Cabin Compartment Node (Ccn) - Electrical Diagnostics: Other Jeep Liberty II

Monitor Conditions

1. When Monitored: With the ignition on, during the heated seat operation.

Set Conditions

1. Set Condition: This code sets immediately when the Heated Seat Module (HSM) detects that the (P187) Left Seat Heater B(+) Driver circuit is shorted to ground.

Possible Causes

Scheme 366

Scheme 367

Scheme 368

Scheme 369

1. VERIFY DTC B1092-FRONT LEFT SEAT HEATER CONTROL CIRCUIT LOW IS ACTIVE Turn the ignition on. With the scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1092-FRONT LEFT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Verify that the seat harness is routed correctly. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Attempt to reproduce condition by adjusting the seat. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK (P187) LEFT SEAT HEATER B(+) DRIVER CIRCUIT IN BODY HARNESS FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Left Seat Cushion Heater connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool, erase DTCs. Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1092-FRONT LEFT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Go to step 3 No Go to step 5
3. CHECK (P187) LEFT SEAT HEATER B(+) DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the HSM connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the (P187) Left Seat Heater B(+) Driver circuit between ground and the HSM connector. Is the resistance below 10K Ohms? Yes Repair the (P187) Left Seat Heater B(+) Driver circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. CHECK (P187) LEFT SEAT HEATER B(+) DRIVER CIRCUIT FOR A SHORT TO (Z913) GROUND CIRCUIT Measure the resistance between the (P187) Left Seat Heater B(+) Driver circuit and the (Z913) Ground circuit at the HSM connector. Is the resistance below 10K Ohms? Yes Repair the (P187) Left Seat Heater B(+) Driver circuit for a short to the (Z913) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Heated Seat Module (HSM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK LEFT SEAT CUSHION HEATER FOR A SHORT TO GROUND Turn the ignition off. Reconnect the Left Seat Cushion Heater connector. Disconnect the Left Seat Back Heater connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool, erase DTCs. Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1092-FRONT LEFT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Replace the shorted Left Seat Cushion Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Left Seat Back Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on, during the heated seat operation.

1. Set Condition: This code sets immediately when the Heated Seat Module (HSM) detects that the (P187) Left Seat Heater B(+) Driver circuit is open.

Scheme 370

Scheme 371

Scheme 372

Scheme 373

1. VERIFY DTC B1094-FRONT LEFT SEAT HEATER CONTROL CIRCUIT OPEN IS ACTIVE Turn the ignition on. With the scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1094-FRONT LEFT SEAT HEATER CONTROL CIRCUIT OPEN active? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Verify that the seat harness is routed correctly. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Attempt to reproduce condition by adjusting the seat. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK FOR OPEN SEAT HEATER ELEMENTS Turn the ignition off. Disconnect the Left Seat Cushion Heater connector. NOTE: Check connectors. Clean and repair as necessary. Measure the total resistance of the Cushion and Seat Back Heater Elements between the (P187) Left Seat Heater B(+) Driver circuit and the (Z913) Ground circuit at the Left Seat Cushion Heater connector (component side). Is the total resistance 2.5 to 3.5 Ohms (+ or - 0.5 Ohms)? Yes Go to step 3 No Go to step 5
3. CHECK (Z913) GROUND CIRCUIT FOR AN OPEN Using a 12-volt test light connected to 12-volts, check the (Z913) Ground circuit at the Left Seat Cushion Heater connector (harness side). NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go to step 4 No Repair the (Z913) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. CHECK (P187) LEFT SEAT HEATER B(+) DRIVER CIRCUIT FOR AN OPEN IN BODY HARNESS Disconnect the HSM connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the (P187) Left Seat Heater B(+) Driver circuit between the HSM connector and the Left Seat Cushion Heater connector (harness side). Is the resistance below 5.0 Ohms? Yes Replace the Heated Seat Module (HSM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the (P187) Left Seat Heater B(+) Driver circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK LEFT SEAT BACK HEATER ELEMENT FOR AN OPEN Disconnect the Left Seat Back Heater connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the Left Seat Back Heater Element between the (P187) Left Seat Heater B(+) Driver and the (Z913) Ground circuit at the Left Seat Back Heater connector (component side). Is the resistance above 6.0 Ohms? Yes Replace the Seat Back Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Seat Cushion Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 374

1. When Monitored: With the ignition on, during the heated seat operation.

1. Set Condition: This code is set immediately when the Heated Seat Module (HSM) detects that the (P188) Right Seat Heater B(+) Driver circuit is shorted to ground.

Scheme 375

Scheme 376

Scheme 377

Scheme 378

1. VERIFY DTC B1096-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT LOW IS ACTIVE Turn the ignition on. With the scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1096-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Verify that the seat harness is routed correctly. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Attempt to reproduce condition by adjusting the seat. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK (P188) RIGHT SEAT HEATER B(+) DRIVER CIRCUIT IN BODY HARNESS FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Right Seat Cushion Heater connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool, erase DTCs. Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1096-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Go to step 3 No Go to step 5
3. CHECK (P188) RIGHT SEAT HEATER B(+) DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the HSM connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the (P188) Right Seat Heater B(+) Driver circuit between ground and the HSM connector. Is the resistance below 10K Ohms? Yes Repair the (P188) Right Seat Heater B(+) Driver circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. CHECK (P188) RIGHT SEAT HEATER B(+) DRIVER CIRCUIT FOR A SHORT TO (Z914) GROUND CIRCUIT Measure the resistance between the (P188) Right Seat Heater B(+) Driver circuit and the (Z914) Ground circuit at the HSM connector. Is the resistance below 10K Ohms? Yes Repair the (P188) Right Seat Heater B(+) Driver circuit for a short to the (Z914) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Heated Seat Module (HSM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK RIGHT SEAT CUSHION HEATER FOR A SHORT TO GROUND Turn the ignition off. Reconnect the Right Seat Cushion Heater connector. Disconnect the Right Seat Back Heater connector. NOTE: Check connectors. Clean and repair as necessary. Turn the ignition on. With the scan tool, erase DTCs. Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1096-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT LOW active? Yes Replace the shorted Right Seat Cushion Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Right Seat Back Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on, during the heated seat operation.

