TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Bolts, A/C Condenser to Radiator | 5.1 | 45 | |
| Bolt, Automatic Belt Tensioner Pulley - Gas Engine | 24 | 212 | |
| Bolt Automatic Belt Tension Assembly | 54 | 40 | |
| Bolts, Charge Air Cooler to Radiator (Turbo Equipped) | 5.1 | 45 | |
| Bolt, Coolant Recovery Bottle | 4 | 35 | |
| Bolts, Coolant Adapter | 18 | 160 | |
| Bolts, Inlet housing to coolant adapter | 8 | 70 | |
| Screw, bypass valve to radiator | 5.1 | 45 | |
| Screw, bypass tube to EGR Cooler | 10 | 88 | |
| Screw, transmission cooler to radiator | 5.1 | 45 | |
| Engine Coolant Temperature Sensor | 19 | 168 | |
| Pivot Bolt, Generator Mounting | 54 | 40 | |
| Locking Nut, Generator Mounting | 54 | 40 | |
| Screws, Transmission Cooler to Radiator | 8 | 70 | |
| Bolts, Water Pump to Engine Block | 25.5 | 225 | |
| EGR Cooler to exhaust manifold tube nuts | 20 | 14 | |
| EGR Cooler to exhaust manifold tube bolts | 20 | 14 | |
| EGR to EGR valve tube bolts | 20 | 14 | |
| Bolts, Water Pump Inlet Tube to water pump housing | 24 | 212 |
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
| 1 - GENERATOR |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - IDLER PULLEY |
| 4 - A/C COMPRESSOR |
| 5 - POWER STEERING PUMP |
| 6 - CRANKSHAFT PULLEY/VIBRATION DAMPER |
| 7 - BELT TENSIONER PULLEY |
| 8 - BELT TENSIONER |
The accessory drive belt on the 2.2L Diesel engine is of the serpentine style. This belt is used to drive the generator, power steering pump, and the A/C compressor.
Scheme 8
| 1 - POWER STEERING PUMP |
|---|
| 2 - ACCESSORY DRIVE BELT |
| 3 - GENERATOR |
| 4 - CRANKSHAFT PULLEY |
| 5 - LOWER IDLER PULLEY |
| 6 - CRANKSHAFT PULLEY |
| 7 - WATER PUMP PULLEY |
| 8 - ACCESSORY DRIVE BELT TENSIONER |
| 9 - UPPER IDLER PULLEY |
The accessory drive belt (2) is a serpentine type belt that is driven by the crankshaft pulley (6).
The belt drives the A/C compressor, generator (3), power steering pump (1) and water pump (7). Belt tension is maintained by an automatic belt tensioner (8).
Scheme 9
| 1 - NORMAL CRACKS ON BELT |
|---|
| 2 - NOT NORMAL CRACKS ON BELT |
When diagnosing serpentine accessory drive belts, small cracks that run across the ribbed surface of the belt from rib to rib (1), are considered normal. These are not a reason to replace the belt. However, cracks running along a rib (not across) (2) are not normal. Any belt with cracks running along a rib must be replaced. Also replace the belt if it has excessive wear, frayed cords or severe glazing.
Refer to ACCESSORY DRIVE BELT DIAGNOSIS CHART for further belt diagnosis.
