SPECIFICATIONS
| Description | Type | Part Number | Capacities |
|---|
| U.S. | Metric |
| Cooling System |
| (1) Engine Coolant (2.0L and 2.4L Engines) | MOPAR® Antifreeze/Coolant 10 Year/150, 000 Mile Formula OAT (Organic Additive Technology) meeting the requirements of Chrysler Material Standard MS-12106 | 1 Gallon - 68163848AA (concentrate) 68163849AA (50/50) | 7.2 Quarts | 6.8 Liters |
| (1) Diesel Engine Coolant (2.2L Turbo Engine - OM651) | MOPAR® Antifreeze/Coolant 5 Year/100, 000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 05066386AA | 10 Quarts | 9.5 Liters |
| Engine Oil with Filter |
| (2) Engine Oil (2.0L and 2.4L Engines) | MOPAR® SAE 5W-20 engine oil or equivalent Pennzoil® or Shell Helix® | 1 Quart - 04761872AC | 4.5 Quarts | 4.26 Liters |
| 5 Quarts - 04761851AD |
| (2) Engine Oil (2.2L Turbo Diesel Engine - OM651) | For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils approved to MB 228.51, MB 229.31 or MB 229.51 and meeting the requirements of Chrysler Material Standard MS-10725. The manufacturer recommends the use of a full synthetic engine oil, such as low SPAsh Multigrade 0W-30, 0W-40, 5W-30, 5W-40, 10W-30, 10W-40. | N/A | 8.0 Quarts | 7.5 Liters |
| Engine Oil Filter (2.0L and 2.4L Engines) | MOPAR® Engine Oil Filter | 04892339AA | N/A | N/A |
| Engine Oil Filter (2.2L Turbo Diesel Engine - OM651) | MOPAR® Engine Oil Filter | 68091826AA | N/A | N/A |
| Fuel (approximate) |
| Fuel Selection (2.0L and 2.4L Engines) | 87 Octane Unleaded Fuel, Domestic | N/A | 13.6 Gallons | 51.5 Liters |
| 91 Octane Unleaded Fuel, Export |
| Fuel Selection (2.2L Turbo Diesel Engine - OM651) | Use only the best quality fuel with a calculated Cetane Index of 50 or higher. In addition, the manufacturer recommends using diesel fuel with a sulfur content of less than or equal to 15 ppm. | N/A | 13.6 Gallons | 51.5 Liters |
| A/C Refrigerant System |
| Refrigerant | R-134a | 82300101AB | 1.31 Pounds | 595 Grams |
| (1) System fill capacity includes heater and coolant recovery bottle filled to MAX level. |
| (2) For countries that use the ACEA European Oil Categories for Service Fill Oils, use the recommended engine oil that meets the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51 only. Refer to your engine oil filler cap for correct SAE grade. |
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| (1) | System fill capacity includes heater and coolant recovery bottle filled to MAX level. |
| (2) | For countries that use the ACEA European Oil Categories for Service Fill Oils, use the recommended engine oil that meets the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51 only. Refer to your engine oil filler cap for correct SAE grade. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| Description | Type | Part Number | Gap |
|---|
| U.S. | Metric |
| Spark Plugs (2.0L and 2.4L Engines) | NGK® Nickel | 04606823AB (ZFR5F-11) | 0.043 in | 1.10 mm |
| Description | Type | Part Number | Capacities |
|---|
| U.S. | Metric |
| Automatic |
| CVT - Service Fill | MOPAR® CVT+4 Automatic Transmission Fluid | 1 Quart - 05191184AA | 14.8 Pints | 7.0 Liters |
| 1 Gallon - 05191185AA |
| (1) CVT - Overhaul Fill | MOPAR® CVT+4 Automatic Transmission Fluid | 1 Quart - 05191184AA | 17.1 Pints | 8.1 Liters |
| 1 Gallon - 05191185AA |
| 6F24 | SK Energy ATF SP-4 Transmission Fluid | 1 Quart - 68171866AA | Factory Fill - 7.5 Quarts | Factory Fill - 7.1L |
| 1 Gallon - 68171869AA | Service Fill - Fill to COLD mark |
| Manual |
| NV T355 | MOPAR® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 2.5 - 2.8 Quarts | 2.4 - 2.7 Liters |
| 1 Gallon - 05013458AA |
| AISIN BG6 | MOPAR® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 2.1 Quarts | 2.0 Liters |
| 1 Gallon - 05013458AA |
| Driveline |
| POWER TRANSFER UNIT | MOPAR® MS 9020, SAE 80W90 Gear Lube | 1 Quart - 04874468 | 18.2 Ounces | 0.53 Liters |
| REAR DRIVE ASSEMBLY | MOPAR® MS 9020, SAE 80W90 Gear Lube | 1 Quart - 04874468 | 16.2 Ounces | 0.47 Liters |
| (1) Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to the appropriate service information for the correct procedures. |
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| (1) | Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to the appropriate service information for the correct procedures. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
TRANSMISSION AND DRIVELINE
| Description | Type | Part Number | Capacities |
|---|
| U.S. | Metric |
| Chassis Systems |
| (1) Brake Master Cylinder | MOPAR® Brake Fluid DOT 3, SAE J1703. | 12 oz. Bottle - 04318080AB | N/A | N/A |
| 32 oz. Bottle - 04318081AB |
| (2) Power Steering Reservoir | MOPAR® Power Steering Fluid +4 | 1 Quart - 05013457AA | N/A | N/A |
| (1) If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 (P/N 04549625AC), is acceptable. |
| (2) If MOPAR® Power Steering Fluid +4 is not available, then MOPAR® ATF +4 Automatic Transmission Fluid (P/N 05166226AA), is acceptable. |
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
| (1) | If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 (P/N 04549625AC), is acceptable. |
| (2) | If MOPAR® Power Steering Fluid +4 is not available, then MOPAR® ATF +4 Automatic Transmission Fluid (P/N 05166226AA), is acceptable. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
INTEGRATED POWER MODULE (IPM)
Scheme 1
An Integrated Power Module (IPM) is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini-fuses. A label that identifies each component may be printed on the inside of the cover. Refer to "Engine Compartment" of the Owner's Manual for the underhood location of the IPM.
