All Wheel Drive (Awd) Module - Electrical Diagnostics: Other Jeep Compass I рестайлинг 2

WHEN MONITORED

The Solenoid is active, no solenoid supply circuit DTCs are present and battery voltage is normal.

SET CONDITION

The All Wheel Drive (AWD) Control Module detects the Electronically Controlled Clutch (ECC) Solenoid Power Control is shorted low.

POSSIBLE CAUSES

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

1. VERIFY THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 2 No Go To 10
2. ECC SOLENOID OPERATION Turn the ignition off. Disconnect the ECC Solenoid harness connector. Ignition on, engine not running. Using a 12-volt test light, jump across from the (T78) Solenoid Supply Voltage circuit and the (T312) Rear Differential Solenoid Control circuit in the ECC Solenoid harness connector. With the scan tool, actuate the ECC Solenoid. Does the test light illuminate brightly and flash on and off? Yes Go To 9 No Go To 3
3. (T312) REAR DIFFERENTIAL SOLENOID CONTROL CIRCUIT SHORTED TO GROUND Turn the ignition off. Disconnect the AWD Control Module harness connector. Measure the resistance between ground and the (T312) Rear Differential Solenoid Control circuit at the AWD Module harness connector. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (T312) Rear Differential Solenoid Control circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 4
4. (T312) REAR DIFFERENTIAL SOLENOID CONTROL CIRCUIT OPEN Measure the resistance of the (T312) Rear Differential Solenoid Control circuit between the ECC Solenoid harness connector and the AWD Control Module harness connector. Is the resistance below 5.0 Ohms? Yes Go To 5 No Repair the open in the (T312) Rear Differential Solenoid Control circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
5. (T78) SWITCHED BATTERY SOLENOID SUPPLY CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (T78) Solenoid Supply Voltage circuit at the ECC Solenoid harness connector. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (T78) Solenoid Supply Voltage circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 6
6. (T78) SWITCHED BATTERY SOLENOID SUPPLY CIRCUIT OPEN Measure the resistance of the (T78) Solenoid Supply Voltage circuit between the ECC Solenoid harness connector and the AWD Control Module harness connector. Is the resistance below 5.0 Ohms? Yes Go To 7 No Repair the open in the (T78) Solenoid Supply Voltage circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
7. ECC SOLENOID (T312) REAR DIFFERENTIAL SOLENOID CONTROL CIRCUIT SHORTED INTERNALLY Turn the ignition off. Disconnect the AWD Control Module harness connector. Connect the ECC Solenoid harness connector. Measure the resistance between ground and the (T312) Rear Differential Solenoid Control circuit at the AWD Module harness connector. Is the resistance below 100 Ohms? Yes Repair the short to ground in the (T312) Rear Differential Solenoid Control circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 8
8. AWD CONTROL MODULE NOTE: Before continuing, check the AWD Control Module harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Replace the All Wheel Drive (AWD) Control Module Control Module in accordance with Service Information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
9. ELECTRONICALLY CONTROLLED CLUTCH (ECC) NOTE: Before continuing, check the ECC Solenoid jumper harness connector terminals for corrosion, damage, or terminals push out, repair/replace as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Replace the Electronically Controlled Clutch (ECC) Solenoid in accordance with Service Information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
10. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

C145A-AWD CLUTCH RETURN CONTROL CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Solenoid is active, no solenoid supply circuit DTCs are present and battery voltage is normal.

The All Wheel Drive (AWD) Control Module detects the Electronically Controlled Clutch (ECC) Solenoid Supply is shorted low.

C145D-AWD CLUTCH POWER/RETURN CONTROL CIRCUIT OPEN

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

The Solenoid is active, no solenoid supply circuit DTCs are present and battery voltage is normal.

The All Wheel Drive (AWD) Control Module detects the Electronically Controlled Clutch (ECC) Solenoid Supply or Return Control circuit is open.

C145F-AWD SYSTEM TEMPORARILY DISABLED - OVERTEMPERATURE

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Ignition on.

The AWD Control Module detects an overheat condition due to excessive difference in speed across the ECC from hard driving conditions (Mud, Sand, Snow, 2WD Chassis dynamometer etc.).

Always perform the AWD Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

With the ignition on and no system undervoltage or overvoltage condition present.

The All Wheel Drive (AWD) Control Module Switch is not reporting a valid voltage for either switch position.