1. Set Condition: This code sets immediately when the Heated Seat Module (HSM) detects that the (P188) Right Seat Heater B(+) Driver circuit is open.

Scheme 379

Scheme 380

Scheme 381

Scheme 382

1. VERIFY DTC B1098-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT OPEN IS ACTIVE Turn the ignition on. With the scan tool, record and erase Diagnostic Trouble Codes (DTCs). Operate the Heated Seat Switch in both positions several times. With the scan tool, read DTCs. Is DTC B1098-FRONT RIGHT SEAT HEATER CONTROL CIRCUIT OPEN active? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Verify that the seat harness is routed correctly. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Attempt to reproduce condition by adjusting the seat. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK FOR OPEN SEAT HEATER ELEMENTS Turn the ignition off. Disconnect the Right Seat Cushion Heater connector. NOTE: Check connectors. Clean and repair as necessary. Measure the total resistance of the Cushion and Seat Back Heater Elements between (P188) Right Seat Heater B(+) Driver circuit and the (Z914) Ground circuit at the Right Seat Cushion Heater connector (component side). Is the total resistance 2.5 to 3.5 Ohms (+ or - 0.5 Ohms)? Yes Go to step 3 No Go to step 5
3. CHECK (Z914) GROUND CIRCUIT FOR AN OPEN Using a 12-volt test light connected to 12-volts, check the (Z914) Ground circuit at the Right Seat Cushion Heater connector (harness side). NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go to step 4 No Repair the (Z914) Ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. CHECK (P188) RIGHT SEAT HEATER B(+) DRIVER CIRCUIT FOR AN OPEN IN BODY HARNESS Disconnect the HSM connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the (P188) Right Seat Heater B(+) Driver circuit between the HSM connector and the Right Seat Cushion Heater connector (harness side). Is the resistance below 5.0 Ohms? Yes Replace the Heated Seat Module (HSM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the (P188) Right Seat Heater B(+) Driver circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK RIGHT SEAT BACK HEATER ELEMENT FOR AN OPEN Disconnect the Right Seat Back Heater connector. NOTE: Check connectors. Clean and repair as necessary. Measure the resistance of the Right Seat Back Heater Element between the (P188) Right Seat Heater B(+) Driver and the (Z914) Ground circuit at the Right Seat Back Heater connector (component side). Is the resistance above 6.0 Ohms? Yes Replace the Seat Back Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Seat Cushion Heater Element in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on.

1. Set Condition: If the Cluster/Cabin Compartment Node (CCN) senses the Left Heated Seat switch input for more than 10 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: If the Cluster/Cabin Compartment Node (CCN) senses the Right Heated Seat switch input for more than 10 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Menu Switch active for greater than 20 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: Failure in Compass performance.

Scheme 383

Scheme 384

1. CHECK FOR AN ACTIVE DTC NOTE: Remove any electronic devices (laptop computers, cell phones) from the instrument panel. NOTE: Before proceeding, check the compass variance and calibration in accordance with the Service Information. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. (F921) FUSED RUN RELAY OUTPUT CIRCUIT OPEN Turn the ignition off. Disconnect the Compass Module harness connector. Ignition on, engine not running. Using a 12-volt test light connected to ground, check the (F921) Fused Run Relay Output circuit. Does the test light illuminate brightly? Yes Go to step 3 No Repair the open in the (F921) Fused Run Relay Output circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
3. (Z916) GROUND CIRCUIT OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z916) Ground circuit. Does the test light illuminate brightly? Yes Replace the Compass Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (Z916) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Compass/Temp Button is active for greater than 20 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Reset Switch is active for greater than 20 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Trip/Toggle Switch is active for greater than 20 seconds.

