Power Transfer Unit - Service Information: Specifications Jeep Compass I рестайлинг

SPECIFICATIONS

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Disconnect negative battery cable (2).
2. Remove the engine trim cover.
3. Remove air cleaner assembly (1).
4. Remove Power Distribution Center (PDC) from bracket.
5. Raise the vehicle on the hoist.
6. Remove front halfshafts. Refer to «Removal»(ref-462452-S27729310862012040500000) .
7. Remove drain plug (2) at PTU and allow fluid to drain.
8. Reinstall drain plug.
9. Mark (2) prop shaft and differential (3) for proper installation.
10. Remove the rear prop shaft. Refer to «Removal»(/jeep/compass/i-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
11. Remove the two exhaust to maniverter (exhaust manifold with catalytic converter) bolts (1).
12. Unplug the downstream O2 sensor connector.
13. Remove the exhaust system. Refer to «MUFFLER, Exhaust, Removal»(ref-462494-S22346038582012040500000) .
14. Lower the vehicle on the hoist.
15. Unplug the upstream O2 sensor connector.
16. Remove upstream O2 sensor from the maniverter (exhaust manifold with catalytic converter) using O2s (Oxygen Sensor) Remover/Installer (special tool #8439, O2 Sensor Wrench) (2).
17. Remove the four maniverter heat shield bolts (1).
18. Remove the two retaining bolts (2) and one nut (1) from the maniverter side heat shield (3).
19. Remove the seven maniverter to head retaining bolts.
20. Slide the maniverter up and to the right, support the maniverter (1) with the help of a bungie cord.
21. Raise the vehicle on the hoist.
22. Remove the four (1) engine to maniverter bracket bolts.
23. Remove the rear engine mount through bolt (2).
24. Remove the three front engine mount to frame bolts and the mount through bolt.
25. Remove the PTU mounting bolts (1, 2).
26. Install a screw jack (2) on front engine mount bracket (1).
27. Raise the front of the engine until the rear mount has dropped (1, 2).
28. Separate the PTU from the transaxle.
29. Remove and discard old O-ring between Transmission and PTU.
30. Roll the PTU (1) forward and down to remove.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. Remove extension housing bolts.
2. Remove the extension housing.
3. Remove the extension housing O-ring.
4. Using a chisel (2) remove the dust shield (1) from the extension housing (3).
5. Remove the pinion housing bolts.
6. Remove the pinion housing.
7. Remove the pinion housing shim.
8. Remove the pinion housing O-ring. NOTE: The pinion nut is a staked type nut.
9. Using a chisel or a grinder, remove the staked depression in the pinion nut.
10. Remove the output shaft nut, using the Output Shaft Nut Socket (special tool #9921, Wrench, Pinion Nut) and Spline Socket (special tool #9922, Socket, Splined).
11. Press the output shaft from the housing using a press.
12. Remove the output shaft spacer.
13. Remove the output shaft bearing.
14. Remove the output shaft housing small side bearing cup using a brass drift.
15. Remove the output shaft housing large side bearing cup using a brass drift.
16. Install Puller (special tool #6444, Puller, Bearing/Gear) and Jaws (special tool #6451, Jaws, Puller) onto output shaft head bearing.
17. Place Puller in a vice and remove the bearing.
18. Remove the inspection cover bolts (1).
19. Remove the inspection cover.
20. Remove the side cover bolts (1).
21. Remove the side cover from case.
22. Remove the carrier assembly. NOTE: Bearing cup is a slip fit.
23. Remove bearing cup by hand (1) or by using a pick.
24. Remove the shim (1) under the bearing cup (3). Measure and record the size of the shim.
25. Remove the inner seal from the PTU cover.
26. Remove the outer seal from the PTU cover.
27. Remove bearing cup by hand (1) or by using a pick.
28. Remove the shim (3) under the bearing cup (1). Measure and record the size of the shim.
29. Remove the carrier case seal.
30. Remove the ring gear bolts.
31. Remove the ring gear.
32. Remove ring gear side bearing using Puller (special tool #C-293-PA, Puller, Press), Inserts (special tool #C-293-37, Block Set, Puller) and Insert (special tool #C-4487-1, Adapter).
33. Remove output side bearing using Puller (special tool #C-293-PA, Puller, Press), Inserts (special tool #C-293-37, Block Set, Puller) and Insert (special tool #C-4487-1, Adapter).

