgate Release
3Rear Window Washer28Cruise Indicator53Sliding Door
4Rear Window Defrost29Hill Descent Control54Sliding Door
5Heated Mirror30Park Assist Off55Convertible Top Down
6Turn Signals31Electronic Stability Program/Brake System Assist System56Convertible Top Up
7Adjustable Pedals32Park Brake Release57Door Lock
8Horn33Adjustable Headlights58Window Lift
9Windshield Wiper Intermittent34Low Beam59Convertible 4 Window Down
10Windshield Washer35Front Fog Light60Window Lock
11Windshield Washer Fluid Level36Rear Fog Light61Power Rear Window
12Windshield Electrically Heated37Cargo Lamp62Voice Recognition Button
13Windshield Defrost38Hazard Lights63Uconnect™ Button
14Windshield Wiper And Washer39115-Volt Power Inverter64SwayBar Disconnect
15Ventilating Fan40Key Activate (Power Outlet)65All Wheel Drive
16Air Conditioning41Exterior Bulb Failure66Four Wheel Drive
17Upper Air Outlet42Master Lighting Switch67Two Wheel Drive
18Upper And Lower Air Outlet43Dome Light68Four Wheel Drive Low
19Lower Air Outlet44Park Lights69Four Wheel Drive Lock
20Defrost And Lower Air Outlet45Instrument Panel Illumination70Four Wheel Drive Auto
21Heated Seat Low46Electronic Stability Program Off71Front Axle Lock
22Heated Seat High47Diesel Exhaust Brake72Rear Axle Lock
23Ventilated Seat48Overdrive Off73EVIC Menu
24Recirculation49Hood Release74Navigation Button
25Heated Steering Wheel50Trunk/Deck Release75Step
76Reset77Axle Lock Button78Traction Control Off

INTERNATIONAL CONTROL SYMBOL IDENTIFICATION

Scheme 6

Scheme 6: ENGINE COMPARTMENT

The graphic symbols illustrated are used to identify engine compartment lubricant and fluid inspection and fill locations. The symbols correspond to the caps located within the engine compartment.

Scheme 7

Scheme 7: DESCRIPTION
1 - VEHICLE EMISSION CONTROL INFORMATION (VECI) LABEL
2 - COVER - COWL GRILLE

Note. The Vehicle Emission Control Information (VECI) label(s) must be in place for the life of the vehicle. When replacing the component in which the VECI label is adhered, a new VECI label must also be adhered to the new component.

All models have a VECI label. Chrysler permanently attaches the label in the engine compartment. The label cannot be removed without defacing label information and destroying label.

The VECI label contains the following

  1. Engine family and displacement
  2. Evaporative family
  3. Certification application
  4. Engine timing specifications (if adjustable)
  5. Idle speeds (if adjustable)

Scheme 8

Scheme 8: DESCRIPTION

The metric system is based on quantities of one, ten, one hundred, one thousand and one million.

The following chart will assist in converting metric units to equivalent English and SAE units, or vise versa.

MULTIPLYBYTO GETMULTIPLYBYTO GET
In-lbsX 0.11298= Newton Meters (N.m)N.mX 8.851= in-lbs
Ft-lbsX 1.3558= Newton Meters (N.m)N.mX 0.7376= ft-lbs
Inches Hg (60° F)X 3.377= Kilopascals (kPa)KPaX 0.2961= Inches Hg
PsiX 6.895= Kilopascals (kPa)KPaX 0.145= psi
InchesX 25.4= Millimeters (mm)MmX 0.03937= Inches
FeetX 0.3048= Meters (M)MX 3.281= Feet
YardsX 0.9144= MetersMX 1.0936= Yards
MphX 1.6093= Kilometers/Hr. (Km/h)Km/hX 0.6214= mph
Feet/SecX 0.3048= Meters/Sec (M/S)M/SX 3.281= Feet/Sec
MphX 0.4470= Meters/Sec (M/S)M/SX 2.237= mph
Kilometers/Hr. (Km/h)X 0.27778= Meters/Sec (M/S)M/SX 3.600Kilometers/Hr. (Km/h)

CONVERSION FORMULAS AND EQUIVALENT VALUES

COMMON METRIC EQUIVALENTS
1 inch = 25 Millimeters1 Cubic Inch = 16 Cubic Centimeters
1 Foot = 0.3 Meter1 Cubic Foot = 0.03 Cubic Meter
1 Yard = 0.9 Meter1 Cubic Yard = 0.8 Cubic Meter
1 Mile = 1.6 Kilometers

Refer to the Metric Conversion Chart to convert torque values listed in metric Newton- meters (N.m). Also, use the chart to convert between millimeters (mm) and inches (in.).

THREADED HOLE REPAIR

Most stripped threaded holes can be repaired using a Helicoil®. Follow the vehicle or Helicoil® recommendations for application and repair procedures.

Scheme 9

Scheme 9: DESCRIPTION

Individual Torque Charts appear within many of the Groups. Refer to the Standard Torque Specifications Chart for torque references not listed in the individual torque charts.

Scheme 10

Scheme 10: DESCRIPTION

A vehicle certification label is attached to every Chrysler LLC vehicle. The label certifies that the vehicle conforms to all applicable Federal Motor Vehicle Standards. The label also lists

  1. Month and year of vehicle manufacture.
  2. Gross Vehicle Weight Rating (GVWR). The gross front and rear axle weight ratings (GAWR's) are based on a minimum rim size and maximum cold tire inflation pressure.
  3. Vehicle Identification Number (VIN).
  4. Type of vehicle.
  5. Type of rear wheels.
  6. Bar code.
  7. Month, Day and Hour (MDH) of final assembly.
  8. Paint and Trim codes.
  9. Country of origin.

The label is located on the driver-side door shut-face.
