REMOVAL
The window motor is incorporated into the window regulator assembly. If the window motor requires replacement, the window regulator must be replaced. See WINDOW REGULATOR .
Scheme 1
Scheme 1: DIAGNOSIS AND TESTING - WINDOW SWITCH
Scheme 2
Scheme 3
Scheme 4
- Remove the switch to be tested. See «REMOVAL»(ref-174946-S07602897922005041200000) .
- Using an ohmmeter, test front switch for continuity.
- If the proper results are not obtained, replace the front window switch.
- Test rear switch for continuity.
- If the proper results are not obtained, replace the rear window switch.
Auto-Down Feature
The power window master switch has a Auto-Down feature on both front windows. The switch is equipped with two detent positions when actuating the power window OPEN. The first detent position allows the window to roll down and stop when the switch is released. The second detent position actuates an integral express roll down relay that rolls the window down after the switch is released. When the express down circuit senses stall current (window has reached end of down travel), the switch will turn current off to the motor. The AUTO feature can be cancelled by actuating the switch UP or DOWN while window is in motion. If the electronic circuit in the switch fails to detect a stall current, the auto down circuit will time out within 9 to 14 seconds.
Scheme 5
- Disconnect and isolate the battery negative cable.
- Using a trim stick, gently pry the switch from the console.
- Disconnect electrical harness connector.
Scheme 6
- Disconnect and isolate the battery negative cable.
- Using a trim stick, gently pry the switch from the console.
- Disconnect electrical harness connector.
REMOVAL - FRONT
| CAUTION | DO NOT allow the waterdam or adhesive to become contaminated with dirt or other foreign substances. |
| CAUTION | DO NOT damage the waterdam during removal and installation. |
| CAUTION | If the waterdam becomes contaminated or damaged, replace the waterdam. |
- Remove the door speaker. See AUDIO/SPEAKER - REMOVAL .
- Separate the waterdam from the inner door panel and off of the latch linkages.
INSTALLATION - FRONT
| CAUTION | DO NOT allow the waterdam or adhesive to become contaminated with dirt or other foreign substances. DO NOT damage the waterdam during removal and installation. If the waterdam becomes contaminated or damaged, replace the waterdam. |
- Position the wire harness and actuator rods through the holes in the waterdam.
- Place waterdam onto the door and pressurize at the butyl bead to seal completely, starting with the top rear locating indent and then moving to the top front locating indent followed by the remaining portion of the waterdam.
- Run a hard plastic squeegee firmly around the perimeter of the waterdam making sure that the drain holes at the bottom of the inner door panel are fully covered by the waterdam.
- Install the speaker.
REMOVAL - REAR
| CAUTION | DO NOT allow the waterdam or adhesive to become contaminated with dirt or other foreign substances. |
| CAUTION | DO NOT damage the waterdam during removal or installation. |
| CAUTION | If the waterdam becomes contaminated or damaged, replace the waterdam. |
- Remove the door speaker. See AUDIO/SPEAKER - REMOVAL .
- Separate the waterdam from the inner door panel and off the latch linkages.
INSTALLATION - REAR
| CAUTION | DO NOT allow the waterdam or adhesive to become contaminated with dirt or other foreign substances. |
| CAUTION | DO NOT damage the waterdam during removal or installation. |
| CAUTION | If the waterdam becomes contaminated or damaged, replace the waterdam. |
- Position the actuator rods through the holes in the waterdam.
- Place the waterdam onto the door and pressurize at the butyl bead to seal completely, starting with the top rear locating indent followed by the remaining portion or the waterdam.
- Run hard plastic squeegee firmly around the perimeter of the waterdam making sure that the drain holes at the bottom of the inner door panel are fully covered by the waterdam.
- Install door speaker.
- Remove the waterdam. See «WATERDAM»(ref-174946-S31787065562005041300000) .
- Raise the glass. Using a long flat blade or hook type tool, disengage clips attaching glass retainer to regulator lift plate.
- Disconnect the glass from the regulator lift plate and re-install the clips.
- Secure the glass in the up position using a wood wedge, tape or equivalent.
- Loosen the bolts.
- Disconnect the runout tube clip.
- Disconnect the electrical connector and remove the regulator.
- Install the regulator assembly.
- Connect the electrical connector.
- Tighten the bolts to 9 N.m (80 in. lbs.). For the passenger side regulator, tighten bolts in the following sequence, at the following positions; 12 o'clock, 6 o'clock, then 9 o'clock position. For the driver side regulator, tighten bolts in the following sequence, at the following positions; 12 o'clock, 6 o'clock, then 3 o'clock position.
- Connect the runout tube clip.
- Remove the glass support and connect to the regulator lift plate.
- Install the waterdam. See «WATERDAM»(ref-174946-S31787065562005041300000) .
- Remove the waterdam. See «WATERDAM»(ref-174946-S31787065562005041300000) .
- Raise the glass and line up the lift plate clip with the hole in the door panel.
- Using a long flat blade or hook type tool, disengage the clip attaching glass retainer to regulator lift plate.
- Disconnect the glass from the regulator lift plate and re-install the clip.
- Secure the glass in the up position using a wood wedge, tape or equivalent.
- Remove the bolts.
- Disconnect the runout tube clip and remove the regulator.
- Disconnect the electrical connector.
- Connect the electrical connector.
- Loosely install the bolts onto the regulator assembly.
- Tighten the bolts to 9 N.m (80 in. lbs.). For the passenger side regulator, tighten bolts in the following sequence, at the following positions; 6 o'clock, 12 o'clock, then 9 o'clock position. For the driver side regulator, tighten bolts in the following sequence, at the following positions; 6 o'clock, 12 o'clock, then 3 o'clock position.
- Remove the glass support and connect to the regulator lift plate.
- Install the waterdam. See «WATERDAM»(ref-174946-S31787065562005041300000) .
- Remove the inside handle screw plug and remove the screw.
- Remove the pull handle screw.
- Using a trim stick C-4755 or equivalent, disengage the trim panel clips and remove the trim panel.
- Disconnect the electrical connectors and the inside handle actuator rod.
- Connect the inside handle actuator rod and the electrical connectors.
- Position the trim panel and seat the clips fully.
- Instal the screws and install the screw plug.
- Remove the inside handle screw plug and remove the screw.
- Remove the pull handle screw.
- Using a trim stick C-4755 or equivalent, disengage the trim panel clips and remove the trim panel.
- Disconnect the electrical connectors and the inside handle actuator rod.
- Connect the inside handle actuator rod and the electrical connectors.
- Position the trim panel and seat the clips fully.
- Instal the screws and install the screw plug.