1. When Monitored: With the Radio on.

1. Set Condition: The Cluster Detects the Radio Control MUX (multiplex) circuit is open or shorted to voltage.

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Scheme 393

Scheme 394

1. CHECK FOR ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read the active DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. EVIC OR NON-EVIC VEHICLE Is this vehicle equipped with EVIC controls on the Steering Wheel? Yes Go to step 12 No Go to step 3
3. (X20) RADIO CONTROL MUX CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Cluster C3 harness connector. Turn the ignition on. Measure the voltage on the (X20) Radio Control MUX circuit. Is the voltage above 10.0 volts? Yes Repair the short to voltage in the (X20) Radio Control MUX circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. LEFT REMOTE RADIO SWITCH Turn the ignition off. Reconnect the Cluster C3 harness connector. Disconnect the Left Remote Radio Switch harness connector. Connect a 5 Amp fused jumper wire between cavity 1 and cavity 2 in the Left Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage below 1.0 volt? Yes Replace the Left Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 5
5. RIGHT REMOTE RADIO SWITCH Turn the ignition off. Connect the Left Remote Radio Switch harness connector. Disconnect the Right Remote Radio Switch harness connector. Connect a 5 Amp fused jumper wire between cavity 1 and cavity 2 in the Right Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage below 1.0 volt? Yes Replace the Right Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 6
6. (X20) RADIO CONTROL MUX CIRCUIT OPEN Turn the ignition off. Disconnect the Left Remote Radio Switch harness connector. Disconnect the Cluster C3 harness connector. Measure the resistance of the (X20) Radio Control MUX circuit between the Cluster C3 and Remote Radio Switches harness connectors. Is the resistance above 5.0 Ohms? Yes Go to step 7 No Go to step 9
7. (X20) RADIO CONTROL MUX CIRCUIT OPEN BETWEEN REMOTE RADIO SWITCHES AND CLOCKSPRING Turn the ignition off. Disconnect the Clockspring C8 harness connector. Measure the resistance of the (X20) Radio Control MUX circuit between the Remote Radio Switches and Clockspring C8 harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (X20) Radio Control MUX circuit for a open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 8
8. (X20) RADIO CONTROL MUX CIRCUIT OPEN BETWEEN CLOCKSPRING AND CLUSTER Disconnect the Clockspring C2 harness connector. Measure the resistance of the (X20) Radio Control MUX circuit between the Cluster C3 and Clockspring C2 harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (X20) Radio Control MUX circuit for a open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
9. (X920) RADIO CONTROL MUX RETURN CIRCUIT OPEN Disconnect the Cluster C2 harness connector. Measure the resistance of the (X920) Radio Control MUX Return circuit between the Cluster C2 and Remote Radio Switches harness connectors. Are the resistances above 5.0 Ohms? Yes Go to step 10 No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
10. (X920) RADIO CONTROL MUX RETURN CIRCUIT OPEN BETWEEN REMOTE RADIO SWITCHES AND CLOCKSPRING Disconnect the Clockspring C8 harness connector. Measure the resistance of the (X920) Radio Control MUX Return circuit between the Remote Radio Switches and Clockspring C8 harness connectors. Are the resistances above 5.0 Ohms? Yes Repair the open in the (X920) Radio Control MUX Return circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 11
11. (X920) RADIO CONTROL MUX RETURN CIRCUIT OPEN BETWEEN CLOCKSPRING AND CLUSTER Disconnect the Clockspring C2 harness connector. Measure the resistance of the (X920) Radio Control MUX Return circuit between the Cluster C2 and Clockspring C2 harness connectors. Is the resistance above 5.0 Ohms? Yes Repair the open in the (X920) Radio Control MUX Return circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
12. (X20) RADIO CONTROL MUX CIRCUIT SHORT TO VOLTAGE Turn the ignition off. Disconnect the Right Steering Wheel Switch harness connector. Turn the ignition on. Measure the voltage on the (X20) Radio Control MUX circuit. Is the voltage above 10.0 volts? Yes Repair the short to voltage in the (X20) Radio Control MUX circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 13
13. LEFT REMOTE RADIO SWITCH Turn the ignition off. Connect the Right Steering Wheel Switch harness connector. Disconnect the Left Remote Radio Switch harness connector. Connect a 5 Amp fused jumper wire between cavity 1 and cavity 2 in the Left Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage below 1.0 volt? Yes Replace the Left Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 14
14. RIGHT REMOTE RADIO SWITCH Turn the ignition off. Connect the Left Remote Radio Switch harness connector. Disconnect the Right Remote Radio Switch harness connector. Connect a 5 Amp fused jumper wire between cavity 1 and cavity 2 in the Right Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage below 1.0 volt? Yes Replace the Right Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 15
15. (X20) RADIO CONTROL MUX CIRCUIT OPEN Turn the ignition off. Disconnect the Right Steering Wheel Switch harness connector. Measure the resistance of the (X20) Radio Control MUX circuit. Are the resistances above 5.0 Ohms? Yes Repair the open in the (X20) Radio Control MUX circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 16
16. (X920) RADIO CONTROL MUX RETURN CIRCUIT OPEN Measure the resistance of the (X920) Radio Control MUX Return circuit. Are the resistances above 5.0 Ohms? Yes Repair the open in the (X20) Radio Control MUX circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Right Steering Wheel Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition in any position except off.

1. Set Condition: The Cluster detects a stuck switch state on the (X20) Radio Control MUX (multiplex) circuit for more than 30 seconds.

Scheme 395

1. CHECK FOR ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. LEFT REMOTE RADIO SWITCH Turn the ignition off. Disconnect the Left Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage approximately 5.0 volts? Yes Replace the Left Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 3
3. RIGHT REMOTE RADIO SWITCH Turn the ignition off. Disconnect the Right Remote Radio Switch harness connector. Turn the ignition on. With the scan tool monitor the Remote Radio Control Switch voltage. Is the voltage approximately 5.0 volts? Yes Replace the Right Remote Radio Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. (X20) RADIO CONTROL MUX CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (X20) Radio Control MUX circuit. Is the resistance below 100.0 Ohms? Yes Using the Wiring Diagrams as a guide, repair the short to ground in the (X20) Radio Control MUX circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Steering Wheel Control Down Switch is active for greater than 20 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Steering Wheel Control Right Switch is active for greater than 20 seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Head Lamp Switch Input circuit voltage is less than the expected value.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Panel Dimmer Switch Input Circuit voltage is less than the expected value.