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. Install output side spool shaft bearing using Installer (special tool #C-3095-A, Installer, Bearing).
2. Install ring gear side bearing using Installer (special tool #8148, Cup).
3. Install the ring gear.
4. Install the new ring gear bolts and tighten to 74 N.m (55 ft. lbs.).
5. Install the carrier case seal using Installer (special tool #9851, Installer, Seal) and Handle (special tool #C-4171, Driver Handle, Universal).
6. Install the shim (3) under the bearing cup (1) in the case side.
7. Install the bearing cup by hand.
8. Install the inner seal into the PTU cover using Installer (special tool #9852, Installer, Seal) and Handle (special tool #C-4171, Driver Handle, Universal).
9. Install the outer seal into the PTU cover using Installer (special tool #9853, Installer, Seal) and Handle (special tool #C-4171, Driver Handle, Universal).
10. Install the shim (1) under the bearing cup (3).
11. Install bearing cup by hand (3).
12. Install the carrier assembly into the case
13. Install the side cover
14. Tighten side cover bolts (1) to 23 N.m (17 ft. lbs.).
15. Install the output shaft head bearing on to the pinion shaft using Installer (special tool #9714, Installer, Bearing) and a Press.
16. Install the output shaft head bearing cup using Installer (special tool #6061, Installer, Cup) and Handle (special tool #C-4171, Driver Handle, Universal).
17. Install the output shaft tail bearing cup using Installer (special tool #9855, Installer, Bearing Cup) and Handle (special tool #C-4171, Driver Handle, Universal).
18. Install the output shaft spacer onto the output shaft.
19. Install output shaft into output shaft housing.
20. Install output shaft tail bearing on to out put shaft using Installer (special tool #L-4411, Installer, Bearing). NOTE: The output shaft nut is a staked type nut.
21. Install the output shaft nut (1) onto the output shaft (2).
22. Tighten the output shaft nut using Pinion Nut Socket (special tool #9921, Wrench, Pinion Nut) to 150 N.m (111 ft. lbs.).
23. Using an inch pound torque wrench check and Pinion Nut Socket (special tool #9921, Wrench, Pinion Nut) (1) check the rotating torque, it should be 30 in. lbs. Add 0.002 in. larger shim to increase rotating torque and add 0.002 in. smaller shim to decrease rotating torque. Repeat until proper turning torque is obtained.
24. Using a punch stake the output shaft nut.
25. Install the pinion housing O-ring (3).
26. Install the pinion housing shim (1).
27. Install the output shaft seal using Installer (special tool #9851, Installer, Seal) and Handle (special tool #C-4171, Driver Handle, Universal).
28. Install a new extension housing O-ring.
29. Install the output shaft housing and bolts onto the carrier housing.
30. Apply pattern check grease to the ring gear.
31. Using a block of wood (2) install the dust shield (3) onto the extension housing (1).
32. Install the extension housing and bolts.
33. Tighten output shaft housing bolts to 38 N.m (28 ft. lbs.).
34. Tighten the extension housing bolts to 38 N.m (28 ft. lbs.).
35. Clean cover and apply MOPAR® axle RTV or equivalent.
36. Install the vent and bolts, tighten the bolts to 23 N.m (17 ft. lbs.).
37. Install the vent shield and bolts. tighten the bolts to 23 N.m (17 ft. lbs.).
38. Clean cover and apply MOPAR® axle RTV.
39. Apply MOPAR® lock AND seal adhesive or equivalent to bolts.
40. Install the inspection cover and bolts. tighten the bolts to 23 N.m (17 ft. lbs.).
41. Fill the PTU. Refer to «Standard Procedure»(ref-462499-S07966245282012040500000) .

Scheme 57

Scheme 58

Scheme 59

1. Roll the PTU in, moving from front to back (1). see scheme 70
2. Rest the PTU (1) on the frame (3) while the engine and transaxle (2) are raised back into position. (Scheme 57)
3. Lower screw jack (2) until rear mount through bolt can be installed. see scheme 72
4. Install rear mount through bolt (2) and tighten bolt to 75 Nm (55 ft. see scheme 73 lbs.).
5. Install the transmission crossmember and bolts, (2) tighten to 75 Nm (55 ft. lbs.).
6. Install the through bolt at the front transmission mount (1) and tighten to 75 Nm (55 ft. lbs.). NOTE: STICKING THE O-RING WITH VASELINE OR TRANS ASSEMBLY GREASE IS RECOMMENDED.
7. Insure that the O-ring (1) between the PTU and transaxle is in place. (Scheme 59)
8. Slide the PTU into place.
9. Install and tighten the PTU mounting bolts (1,2) to 58 N.m (43ft. lbs.).
10. Lower the hoist.
11. Install the maniverter. Refer to «CONVERTER, Catalytic, Installation»(ref-462494-S05861302702012040500000).
12. Install the air box (1).
13. Install engine trim cover.
14. Raise the vehicle on the hoist.
15. Install the exhaust system. Refer to «MUFFLER, Exhaust, Installation»(ref-462494-S41184946632012040500000).
16. Install the Prop shaft. Refer to «Installation»(/jeep/compass/i-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft__installation).
17. Install the axle shafts. Refer to «Installation»(ref-462452-S00718294952012040500000) and «Installation»(/jeep/compass/i-2010-2013/remont/axle-shafts/#left-rear-half-shaft__installation) and «Installation»(/jeep/compass/i-2010-2013/remont/axle-shafts/#right-rear-half-shaft__installation).
18. Fill PTU. Refer to «Standard Procedure»(ref-462499-S07966245282012040500000).
19. Lower hoist.
20. Connect battery cables (2).
21. Top off the fluids. Refer to «Standard Procedure»(ref-462499-S07966245282012040500000).
