Power Distribution: Removal & Installation Jeep Compass I

Body Electrical 1 illustration ~117 words

INSTALLATION

  1. Install the AC power outlet.
  2. Connect electrical connector.
  3. Install the center console, refer to «INSTALLATION»(ref-304328-S27478197112008110700000) .
  4. Connect the battery negative cable.

REMOVAL

WARNINGDisable the airbag system before attempting any steering wheel, steering column, or instrument panel component diagnosis or service. Disconnect and isolate the negative battery (ground) cable, then wait two minutes for the airbag system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to take the proper precautions could result in accidental airbag deployment and possible personal injury or death.

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect and isolate the negative battery cable.
  2. Remove the shift bezel. Refer to «REMOVAL»(ref-304328-S37893031912008110700000) .
  3. Remove the center bezel from the instrument panel. Refer to «REMOVAL»(ref-304328-S32343677232008110700000) .
  4. Remove the fasteners from the mounting brackets of the inverter module.
  5. Disconnect the electrical connectors and remove the inverter module.
  1. Connect the electrical connectors to the inverter module.
  2. Install the fasteners to the mounting brackets.
  3. Install the center bezel to the instrument panel. Refer to «INSTALLATION»(ref-304328-S22690066882008110700000) .
  4. Install the shift bezel. Refer to «INSTALLATION»(ref-304328-S18642081122008110700000) .
  5. Connect the battery negative cable.