1. When Monitored: With the ignition on and the Panel Illumination active.

1. Set Condition: Panel Illumination Status LOW.

Scheme 396

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Activate the Panel Illumination. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
2. CHECK EACH NON-FUNCTIONING COMPONENT FOR AN INTERNAL SHORT TO GROUND NOTE: Using the wiring diagram as a guide disconnect each non-functioning component one at a time while checking for the DTC to become stored. Repeat these steps for each component. Turn the ignition off. Disconnect the non-functioning component harness connector. Turn the ignition on. Activate the Panel Illumination. With the scan tool, read DTCs. Is the DTC still active? Yes Go to step 3 No Replace the non-functioning component that when disconnected caused the DTC to become stored in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
3. CHECK THE (E12) PANEL LAMPS DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Instrument Cluster C1 harness connector. With all (E12) Panel Lamps Driver circuit components disconnected, measure the resistance to ground on the (E12) Panel Lamps Driver Circuit from the Instrument Cluster C1 harness connector. Is the resistance less than 10K ohms? Yes Repair the (E12) Panel Lamps Driver circuit for a short to ground. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Replace the Cluster in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)

1. When Monitored: With the ignition on and the Panel Illumination circuit active.

1. Set Condition: The Instrument Cluster detects an open condition on the Panel Illumination Control circuit.

Scheme 397

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Activate the Panel Illumination. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
2. CHECK THE (E12) PANEL LAMPS DRIVER CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C1 harness connector. Inspect the connector and associated wiring for the Panel illumination circuit. Using a fused jumper wire connected to 12 volts, probe cavity 2 of the Cluster C1 harness connector. Did the components illuminate? Yes Replace the Instrument Cluster in accordance with the service information. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Using the wiring diagrams as a guide, locate and repair the (E12) Panel Lamps Driver circuit for an open. Perform BODY VERIFICATION TEST - VER 1. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)

Scheme 398

1. When Monitored: With the ignition on.

1. Set Condition: When the Cluster detects a short to battery on the Control circuit.

Scheme 399

Scheme 400

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Clear all Cluster DTCs. Turn the Courtesy Lamps on. With the scan tool, read DTCs. Does the scan tool read: B161A-COURTESY/DOME LAMP CONTROL CIRCUIT? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK THE (M24) COURTESY LAMPS DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C2 harness connector. Measure the resistance between the (M24) Courtesy Lamp Driver circuit and ground. Is the resistance below 5.0 Ohms? Yes Repair the (M24) Courtesy Lamp Driver circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 3
3. CHECK THE (M24) COURTESY LAMPS DRIVER CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Cluster C2 harness connector. Turn the ignition on. Measure the voltage of the (M24) Courtesy Lamp Driver circuit. Is the voltage below 10.0 volts? Yes Repair the (M24) Courtesy Lamp Driver circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 401

1. When Monitored: Continuously

1. Set Condition: When the Cluster detects a short to battery on the Control circuit.

Scheme 402

Scheme 403

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. Turn the Courtesy Lamps on. With the scan tool, read DTCs. Does the scan tool read: B161E-READING LAMP CONTROL CIRCUIT? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
2. CHECK THE (M27) READING/RAIL LAMPS DRIVER CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Cluster C2 harness connector. Measure the resistance between the (M27) Reading/Rail Lamps Driver circuit and ground. Is the resistance below 5.0 Ohms? Yes Repair the (M27) Reading/Rail Lamps Driver circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 3
3. CHECK THE (M27) READING/RAIL LAMPS DRIVER CIRCUIT FOR AN OPEN Turn the ignition off. Disconnect the Rear Dome Lamp harness connector. Measure the resistance of the (M27) Reading/Rail Lamps Driver circuit. Is the resistance above 10 Ohms? Yes Repair the (M27) Reading/Rail Lamps Driver circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Front Fog Lamp Switch Input Circuit voltage is less than the expected value.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Turn Signal function inoperative.

1. When Monitored: Ignition on.

1. Set Condition: If the Heated Seat Module (HSM) detects voltage under 10 volts on the (P693) Fused Run Relay Output circuit.

Scheme 404

1. CHECK FOR CHARGING SYSTEM DIAGNOSTIC TROUBLE CODES (DTCs) Turn the ignition on. With the scan tool, read Powertrain Control Module (PCM) / Engine Control Module (ECM) DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to «DTC-Based Diagnostics/MODULE, Powertrain Control (PCM) - Diagnosis and Testing»(ref-350089) for gasoline engine applications Refer to «DTC-Based Diagnostics/MODULE, Engine Control (ECM) - Diagnosis and Testing»(ref-350090) for diesel engine applications. No Go to step 2
2. VERIFY DTC B2181-HEATED SEAT MODULE POWER SUPPLY LOW IS ACTIVE With the scan tool, record and erase DTCs. Turn the ignition off. Start the engine and let it run for one minute. With the scan tool, read DTCs. Does DTC B2181-HEATED SEAT MODULE POWER SUPPLY LOW reset? Yes Go to step 3 No The conditions that caused this code to set are not present at this time. Verify that the seat harness is routed correctly to the HSM. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension. Attempt to reproduce condition by adjusting the seat. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
3. CHECK (P693) FUSED RUN RELAY OUTPUT CIRCUIT VOLTAGE Turn the ignition off. Disconnect the HSM harness connector. NOTE: Check connectors - Clean and repair as necessary. Start the engine. Allow the engine to idle. Measure the voltage of the (P693) Fused Run Relay Output circuit between the HSM connector and ground and compare it to the voltage at the vehicle battery. Is the voltage measured at the HSM connector the same as the voltage measured at the battery? Yes Replace the Heated Seat Module (HSM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the (P693) Fused Run Relay Output circuit for the cause of the low voltage condition at the HSM. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With ignition on.

