Driveability - Gas - Non-Dtc Based Diagnostics: Overview Jeep Compass I рестайлинг

Scheme 491

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Scheme 492

Scheme 493

Scheme 494

1. GENERATOR FULL FIELD TEST NOTE: Diagnose and repair any generator sense or field control circuit DTCs before proceeding with this test. Start the engine and allow it to reach operating temperature. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. With the scan tool, perform the Generator Full Field test. Follow the instructions displayed on the scan tool. Monitor the system (battery) voltage and the generator sense voltage on the scan tool while performing the test. NOTE: With the engine running, the difference between the system (battery) voltage and the generator sense voltage should be below 2 volts. NOTE: With the generator field fully actuated, the system (battery) voltage should be above 14.0 volts. NOTE: With the generator field actuated off, the system (battery) voltage should be below 13.0 volts, and eventually drop as battery load is increased. Did the system voltage change as described above during the Generator Full Field test? Yes Test complete. No Go to 2 .
2. CHARGING SYSTEM INSPECTION Inspect and test the battery in accordance with the Service Information. Inspect the generator drive belt for proper alignment and adjustment. Inspect the vehicle for aftermarket accessories that may exceed the generator system output. Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagrams as a guide and inspect the wiring and connectors for a damaged or shorted circuit. Were any problems found? Yes Repair as necessary. No Go to 3 .
3. BATTERY POSITIVE (+) CIRCUIT HIGH RESISTANCE NOTE: Make sure all testing equipment and cables are clear of any engine parts before starting the engine. Start the engine. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage between the B (+) Terminal at the Generator and the Battery Positive (+) Post. Is the voltage below 0.4 of a volt? Yes Go to 4 . No Repair the battery positive (+) circuit between the generator and battery for high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) .
4. GENERATOR CASE GROUND HIGH RESISTANCE NOTE: Make sure all testing equipment and cables are clear of any engine parts before starting the engine. Start the engine. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Measure the voltage between the Generator case and the Battery Negative (-) post. Is the voltage below 0.1 of a volt? Yes Go to 5 . No Repair the Generator Case ground for high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) for 2.0L and 2.4L.
5. (A801) FUSED B(+) CIRCUIT HIGH RESISTANCE Turn the ignition off. Using a voltmeter, perform a voltage drop test by probing the battery positive (+) terminal and backprobing the PCM C2 (A801) Fused B(+) circuit. Make sure the voltmeter leads are connected so that positive polarity is displayed on the voltmeter. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Start the engine. Is the voltage below 0.5 of a volt? Yes Go to 6 . No Repair the (A801) Fused B(+) circuit(s) for high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) for 2.0L and 2.4L.
6. (A804) GENERATOR SENSE CIRCUIT HIGH RESISTANCE Turn the ignition off. Using a voltmeter, perform a voltage drop test by backprobing the (A804) Generator Sense circuit at the Generator harness connector and backprobing PCM C2 (A804) generator sense circuit. Make sure the voltmeter leads are connected so that positive polarity is displayed on the voltmeter. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Start the engine. Is the voltage below 0.5 of a volt? Yes Go to 7 . No Repair the (A804) Generator Sense circuit for high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) .
7. (K20) GEN FIELD CONTROL CIRCUIT HIGH RESISTANCE Turn the ignition off. Using a voltmeter, perform a voltage drop test by backprobing the (K20) Gen Field Control circuit at the Generator harness connector and backprobing PCM C2 (K20) generator control circuit. Make sure the voltmeter leads are connected so that positive polarity is displayed on the voltmeter. WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts or fan. Do not wear loose clothing. Failure to follow these instructions may result in possible serious or fatal injury. Start the engine. Is the voltage below 0.5 of a volt? Yes Go to 8 . No Repair the (K20) Gen Field Control circuit for high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) .
8. GENERATOR Turn the ignition off. Disconnect the Generator harness connector. Connect a 12-volt test light connected between ground and the (K20) Gen Field Control circuit in the Generator harness connector. Turn the ignition on. With the scan tool, actuate the Alternator Field Control State to toggle. NOTE: The test light should toggle on and off with the actuation. NOTE: If a DTC is active, the actuation test may not be allowed by the PCM. If may be necessary to clear DTCs before starting the actuation. Does the test light illuminate on and off with the actuation? Yes Replace the Generator in accordance with the Service Information. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) . No Go to 9 .
9. (K20) GEN FIELD CONTROL CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Powertrain Control Module (PCM) C2 harness connector. Turn the ignition on. Measure the voltage of the (K20) Gen Field Control circuit in the Generator harness connector. Is there any voltage present? Yes Repair the (K20) Gen Field Control circuit for a short to voltage. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) . No Go to 10 .
10. (K20) GEN FIELD CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (K20) Gen Field Control circuit in the Generator harness connector. Is the resistance below 100 Ohms? Yes Repair the (K20) Gen Field Control circuit for a short to ground. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) . No Go to 11 .
11. (K20) GEN FIELD CONTROL CIRCUIT OPEN OR HIGH RESISTANCE CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals, resulting in poor terminal to pin connection. Install the PCM Pinout Box (special tool #8815A, Kit, NGC, 38 Position) to perform diagnosis. Measure the resistance of the (K20) Gen Field Control circuit between the Generator harness connector and the appropriate terminal of the PCM Pinout Box (special tool #8815A, Kit, NGC, 38 Position). Is the resistance below 5.0 Ohms? Yes Go to 12 . No Repair the (K20) Gen Field Control circuit for an open circuit or high resistance. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) .
12. CHECKING THE PCM POWER AND GROUND CIRCUITS Inspect the PCM power and ground circuits. Were any problems found? Yes Repair the PCM power and ground circuit(s) as necessary. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) . No Go to 13 .
13. POWERTRAIN CONTROL MODULE (PCM) Using the wiring diagram as a guide, inspect the wiring and connectors between the Generator and the Powertrain Control Module (PCM). Look for any chafed, pierced, pinched, or partially broken wires. Look for broken, bent, pushed out or corroded terminals. Perform any Technical Service Bulletins that may apply. Were any problems found? Yes Repair as necessary. Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) . No Replace and program the Powertrain Control Module (PCM) in accordance with the Service Information. Refer to «MODULE, Powertrain Control , Removal»(ref-462466-S42871077392012040500000) . Perform the POWERTRAIN VERIFICATION TEST. Refer to «POWERTRAIN VERIFICATION TEST»(ref-462523-S03338033562012040500000) .

Scheme 495

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .