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

1. VERIFY THE DTC IS ACTIVE Ignition on, engine not running. NOTE: Repair any system undervoltage or overvoltage DTCs that are set in this module before proceeding. With the scan tool, read DTCs in the TIPM. Is the DTC active at this time? Yes Go To 2 No Go To 7
2. TRANSFER CASE SELECTOR SWITCH Turn the ignition off to the lock position. Disconnect the Transfer Case Selector Switch harness connector. Connect a jumper wire between the (K77) Transfer Case Position Sensor Input circuit and the (Z908) Ground circuit in the Transfer Case Selector Switch harness connector. Ignition on, engine not running. With the scan tool, read the Transfer Case Position Sensor Switch voltage. The switch voltage should be approximately 5.0 volts. Does the voltage display as described? Yes Replace the Transfer Case Selector Switch in accordance with the service information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 3
3. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT SHORTED TO GROUND Turn the ignition off to the lock position. Disconnect the CCN C3 harness connector. Measure the resistance between ground and the (K77) Transfer Case Position Sensor Input circuit. Is the resistance less than 5.0 Ohms? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to ground. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 4
4. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT SHORTED TO VOLTAGE Ignition on, engine not running. Measure the voltage of the (K77) Transfer Case Position Sensor Input circuit. Is the voltage above 10 volts? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for a short to voltage. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 5
5. (K77) TRANSFER CASE POSITION SENSOR INPUT CIRCUIT OPEN Turn the ignition off to the lock position. Measure the resistance of the (K77) Transfer Case Position Sensor Input circuit between the Transfer Case Selector Switch harness connector and the CCN C3 harness connector. Is the resistance greater than 5.0 Ohms? Yes Repair the (K77) Transfer Case Position Sensor Input circuit for an open. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 6
6. (Z908) GROUND CIRCUIT OPEN Measure the resistance of the (Z908) Ground circuit between the Transfer Case Selector Switch harness connector and the CCN C3 harness connector. Is the resistance above 5.0 Ohms? Yes Repair the (Z908) Ground circuit for an open. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Replace the All Wheel Drive (AWD) Control Module in accordance with Service Information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
7. INTERMITTENT TRANSFER CASE RANGE SELECT SWITCH PERFORMANCE The conditions necessary to set this DTC are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. While monitoring the scan tool data relative to this circuit, move the selector switch to each position several times. Look for the data to change other than as expected or for the DTC to reset. Were any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test complete.

Continuously.

The All Wheel Drive Control Module (AWD) detects that system voltage is below 8.0 volts for 10 seconds.

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

1. CHARGING SYSTEM DTCS PRESENT Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module. Are there any Charging System or related voltage DTCs present? Yes Perform the appropriate diagnostic procedure. Refer to the «DTC INDEX»(ref-612788) article . No Go To 2
2. VERIFY THE DTC IS ACTIVE Ignition on, engine running. Keep the engine at 1500 rpm for 15 seconds Maintain the engine at 1500 rpm for 15 seconds With the scan tool, select View DTCs. Is the DTC active at this time? Yes Go To 3 No Go To 10
3. CHECK THE TIPM (A923) FUSED B(+) VOLTAGE While back probing, measure the voltage of the (A923) Fused B(+) circuit in the TIPM C7 harness connector. Is the voltage above 9 volts? Yes Go To 4 No Go To 9
4. CHECK THE TIPM (F202) IGNITION SWITCH OUTPUT RUN/START VOLTAGE While back probing, measure the voltage of the (F202) Ignition Switch Output Run/Start circuit in the TIPM C11 harness connector. Is the voltage above 8 volts? Yes Go To 5 No Go To 9
5. (A923) FUSED B(+) CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the AWD Module harness connector. Disconnect the TIPM C7 harness connector. Connect a jumper wire between the (A923) Fused B(+) circuit and Ground in the TIPM C7 harness connector. With a 12-volt test light connected to B(+), check the (A923) Fused B(+) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 6 No Repair the (F202) Ignition Switch Output (RUN/START) circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
6. (F202) IGNITION SWITCH OUTPUT (RUN/START) CIRCUIT OPEN OR HIGH RESISTANCE Disconnect the TIPM C11 harness connector. Connect a jumper wire between the (F202) Ignition Switch Output (RUN/START) circuit and ground in the TIPM C11 harness connector. With a 12-volt test light connected to B(+), check the (F202) Ignition Switch Output (RUN/START) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 7 No Repair the (F202) Ignition Switch Output (RUN/START) circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
7. (Z906) GROUND CIRCUIT OPEN OR HIGH RESISTANCE With a 12-volt test light connected to B(+), check the (Z906) ground circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 8 No Repair the (Z906) Ground circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
8. AWD CONTROL MODULE NOTE: Before continuing, check the AWD Module harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Repair Replace theAll Wheel Drive (AWD) Control Module in accordance with the Service information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
9. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Repair Replace the Totally Integrated Power Module (TIPM) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612758-S33453045902014043000000) .
10. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

Continuously.