1. Set Condition: If the Heated Seat Module (HSM) detects voltage over 16.0 volts on the (P693) Fused Run Relay Output circuit.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Wiper Mode Switch Input circuit voltage is less than the expected value.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the Washer Switch Input circuit voltage is less than the expected value.

1. When Monitored: Continuously.

1. Set Condition: When the Cluster senses the horn switch input for more than 30 seconds.

Scheme 405

Scheme 406

Scheme 407

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. Using a scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. CHECK FOR A SHORTED HORN SWITCH WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Remove the driver airbag in accordance with the Service Information. Disconnect the Horn Switch connector. NOTE: Before proceeding, thoroughly inspect the wiring harness and connectors between the horn switch and the Right Steering Wheel Switch. Look for chafed, pierced, pinched or partially broken wires and broken, bent, pushed out, spread, corroded or contaminated terminals. WARNING: Turn the ignition on, then reconnect the 12-volt battery. Failure to follow these instructions may result in possible serious or fatal injury. Cycle the ignition switch and then wait 30 seconds. With the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go to step 3 No Replace the Horn Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
3. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND Turn the ignition off. Disconnect the Right Steering Wheel Switch harness connector. Measure the resistance of the (X3) Horn Switch Sense circuit between ground and the Right Steering Wheel Switch harness connector. Is the resistance below 10K Ohms? Yes Repair the (X3) Horn Switch Sense circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR A SHORT TO (Z910) GROUND CIRCUIT, (G907) EVIC/NAV MUX RETURN CIRCUIT, OR TO (X920) RADIO CONTROL MUX RETURN CIRCUIT Disconnect the Clockspring C8 harness connector. Measure the resistance between the (X3) Horn Switch Sense circuit and the (Z910) Ground circuit at the Right Steering Wheel Switch harness connector. Measure the resistance between the (X3) Horn Switch Sense circuit and the (G907) EVIC/NAV MUX Return circuit at the Right Steering Wheel Switch harness connector. Measure the resistance between the (X3) Horn Switch Sense circuit and the (X920) Radio Control MUX Return circuit at the Right Steering Wheel Switch connector. Is the resistance below 10K Ohms between the (X3) Horn Switch Sense circuit and any of the other circuits? Yes Repair all circuits with a resistance below 10K Ohms for a short to the (X3) Horn Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 5
5. CHECK FOR A SHORTED RIGHT STEERING WHEEL SWITCH Replace the Right Steering Wheel Switch in accordance with the Service Information. Reconnect the horn switch connector. Turn the ignition on. Using a scan tool, erase the DTCs. Operate the horn switch several times. Cycle the ignition switch. Turn the ignition on and wait 30 seconds. Using a scan tool, read the DTCs. Does the scan tool display DTC: B2339-HORN SWITCH STUCK? Yes Replace the Right Steering Wheel Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Test complete. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 408

For complete wiring diagrams refer to SYSTEM WIRING DIAGRAMS .

1. When Monitored: Continuously.

1. Set Condition: When the Cluster senses the Horn Switch input for more than 30 seconds.

Scheme 409

Scheme 410

Scheme 411

Scheme 412

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display DTC: B2339-HORN SWITCH STUCK? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. CHECK FOR SHORTED (X3) HORN SWITCH SENSE CIRCUIT BETWEEN CLOCKSPRING AND CLUSTER Turn the ignition off. Remove the steering column shroud in accordance with the Service Information. Disconnect the Clockspring C2 connector. Turn the ignition on. With the scan tool, read the DTCs. Does the scan tool display DTC: B2339-HORN SWITCH STUCK? Yes Go to step 3 No Go to step 5
3. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND BETWEEN CLOCKSPRING AND CLUSTER Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (X3) Horn Switch Sense circuit between ground and the Clockspring C2 harness connector. Is the resistance below 10K Ohms? Yes Repair the short to ground in the (X3) Horn Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR SHORT TO (X920) RADIO CONTROL MUX RETURN CIRCUIT OR TO (V937) S/C SWITCH RETURN CIRCUIT BETWEEN CLOCKSPRING AND CLUSTER Measure the resistance between the (X3) Horn Switch Sense circuit and the (X920) Radio Control MUX Return circuit at the Clockspring C2 harness connector. Measure the resistance between the (X3) Horn Switch Sense circuit and the (V937) S/C Switch Return circuit at the Clockspring C2 harness connector. Is the resistance below 10K Ohms for either measurement? Yes Repair all circuits with a resistance below 10K Ohms for a short to the (X3) Horn Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK FOR A SHORTED HORN SWITCH WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Remove the driver airbag in accordance with the Service Information. Disconnect the horn switch connector. NOTE: Before proceeding, thoroughly inspect the wiring harness between the horn switch and the Clockspring. Look for chafed, pierced, pinched or partially broken wires and broken, bent, pushed out, spread, corroded or contaminated terminals. Reconnect the Clockspring C2 harness connector. WARNING: Turn the ignition on, then reconnect the 12-volt battery. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, read the DTCs. Does the scan tool display DTC: B2339-HORN SWITCH STUCK? Yes Go to step 6 No Replace the Horn Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
6. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR A SHORT TO GROUND BETWEEN HORN SWITCH AND CLOCKSPRING Turn the ignition off. Disconnect the Clockspring C8 harness connector. Measure the resistance of the (X3) Horn Switch Sense circuit between ground and the Clockspring C8 harness connector. Is the resistance below 10K Ohms? Yes Repair the short to ground in the (X3) Horn Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 7
7. CHECK (X3) HORN SWITCH SENSE CIRCUIT FOR A SHORT TO (X920) RADIO CONTROL MUX RETURN CIRCUIT OR TO (V937) S/C SWITCH RETURN CIRCUIT BETWEEN HORN SWITCH AND CLOCKSPRING Measure the resistance between (X3) Horn Switch Sense circuit and the (X920) Radio Control MUX Return circuit at the Clockspring C8 harness connector. Measure the resistance between (X3) Horn Switch Sense circuit and the (V937) S/C Return circuit at the Clockspring C8 connector. Is the resistance below 10K Ohms for either measurement? Yes Repair all circuits with a resistance below 10K Ohms for a short to the (X3) Horn Switch Sense circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects that the High Beam function is inoperative.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects that the Mist function is inoperative.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects that the Flash to Pass / Optical Horn function is inoperative.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects the TRAC/ESP Off Switch is active for greater than 20 seconds.