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|
| 1 | Empty | | Empty |
| 2 | | 15 Amp Lt Blue | AWD/4WD Control Module - If Equipped |
| 3 | | 10 Amp Red | Rear Center Brake Light Switch |
| 4 | | 10 Amp Red | Ignition Switch/Occupant Classification Module |
| 5 | | 20 Amp Yellow | Trailer Tow - If Equipped |
| 6 | | 10 Amp Red | Power Mirror/Steering Control Satellite Radio/Hands-Free Phone |
| 7 | | 30 Amp Green | Ignition Off Draw |
| 8 | | 30 Amp Green | Ignition Off Draw |
| 9 | 40 Amp Green | | Power Seats |
| 10 | | 20 Amp Yellow | Power Locks/Interior Lighting |
| 11 | | 15 Amp Lt Blue | Power Outlet |
| 12 | | 20 Amp Yellow | 115V AC Inverter - If equipped |
| 13 | | 20 Amp Yellow | Cigar Lighter |
| 14 | | 10 Amp Red | Instrument Cluster |
| 15 | 40 Amp Green | | Radiator Fan |
| 16 | | 15 Amp Lt Blue | Dome Lamp/Sunroof/Rear Wiper Motor |
| 17 | | 10 Amp Red | Wireless Control Module |
| 18 | 40 Amp Green | | Auto Shutdown Relay |
| 19 | | 20 Amp Yellow | Radio Amplifiers |
| 20 | | 15 Amp Lt Blue | Radio |
| 21 | | 10 Amp Red | Intrusion Module/Siren - If Equipped |
| 22 | | 10 Amp Red | Heating, AC/Compass |
| 23 | | 15 Amp Lt Blue | Auto Shutdown Relay |
| 24 | | 15 Amp Lt Blue | Power Sunroof - If Equipped |
| 25 | | 10 Amp Red | Heated Mirror - If Equipped |
| 26 | | 15 Amp Lt Blue | Auto Shutdown Relay |
| 27 | | 10 Amp Red | Airbag Control Module |
| 28 | | 10 Amp Red | Airbag Control Module/Occupant Classification Module |
| 29 | | | Hot Car (No Fuse Required) |
| 30 | | 20 Amp Yellow | Heated Seats - If Equipped |
| 31 | | 10 Amp Red | Headlamp Washer - If Equipped |
| 32 | 30 Amp Pink | | Auto Shutdown Relay |
| 33 | | 10 Amp Red | J1962 Conn/Powertrain Control Module |
| 34 | 30 Amp Pink | | Antilock Brake Valve |
| 35 | 40 Amp Green | | Antilock Brake Pump |
| 36 | 30 Amp Pink | | Headlamp/Washer Control/Smart Glass - If Equipped |
| 37 | | 25 Amp Natural | Diesel Fuel Heater - If Equipped |
| CAUTION | When installing the IPM cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the IPM, and possibly result in an electrical system failure. |
| CAUTION | When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
Scheme 2
Scheme 2: STANDARD PROCEDURE - HOISTING
| 1 - DRIVE ON LIFT |
|---|
| 2 - FRAME CONTACT LIFT (SINGLE POST) |
| 2 - CHASSIS LIFT (DUAL POST) |
| 2 - OUTBOARD LIFT (DUAL LIFT) |
| 2 - FLOOR JACK |
Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures.
| WARNING | The hoisting and jack lifting points provided are for a complete vehicle. When the engine or rear suspension is removed from a vehicle, the center of gravity is altered making some hoisting conditions unstable. Properly support or secure vehicle to hoisting device when these conditions exist. |
| CAUTION | Do not position hoisting device on suspension components, damage to vehicle can result. Do not attempt to raise one entire side of the vehicle by placing a floor jack midway between the front and rear wheels. This practice may result in permanent damage to the body. |
When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands.
A floor jack or any lifting device, must never be used on any part of the underbody other then the described areas.