The All Wheel Drive Control Module (AWD) detects that system voltage is above 17.0 volts for more than 10 seconds.

C211C-IGNITION RUN/START INPUT CIRCUIT LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

With the ignition on.

The All Wheel Drive (AWD) Control Module will set this DTC if the Ignition Run/Start circuit voltage is less than the expected value for more than 10 seconds.

Scheme 317

1. VERIFY THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read the active DTC. Cycle the ignition switch from off to on, leaving the ignition on for a minimum of 10 seconds. With the scan tool, read the active DTC. Is the DTC active at this time? Yes Go To 2 No Go To 7
2. (F202) IGNITION SWITCH OUTPUT (RUN/START) VOLTAGE Turn the ignition off. Disconnect the AWD Control Module harness connector. Ignition on, engine not running. With a 12-volt test light connected to ground, check the (F202) Ignition Switch Output (RUN/START) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 3 No Go To 4
3. (Z906) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the AWD Control Module harness connector. With a 12-volt test light connected to B+, check the (Z906) Ground circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 5 No Repair the (Z906) Ground circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
4. (F202) IGNITION SWITCH OUTPUT (RUN/START) CIRCUIT OPEN OR HIGH RESISTANCE Disconnect the TIPM C11 harness connector. Connect a jumper wire between the (F202) Ignition Switch Output (RUN/START) circuit and B(+) in the TIPM C11 harness connector. With a 12-volt test light connected to ground, check the (F202) Ignition Switch Output (RUN/START) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 6 No Repair the (F202) Ignition Switch Output (RUN/START) circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
5. AWD CONTROL MODULE NOTE: Before continuing, check the AWD Module harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. . Repair Replace the All Wheel Drive (AWD) Control Module in accordance with the Service information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
6. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. Were any problems found? Repair Replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612758-S33453045902014043000000) .
7. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

C211D-IGNITION RUN/START INPUT CIRCUIT HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

The All Wheel Drive (AWD) Control Module detects that the ignition Switch circuit voltage is above 17.0 volts for more than 10 seconds.

Scheme 318

1. CHARGING SYSTEM DTCS PRESENT Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module. Are there any Charging System or related voltage DTCs present? Yes Perform the appropriate diagnostic procedure. Refer to the «DTC INDEX»(ref-612788) article . No Go To 2
2. VERIFY THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read the DTCs. Cycle the ignition switch from the OFF to ON position, leaving the ignition on for a minimum of 10 seconds. With the scan tool, read the DTCs. Is the DTC active at this time? Yes Go To 3 No Go To 8
3. (F202) IGNITION SWITCH OUTPUT (RUN/START) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the TIPM C11 harness connector. Disconnect the AWD Control Module harness connector. With a 12-volt test light connected to ground, check the (F202) Ignition Switch Output (RUN/START) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Repair the (F202) Ignition Switch Output (RUN/START) circuit for a short to voltage. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 4
4. (F202) IGNITION SWITCH OUTPUT (RUN/START) Reconnect the AWD Control Module harness connector. Reconnect the TIPM C11 harness connector. Ignition on, engine not running. With a 12-volt test light connected to ground, check the (F202) Ignition Switch Output (RUN/START) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 7 No Go To 5
5. CHECK THE TIPM (F202) IGNITION SWITCH OUTPUT (RUN/START) VOLTAGE While back probing, measure the voltage of the (F202) Ignition Switch Output Run/Start circuit in the TIPM C7 harness connector. Is the voltage below 17 volts? Yes Go To 7 No Go To 6
6. AWD CONTROL MODULE NOTE: Before continuing, check the AWD Module harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. View repair. Repair Replace the All Wheel Drive (AWD) Control Module in accordance with the Service information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
7. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. View repair. Repair Replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612758-S33453045902014043000000) .
8. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

C211E-BATTERY SUPPLY VOLTAGE LOW

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

The All Wheel Drive (AWD) Control Module detects that the Fused Battery (+) circuit voltage is below 2.0 volts for more than 1 second.

