FRONT SUSPENSION FASTENER TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Hub Nut | 244 | 180 | |
| Lower Ball Joint Stud Pinch Bolt | 82 | 60 | |
| Lower Control Arm Front Pivot Bolt | 183 | 135 | |
| Lower Control Arm Rear Pivot Bolt | 183 | 135 | |
| Stabilizer Bar Cushion Retainer Screws | 30 | 22 | |
| Stabilizer Bar Link Nuts | 58 | 43 | |
| Strut Clevis-to-Knuckle Nuts | 110 | 81 | |
| Strut Rod Nut | 60 | 44 | |
| Strut-to-Tower Nuts | 48 | 35 | |
| Tie Rod Adjuster Jam Nut | 75 | 55 | |
| Tie Rod End-to-Knuckle Nut | 132 | 97 | |
| Wheel Mounting (Lug) Nuts | 135 | 100 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
The wheel bearing (5) and hub (3) are pressed into the knuckle (1). The wheel bearing is secured in place using a snap ring.
Scheme 14
One side of the wheel bearing has an integrated magnetic encoder ring for wheel speed sensor usage as equipped. It is important that the wheel speed sensor magnetic encoder ring (dark band) (3) be positioned to the inside of the knuckle or the wheel speed sensor will not operate correctly.
The wheel bearing is a Unit 1 type cartridge bearing that requires no maintenance. The wheel bearing can be serviced separately from the hub.
The hub supports the driveline halfshaft outer constant velocity (C/V) joint. Each is splined and meshes in the center of the hub. The outer C/V joint is retained to the hub using a nut. The nut is locked to the outer C/V stub shaft using a cotter pin.
The hub has five studs pressed into its flange.
REAR SUSPENSION FASTENER TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Brake Flex Hose Trailing Link Mounting Nut | 15 | 11 | |
| Brake Flex Hose Trailing Link Mounting Screw | 23 | 17 | |
| Crossmember Stay Brace Mounting screws | 25 | 18 | 221 |
| Hub And Bearing Mounting Bolts | 105 | 77 | |
| Hub Nut | 245 | 181 | |
| Lower Control Arm Trailing Link Bolt Nut | 95 | 70 | |
| Lower Control Arm Crossmember Mounting Bolt Nut | 95 | 70 | |
| Shock Assembly Lower Mounting Bolt Nut | 99 | 73 | |
| Shock Assembly Upper Mounting Nuts | 48 | 35 | |
| Shock Rod Nut | 24 | 18 | |
| Stabilizer Bar Cushion Retainer Screws | 34 | 25 | |
| Stabilizer Link Mounting Nuts | 58 | 43 | |
| Toe Link Trailing Link Mounting Bolt | 95 | 70 | |
| Toe Link Mounting Cam Bolt Nut | 35 | 26 | |
| Trailing Link Body Mounting Bolts | 110 | 81 | |
| Upper Control Arm Trailing Link Bolt Nut | 95 | 70 | |
| Upper Control Arm Crossmember Mounting Bolt | 95 | 70 | |
| Wheel Mounting (Lug) Nuts | 135 | 100 |
Scheme 15
Scheme 16
Scheme 17
Scheme 18
- Raise and support the vehicle. Refer to «STANDARD PROCEDURE»(ref-304322-S16806387812008110700000) .
- Remove the wheel mounting nuts (3), then the tire and wheel assembly (1).
- If equipped, while holding the stabilizer bar link lower stud stationary, remove the nut (2) securing the link to the lower control arm (4).
- Remove the lower shock mounting nut (3) and bolt (1).
- Remove the stay brace (3) mounting screws (2). Remove the stay brace.
- Remove the nut (2) and bolt (3) securing the lower control arm (4) to the trailing link (1).
- Remove the nut (6) and bolt (5) securing the lower control arm (4) to the crossmember (7).
- Remove the lower control arm (4).