Note. The Electronic Stability Control (ESC) may also be referred to as Electronic Stability Program (ESP) depending on the vehicle model year and configuration.

1. When Monitored: Ignition on.

1. Set Condition: The Transfer Case Position Sensor Input circuit voltage is below a specified value for a calibrated amount of time.

Scheme 413

1. CHECK FOR ACTIVE DTC Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. TRANSFER CASE SELECTOR SWITCH Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 3 No Replace the Transfer Case Selector Switch. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
3. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (K77) Transfer Case Position Sensor Input circuit. Is the resistance less than 5.0 Ohms? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

1. When Monitored: Ignition on.

1. Set Condition: The Transfer Case Position Sensor Input circuit voltage is above a specified value for a calibrated amount of time.

Scheme 414

Scheme 415

Scheme 416

1. DTC IS ACTIVE Turn the ignition on. Using the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 3 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Transfer Case Selector Switch harness connector. Disconnect the Cluster C3 harness connector. Turn the ignition on. Measure the voltage of the (K77) Transfer Case Position Sensor Input circuit at the Transfer Case Selector Switch harness connector. Is the voltage above 5.0 volts? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 3
3. TRANSFER CASE SELECTOR SWITCH Turn the ignition off. Reconnect the Cluster C3 harness connector. Connect a jumper wire between the (K77) Transfer Case Position Sensor Input circuit and the (Y13) Transfer Case Position Signal Return circuit in the Transfer Case Selector Switch harness connector. Turn the ignition on. Using the scan tool, read the DTCs. Does the scan tool display this DTC as active? Yes Go to step 4 No Replace the Transfer Case Selector Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT OPEN Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance of the (K77) Transfer Case Position Sensor Input circuit between the Transfer Case Selector Switch harness connector and the Cluster C3 harness connector. Is the resistance greater than 5.0 Ohms? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 5
5. (Y13) TRANSFER CASE POSITION SIGNAL RETURN CIRCUIT OPEN Disconnect the Cluster C2 harness connector. Measure the resistance of the (Y13) Transfer Case Position Signal Return circuit between the Transfer Case Selector Switch harness connector and the Cluster C2 harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (Y13) Transfer Case Position Signal Return circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 417

1. When Monitored: Ignition on.

1. Set Condition: The Cluster detects the Overdrive/Tow Switch function active for more than 10 seconds.

Scheme 418

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. Press the Overdrive/Tow Switch three times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. OVERDRIVE/TOW SWITCH Turn the ignition off. Disconnect the Shift Lever Assembly. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 3 No Replace the Shift Lever Assembly in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
3. (T6) TOW/HAUL OD OFF SIGNAL CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the Cluster C3 harness connector. Measure the resistance between ground and the (T6) Tow/Haul OD Off Signal circuit. Is the resistance below 10K Ohms? Yes Repair the (T6) Tow/Haul OD Off Signal circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 419

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster detects a fault on the (K321) BTSI Unlock Signal circuit.

Scheme 420

Scheme 421

Scheme 422

Scheme 423

Scheme 424

1. CHECK FOR ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Is the DTC active? Yes Go to step 2 No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chaffed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals.
2. BTSI SOLENOID Turn the ignition off. Disconnect the Shift Lever Assembly harness connector. Turn the ignition on. Press the brake pedal. Using a 12-volt test light connected to ground, check the voltage of the (K321) BTSI Unlock Signal circuit. Does the test light illuminate brightly when the brake pedal is depressed? Yes Go to step 3 No Go to step 4
3. BTSI SOLENOID GROUND CIRCUITS Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the Ground circuits in the Shift Lever Assembly harness connector. Does the test light illuminate brightly for each circuit? Yes Replace the Shift Lever Assembly in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the appropriate ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. (K321) BTSI UNLOCK SIGNAL CIRCUIT SHORT TO VOLTAGE Turn the ignition off. Disconnect the Cluster C3 harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, check the voltage of the (K321) BTSI Unlock Signal circuit. Does the test light illuminate brightly? Yes Repair the (K321) BTSI Unlock Signal circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 5
5. (K321) BTSI UNLOCK SIGNAL SHORT TO GROUND Turn the ignition off. Using a test light connected to 12-volts, check the (K321) BTSI Unlock Signal circuit. Does the test light illuminate brightly? Yes Repair the (K321) BTSI Unlock Signal circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 6
6. (K321) BTSI UNLOCK SIGNAL CIRCUIT OPEN Measure the resistance of the (K321) BTSI Unlock Signal circuit. Is the resistance above 10K Ohms? Yes Repair the (K321) BTSI Unlock Signal for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 425

1. When Monitored: With the ignition on.

1. Set Condition: If the Cluster (CCN) senses the Inverter switch input for more than 20 seconds.

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: The controller detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

1. When Monitored: Continuously when the ignition is on. The battery voltage between 10.0 and 16.0 Volts. Ignition Off Draw (IOD) fuse installed. Totally Integrated Power Module (TIPM) is configured correctly.

1. Set Condition: Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster does not receive information from the Compass Module.

Scheme 426

Scheme 427

1. CHECK FOR AN ACTIVE DTC NOTE: Remove any electronic devices (laptop computers, cell phones) from the instrument panel. NOTE: Before proceeding, check the compass variance and calibration in accordance with the Service Information. Turn the ignition on. With the scan tool, record and erase DTCs. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
2. (D506) LIN BUS CIRCUIT Turn the ignition off. Disconnect the Compass Module harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5 volts? Yes Go to step 4 No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN Turn the ignition off. Disconnect the Instrument Cluster C2 harness connector. Measure the resistance of the (D506) LIN BUS circuit. Is the resistance below 10K ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
4. (F921) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN Turn the ignition on. Using a 12-volt test light connected to ground, check the (F921) Fused Ignition Switch Output (RUN) circuit at the Compass Module harness connector. Does the test light illuminate brightly? Yes Go to step 5 No Repair the (F921) Fused Ignition Switch Output (RUN) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
5. (Z916) GROUND CIRCUIT OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z916) Ground circuit at the Compass Module harness connector. Does the test light illuminate brightly? Yes Replace the Compass Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Repair the (Z916) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 volts. Ignition Off Draw (IOD) fused installed. Totally Integrated Power Module (TIPM) is configured correctly.

1. Set Condition: Bus messages not received from the Radio for approximately two to five seconds.

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster does not receive information from the Heated Seats Control Module.

Scheme 428

Scheme 429

Scheme 430

Scheme 431

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display the DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. (D506) LIN BUS CIRCUIT OPEN Turn the ignition off. Disconnect the Heated Seats Module harness connector. Turn the ignition on. Is the voltage above 5.0 volts? Yes Go to step 4 No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN Turn the ignition off. Disconnect the Cluster C2 harness connector. Turn the ignition on. Measure the resistance of the (D506) LIN BUS circuit. Is the resistance below 10K Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. (P693) HEATED SEAT MODULE SUPPLY Using a 12-volt test light connected to ground, check the (P693) Heated Seat Module Supply circuit. Does the test light illuminate brightly? Yes Go to step 5 No Repair the (P693) Heated Seat Module Supply circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. (Z914) GROUND CIRCUIT OPEN Using a 12-volt test light connected to 12 volts, check the (Z914) Ground circuit. Does the test light illuminate brightly? Yes Replace the Heated Seats Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the (Z914) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 432

1. When Monitored: With the ignition on.

1. Set Condition: LIN 1 Bus circuit performance.

Scheme 433

Scheme 434

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. SHORTED LIN BUS COMPONENT NOTE: After disconnecting each component, check DTCs with the scan tool. Turn the ignition on. Disconnect the Compass Module harness connector. Disconnect the Heated Seat Module harness connector. Disconnect the Switch Bank harness connector. Disconnect the Multifunction Switch harness connector. Disconnect the Right Steering Wheel Switch harness connector. With each component disconnected, did the DTC U1008-LIN 1 BUS change from active to stored? Yes Replace the component that caused the DTC U1008-LIN 1 BUS to change from active to stored. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN Turn the ignition off. Disconnect the Cluster C2 harness connector. Disconnect the Switch Bank harness connector. Measure the resistance of the (D506) LIN Bus circuit. Is the resistance above 10K Ohms? Yes Repair the (D506) LIN Bus circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 4
4. (D506) LIN BUS CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance to ground on the (D506) LIN Bus circuit. Is the resistance below 10K Ohms? Yes Repair the (D506) LIN Bus circuit for a short to ground. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 435

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster does not receive information from the Right Steering Wheel Switch.

