THEORY OF OPERATION
The (X201) Left Front Speaker (+) circuit and the (X291) Left Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X201) Left Front Speaker (+) circuit and the (X291) Left Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X201) Left Front Speaker (+) circuit and the (X291) Left Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X202) Right Front Speaker (+) circuit and the (X292) Right Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X202) Right Front Speaker (+) circuit and the (X292) Right Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
| Possible Causes |
|---|
| (X202) RIGHT FRONT SPEAKER (+) CIRCUIT SHORTED TO VOLTAGE |
| (X292) RIGHT FRONT SPEAKER (-) CIRCUIT SHORTED TO VOLTAGE |
| RADIO |
Scheme 129
Scheme 130
- CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Radio DTCs. Using the scan tool, record and erase the Radio DTCs. Turn the Radio on. Adjust the speakers to the front and center. Using the scan tool, read the active Radio DTCs. Does the scan tool display active: B1406-FRONT RIGHT AUDIO SPEAKER OUTPUT CIRCUIT HIGH? Yes Go To 2 No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/compass/i-2-2013-2016/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
- CHECK FOR VOLTAGE ON THE (X202) RIGHT FRONT SPEAKER (+) CIRCUIT Turn the ignition off. Disconnect the Radio C2 harness connector. Disconnect the Right Front Speaker harness connector. Turn the ignition on. Measure the voltage between ground and the (X202) Right Front Speaker (+) circuit. Is there any voltage present? Yes Repair the (X202) Right Front Door Speaker (+) circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/compass/i-2-2013-2016/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Go To 3
- CHECK FOR VOLTAGE ON THE (X292) RIGHT FRONT SPEAKER (-) CIRCUIT Measure the voltage between ground and the (X292) Right Front Speaker (-) circuit. Is there any voltage present? Yes Repair the (X292) Right Front Door Speaker (-) circuit for a short to voltage. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/compass/i-2-2013-2016/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) . No Replace the Radio in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(/jeep/compass/i-2-2013-2016/remont/communication-devices/#totally-integrated-power-module-tipm-body-verification-test) .
The (X202) Right Front Speaker (+) circuit and the (X292) Right Front Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X205) Left Rear Speaker (+) circuit and the (X295) Left Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X51) Left Rear Audio (+) circuit and the (X57) Left Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X205) Left Rear Speaker (+) circuit and the (X295) Left Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X51) Left Rear Audio (+) circuit and the (X57) Left Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X205) Left Rear Speaker (+) circuit and the (X295) Left Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X51) Left Rear Audio (+) circuit and the (X57) Left Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X206) Right Rear Speaker (+) circuit and the (X296) Right Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X52) Right Rear Audio (+) circuit and the (X58) Right Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X206) Right Rear Speaker (+) circuit and the (X296) Right Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X52) Right Rear Audio (+) circuit and the (X58) Right Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X206) Right Rear Speaker (+) circuit and the (X296) Right Rear Speaker (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
The (X52) Right Rear Audio (+) circuit and the (X58) Right Rear Audio (-) circuit are outputs of the Radio. The Radio controls and monitors these circuits for a concern.
