Power Windows - Service Information: Removal & Installation Jeep Compass I рестайлинг 2

REMOVAL

1. Move the window to the full UP position, if possible.
2. Disconnect and isolate the battery negative cable.
3. Remove the front door module. Refer to «PANEL, DOOR TRIM, BOLSTER, REMOVAL»(ref-612710-S03190722892014043000000) .
4. Disconnect electrical harness connector from motor.
5. Remove window regulator.
6. With regulator on bench, remove four screws retaining the motor to the regulator and remove motor.

INSTALLATION

1. With regulator on bench, install four screws retaining the motor to the regulator.
2. Install the window regulator.
3. Connect the electrical harness connector to window motor.
4. Install the door module. Refer to «PANEL, DOOR TRIM, BOLSTER, INSTALLATION»(ref-612710-S01032006442014043000000) .
5. Connect battery negative cable.

Scheme 2

1. Disconnect and isolate the battery negative cable.
2. Remove the front door bolster. Refer to «PANEL, DOOR TRIM, BOLSTER, REMOVAL»(ref-612710-S03190722892014043000000) .
3. Disconnect the electrical harness connectors.
4. With the bolster on the bench, gently pry in on the tabs of the mirror switch and push through the front of the cover and remove.

1. Place the mirror switch in bolster opening and firmly snap into place.
2. Connect the electrical harness connectors.
3. Install the front door bolster. Refer to «PANEL, DOOR TRIM, BOLSTER, INSTALLATION»(ref-612710-S01032006442014043000000) .
4. Connect the battery negative cable.
