OPERATION
The automatic transmission fluid is selected based upon several qualities. The fluid must provide a high level of protection for the internal components by providing a lubricating film between adjacent metal components. The fluid must also be thermally stable so that it can maintain a consistent viscosity through a large temperature range. If the viscosity stays constant through the temperature range of operation, transmission operation and shift feel will remain consistent. Transmission fluid must also be a good conductor of heat. The fluid must absorb heat from the internal transmission components and transfer that heat to the transmission case.
DESCRIPTION
The fluid check/fill point locations are located in each applicable service manual section.
Scheme 1
The Totally Integrated Power Module (TIPM) is located in the engine compartment near the battery. This center contains cartridge fuses, mini fuses and relays. A label that identifies each component is printed on the inside of the cover.
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|---|---|---|
| J1 | |||
| J2 | 30 Amp Pink | Transfer Case Module - if equipped | |
| J3 | 40 Amp Green | Rear Door Modules | |
| J4 | 25 Amp White | Driver Door Node | |
| J5 | 25 Amp White | Passenger Door Node | |
| J6 | 40 Amp Green | Anti-Lock Brake System (ABS) Pump/ESP - if equipped | |
| J7 | 30 Amp Pink | Anti-Lock Brake System (ABS) Valve/ESP - if equipped | |
| J8 | 40 Amp Green | Power Seats - if equipped | |
| J9 | 40 Amp Green | PZEV/Flex Fuel - if equipped | |
| J10 | |||
| J11 | |||
| J13 | 60 Amp Yellow | Ignition Off Draw (IOD) | |
| J14 | 40 Amp Green | EBL (Rear Window Defogger) - if equipped | |
| J15 | |||
| J17 | 40 Amp Green | Starter Solenoid | |
| J18 | 20 Amp Blue | Powertrain Control Module (PCM) Transmission Relay | |
| J19 | 60 Amp Yellow | Radiator Fan | |
| J20 | 30 Amp Pink | Front Wiper | |
| J21 | 20 Amp Blue | Front Washer/Rear Washer - if equipped | |
| J22 | 25 Amp White | Sunroof Module - if equipped | |
| M1 | 15 Amp Blue | Stop Light Switch Feed - Center High Mounted Stop Light (CHMSL) | |
| M2 | 20 Amp Yellow | Trailer Lighting - if equipped | |
| M3 | |||
| M4 | 10 Amp Red | Trailer Tow - if equipped | |
| M5 | 25 Amp Natural | Power Inverter - if equipped | |
| M6 | 20 Amp Yellow | Power Outlet #1 (cigar lighter)/Rain Sensor - if equipped/Trailer Tow - if equipped | |
| M7 | 20 Amp Yellow | Power Outlet #2 (BATT/ACC SELECT) | |
| M8 | 20 Amp Yellow | Front Heated Seats - if equipped | |
| M9 | |||
| M10 | 15 Amp Blue | Hands-Free Module (HFM) - if equipped/Universal Garage Door Opener (UGDO) - if equipped/Vanity Light | |
| M11 | 10 Amp Red | Automatic Temperature Control (ATC) - if equipped | |
| M12 | 30 Amp Green | Radio/Amplifier - if equipped | |
| M13 | 20 Amp Yellow | Cabin Compartment Node (CCN)/Wireless Control Module (WCM)/Multifunction Control Switch | |
| M14 | |||
| M15 | 20 Amp Yellow | Multifunction Control Switch/Cabin Compartment Node (CCN)/Steering Column Control Module (SCM)/Rear View Mirror/Tire Pressure Monitor (TPM) - if equipped/IR Sensor - if equipped/Transfer Case Module - if equipped | |
| M16 | 10 Amp Red | Occupant Restraint Controller (ORC) | |
| M17 | 15 Amp Blue | Exterior Lighting - Left Front Park and Side Marker, Left Tail and Running, License Lights | |
| M18 | 15 Amp Blue | Exterior Lighting - Right Front Park and Side Marker, Right Tail and Running Lights | |
| M19 | 25 Amp Natural | Auto Shut Down (ASD) #1 and #2 | |
| M20 | 15 Amp Blue | Interior Lighting/Steering Wheel Switches - if equipped/Switch Bank/Electronic Vehicle Information Center (EVIC) - if equipped | |
| M21 | 20 Amp Yellow | Auto Shut Down (ASD) #3 | |
| M22 | 10 Amp Red | Right Horn (Hi/Low) | |
| M23 | 10 Amp Red | Left Horn (Hi/Low) | |
| M25 | 20 Amp Yellow | Fuel Pump | |
| M26 | 10 Amp Red | Power Mirror Switch/ Driver Window Switch | |
| M27 | 10 Amp Red | Ignition Switch/Wireless Control Module (WCM)/Steering Column Lock - if equipped | |
| M28 | 10 Amp Red | Powertrain Control Module (PCM) | |
| M29 | 10 Amp Red | Occupant Classification Module (OCM) | |
| M30 | 15 Amp Blue | Rear Wiper Module - if equipped/Diagnostic Link | |
| M31 | 20 Amp Yellow | Back-Up Lights | |
| M32 | 10 Amp Red | Occupant Restraint Controller (ORC) | |
| M33 | 10 Amp Red | Powertrain Control Module (PCM) | |
| M34 | 10 Amp Red | Park Assist Module - if equipped/Heating, Ventilation, and Air Conditioning (HVAC) Module - if equipped/Compass Module - if equipped | |
| M35 | 10 Amp Red | Heated Mirrors - if equipped | |
| M36 | |||
| M37 | 10 Amp Red | Anti-Lock Brake System (ABS)/Electronic Stability Program (ESP) Module/Stop Light Switch | |
| M38 | 25 Amp Natural | Door and Liftgate Lock/Unlock Motors |
| Cavity | Description |
|---|---|
| 1 CB1 | Circuit Breaker 1 |
| 2 | Run Accessory |
| 3 | Run Start |
| 4 | Run |
| 5 | Rear Window Defogger (EBL) |
| 6 | Starter Motor |
| 7 | Transmission Control (EATX) |
| 8 | Spare |
| 9 | Auto Shut Down |
| 10 | Spare |
| 11 | Radiator Fan Control |
| 12 | Spare |
Relay's
| CAUTION | When installing the Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Integrated Power Module, and possibly result in a electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