Scheme 319

1. CHARGING SYSTEM DTCS PRESENT Ignition on, engine not running. With the scan tool, select View DTCs in the Powertrain Control Module. Are there any Charging System or related voltage DTCs present? Yes Perform the appropriate diagnostic procedure. Refer to the «DTC INDEX»(ref-612788) article . No Go To 2
2. VERIFY THE DTC IS ACTIVE NOTE: Leave the ignition on for 2 seconds. With the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 3 No Go To 8
3. CHECK THE TIPM (A923) FUSED B+ VOLTAGE While back probing, measure the voltage of the (A923) Fused B+ circuit in the TIPM C7 harness connector. Is the voltage below 2 volts? Yes Go To 7 No Go To 4
4. (A923) FUSED B+ CIRCUIT OPEN OR HIGH RESISTANCE Turn the ignition off. Disconnect the AWD module harness connector. Ignition on, engine not running. With a 12-volt test light connected to ground, check the (A923) Fused B(+) circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 5 No Repair the (A923) Fused B+ circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
5. (Z906) GROUND CIRCUIT OPEN OR HIGH RESISTANCE Using a 12-volt test light connected to B(+), check the (Z906) Ground circuit in the AWD Control Module harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 6 No Repair the (Z906) Ground circuit for an open circuit or high resistance. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
6. AWD CONTROL MODULE NOTE: Before continuing, check the AWD Module harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. View repair. Repair Replace the All Wheel Drive (AWD) Control Module in accordance with the Service information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
7. TOTALLY INTEGRATED POWER MODULE NOTE: Before continuing, check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Repair as necessary. Using the schematics as a guide, inspect the wire harness and connectors. Pay particular attention to all Power and Ground circuits. View repair. Repair Replace the Totally Integrated Power Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612758-S33453045902014043000000) .
8. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

C211F-BATTERY SUPPLY VOLTAGE HIGH

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Continuously.

The All Wheel Drive (AWD) Control Module detects that the Fused Battery (+) circuit voltage is above 17.0 volts for more than 10 seconds.

With the ignition on.

The All Wheel Drive (AWD) Module has detected a failure internal to the controller.

Scheme 320

1. VERIFY THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read DTCs. Is the DTC active at this time? Yes Go To 2 No Go To 5
2. ALL WHEEL DRIVE (AWD) MODULE INTERNAL FAILURE With the scan tool, check the AWD failure indicator light. Is the AWD failure indicator light active at this time? Yes Go To 3 No Go To 4
3. (T312) REAR DIFFERENTIAL SOLENOID CONTROL CIRCUIT SHORTED TO VOLTAGE Turn the ignition off to the lock position. Disconnect the AWD Control Module harness connector. Measure the voltage of the (T312) Rear Differential Solenoid Control circuit in the AWD Module harness connector. Is there any voltage present? Yes Repair the short to voltage in the (T312) Rear Differential Solenoid Control circuit. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Go To 4
4. ALL WHEEL DRIVE CONTROL MODULE The AWD Control Module has detected an internal failure. Repair Replace the All Wheel Drive (AWD) Control Module in accordance with the Service Information. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) .
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle test the wiring harness and connectors while checking for shorted and open circuits. Using the scan tool, monitor the data related to this circuit while performing the wiggle test. Look for the data to change or for the DTC to reset. Were there any problems found? Yes Repair as necessary. Perform the AWD CONTROL MODULE VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-612764-S24771594392014043000000) . No Test Complete.

Ignition run time is greater than one second. Battery voltage between 10 and 16 volts. Engine run time greater than three seconds.

The circuit is continuously monitored. Two Trip fault.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Powertrain Control Module (ECM/PCM) for approximately two to five seconds.

Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously when the ignition is on.

The battery voltage between 10.0 and 16.0 Volts.

Ignition Off Draw (IOD) fuse installed.

Totally Integrated Power Module (TIPM) is configured correctly.

Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

Continuously with the ignition on, one valid CAN message received at least once, and no U0002-CAN C Bus Off Performance DTC present.

When the AWD Control Module detects an incorrect CAN message from the Power Control Module (PCM).

Continuously with the ignition on, one valid CAN ID received at least once, and no U0002-CAN Bus Off Performance DTC present.

When the TCM detects an incorrect CAN ID from the ABS control module.

Continuously with the ignition on, one valid CAN ID received at least once, and no U0002-CAN Bus Off Performance DTC present.

When the AWD Control Module detects an incorrect CAN ID from the CLUSTER/CCN.

Ignition on.

The AWD does not receive a vehicle speed signal from the Anti-lock brake Module over the CAN C bus.

Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Refer to STANDARD PROCEDURE .

Continuously with the ignition on.

When the All Wheel Drive (AWD) Module detects an incorrect CAN messages from the Engine Control Module (ECM) or the Totally Integrated Power Module (TIPM).