Scheme 436

Scheme 437

Scheme 438

Scheme 439

Scheme 440

Scheme 441

Scheme 442

Scheme 443

Scheme 444

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. CHECK THE VOLTAGE OF (D506) LIN BUS CIRCUIT AT THE RIGHT STEERING WHEEL SWITCH Turn the ignition off. Disconnect the Right Steering Wheel Switch harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN Bus circuit at the Right Steering Wheel Switch harness connector. Is the voltage above 5.0 volts? Yes Go to step 5 No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN BETWEEN THE RIGHT STEERING WHEEL SWITCH AND CLOCKSPRING Turn the ignition off. Disconnect the Clockspring C8 harness connector. Measure the resistance of the (D506) LIN Bus circuit between the Right Steering Wheel Switch and Clockspring C8 harness connectors. Is the resistance below 5.0 Ohms? Yes Go to step 4 No Repair the open in the (D506) LIN Bus circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. CHECK THE VOLTAGE OF (D506) LIN BUS CIRCUIT AT THE CLOCKSPRING Disconnect the Clockspring C2 harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN Bus circuit at the Clockspring C2 harness connector. Is the voltage above 5.0 volts? Yes Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (D506) LIN Bus circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. CHECK THE VOLTAGE OF (A909) FUSED B(+) CIRCUIT AT THE RIGHT STEERING WHEEL SWITCH Measure the voltage of the (A909) Fused B(+) circuit at the Right Steering Wheel Switch harness connector. Is the voltage above 10.0 volts? Yes Go to step 8 No Go to step 6
6. (A909) FUSED B(+) CIRCUIT OPEN BETWEEN THE RIGHT STEERING WHEEL SWITCH AND CLOCKSPRING Turn the ignition off. Disconnect the Clockspring C8 harness connector. Measure the resistance of the (A909) Fused B(+) circuit between the Right Steering Wheel Switch and Clockspring C8 harness connectors. Is the resistance below 5.0 Ohms? Yes Go to step 7 No Repair the open in the (A909) Fused B(+) circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
7. (A909) FUSED B(+) CIRCUIT OPEN BETWEEN THE CLOCKSPRING AND TOTALLY INTEGRATED POWER MODULE Turn the ignition off. Disconnect the Clockspring C2 harness connector. Turn the ignition on. Measure the voltage of the (A909) Fused B(+) circuit at the Clockspring C2 harness connectors. Is the voltage above 10.0 volts? Yes Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (A909) Fused B(+) circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
8. CHECK THE (Z910) GROUND CIRCUIT AT THE RIGHT STEERING WHEEL SWITCH Turn the ignition off. Measure the resistance between ground and the (Z910) Ground circuit at the Right Steering Wheel Switch harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Right Steering Wheel Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Go to step 9
9. (Z910) GROUND CIRCUIT OPEN BETWEEN THE RIGHT STEERING WHEEL SWITCH AND CLOCKSPRING Disconnect the Clockspring C8 harness connector. Measure the resistance of the (Z910) Ground circuit between the Right Steering Wheel Switch and Clockspring C8 harness connectors. Is the resistance below 5.0 Ohms? Yes Go to step 10 No Repair the open in the (Z910) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
10. (Z910) GROUND CIRCUIT OPEN BETWEEN THE CLOCKSPRING AND GROUND Disconnect the Clockspring C2 harness connector. Measure the resistance between ground and the (Z910) Ground circuit at the Clockspring C2 harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Clockspring in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (Z910) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .

Scheme 445

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster does not receive information from the Switch Bank Module.

Scheme 446

Scheme 447

Scheme 448

Scheme 449

1. CHECK FOR AN ACTIVE DTC Turn the ignition on. With the scan tool, record and erase DTCs. Wait 30 seconds. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No The condition that caused this code to set is not present at this time. Check for an intermittent condition by inspecting the related wiring harness for chafed, pierced, pinched, and partially broken wires. Also inspect the related connectors for broken, bent, pushed out, spread, corroded, or contaminated terminals. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
2. (D506) LIN BUS CIRCUIT Turn the ignition off. Disconnect the Switch Bank Module harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5.0 volts? Yes Go to step 4 No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN Turn the ignition off. Disconnect the Cluster C2 harness connector. Measure the resistance of the (D506) LIN BUS circuit. Is the resistance below 5.0 ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Repair the (D506) LIN BUS circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
4. (A909) FUSED B+ CIRCUIT OPEN Using a 12-volt test light connected to ground, check the (A909) Fused B+ circuit at the Switch Bank Module harness connector. Does the test light illuminate brightly? Yes Go to step 5 No Repair the (A909) Fused B+ circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)
5. (Z910) GROUND CIRCUIT OPEN Turn the ignition off. Using a 12-volt test light connected to 12-volts, check the (Z910) Ground circuit at the Switch Bank Module harness connector. Does the test light illuminate brightly? Yes Replace the Switch Bank Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) No Repair the (Z910) ground circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000)

Scheme 450

1. When Monitored: With the ignition on.

1. Set Condition: The Cluster does not receive information from the Left Multifunction Switch

Scheme 451

Scheme 452

Scheme 453

Scheme 454

1. CHECK FOR AN ACTIVE DTC NOTE: Before proceeding with this diagnostic procedure, verify the Left and Right Multifunction Switch and Clockspring harness connectors are properly seated and verify proper pin terminal tension. A loose connection at any of these connectors may cause this DTC to set. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Go to step 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals, and correct pin tension.
2. (D506) LIN BUS CIRCUIT Turn the ignition off. Disconnect the Left Multifunction Switch harness connector. Turn the ignition on. Measure the voltage of the (D506) LIN BUS circuit. Is the voltage above 5.0 volts? Yes Go to step 4 No Go to step 3
3. (D506) LIN BUS CIRCUIT OPEN BETWEEN THE CLUSTER AND LEFT MULTIFUNCTION SWITCH Turn the ignition off. Disconnect the Cluster C2 harness connector. Measure the resistance of the (D506) LIN BUS circuit. Is the resistance below 5.0 Ohms? Yes Replace the Cluster in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (D506) LIN BUS circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
4. (F943) FUSED RUN/START RELAY OUTPUT CIRCUIT OPEN Measure the voltage of the (F943) Fused RUN/START Relay Output circuit at the Left Multifunction Switch harness connector. Is the voltage above 10.0 volts? Yes Go to step 5 No Repair the open in the (F943) Fused RUN/START Relay Output. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
5. (Z910) GROUND CIRCUIT OPEN Turn the ignition off. Measure the resistance between ground and the (Z910) Ground circuit at the Left Multifunction Switch harness connector. Is the resistance below 5.0 Ohms? Yes Replace the Left Multifunction Switch in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) . No Repair the open in the (Z910) ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-350093-S36937059432009121400000) .
