ENGINE MOUNT Jeep Compass I рестайлинг 2

ENGINE MOUNT

1. Install the engine mount (2) onto the body frame rail. Tighten bolts (1) 75 N.m (55 ft. lbs.).
2. Install the engine mount bracket (2) and tighten bolts (1) finger tight.
3. Install engine mount through bolt (3) and tighten to 88 N.m (65 ft. lbs.). Tighten engine mount bracket bolts (1) to 68 N.m (50 ft. lbs.).
4. Remove the floor jack.
5. Install the windshield reservoir. Refer to «RESERVOIR, WINDSHIELD WASHER, INSTALLATION»(ref-612717-S26745984122014043000000) .
6. Install the engine cover (1).
7. Connect the negative battery cable.

Scheme 550

Scheme 551

1. Disconnect the negative battery cable.
2. Disconnect the piston cooling oil control valve harness connector (1).
3. Using Shift Valve Socket (special tool #10237, Socket, Shift Valve) (1), remove the piston cooling oil control valve.

Scheme 552

1. Replace the O-ring seal.
2. Using the Shift Valve Socket (special tool #10237, Socket, Shift Valve) (1), install the piston cooling oil control valve. Tighten to 20 N.m (177 in. lbs.).
3. Connect the piston cooling oil control valve harness connector.
4. Connect the negative battery cable.
5. Start the engine and check for leaks.

Scheme 553

Scheme 554

1. Disconnect the negative battery cable.
2. Drain the engine oil.
3. Remove the oil filter housing. Refer to «HOUSING, OIL FILTER, REMOVAL»(ref-612696-S19508327412014043000000) .
4. Remove bolts (2) and the oil cooler adapter (1).
5. Remove bolts (1) and the oil cooler (2).

Scheme 555

Scheme 556

1. Clean the sealing surfaces and install new O-ring seals (1) on the back side of adapter.
2. Clean the sealing surfaces and install new O-ring seals (1) on the front side of adapter.
3. Install the oil cooler (1) onto the oil cooler adapter. Tighten bolts (1) to 10 N.m (89 in. lbs.).
4. Install the oil cooler adapter (1) to the engine block. Tighten bolts (2) to 20 N.m (177 in. lbs.).
5. Install the oil filter housing (1). Refer to «HOUSING, OIL FILTER, INSTALLATION»(ref-612696-S18422924302014043000000) .
6. Fill the engine with the recommended oil. Refer to «CAPACITIES AND RECOMMENDED FLUIDS, SPECIFICATIONS»(ref-612692-S36910053762014043000000) .
7. Connect the negative battery cable.
8. Start the engine and check for leaks.

Scheme 557

Scheme 558

Scheme 559

Scheme 560

Scheme 561

Scheme 562

Scheme 563

Scheme 564

Scheme 565

Scheme 566

1. Disconnect the negative battery cable.
2. Remove the engine cover (1).
3. Remove fasteners (2, 4) and the underbody belly pan (3).
4. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
5. Drain the cooling system. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .
6. Disconnect upper radiator hose from radiator.
7. Disconnect lower radiator hose at radiator.
8. Disconnect cooling fan wire harness connector.
9. Disconnect both A/C lines at condenser.
10. Remove A/C condenser to radiator mounting screws and remove condenser.
11. Unclip charge air cooler from radiator.
12. Lift radiator and cooling fan assembly from vehicle.
13. Remove the A/C compressor. Refer to «COMPRESSOR, A/C, INSTALLATION»(ref-612707-S19078228292014043000000) .
14. Remove the generator. Refer to «GENERATOR, REMOVAL»(ref-612723-S29059642482014043000000) .
15. Remove the mixing chamber (3). Refer to «MANIFOLD, INTAKE, REMOVAL»(ref-612696-S09851396902014043000000) .
16. Remove bolts (2) and the EGR vacuum solenoid (1).
17. Remove the bolts (1, 3) and accessory drive belt tensioner (2).
18. Remove bolts (1) and the intake manifold support bracket (2).
19. Release the lock tabs (1) and lift up on wire harness.
20. Remove bolt (1) and wire harness support bracket (2).
21. Disconnect the upper coolant temp sensor wire harness connector (1).
22. Remove the three upper bolts (2).
23. Disconnect the piston cooling oil control valve harness connector (1).
24. Disconnect the coolant temperature sensor (1) wire harness connector.
25. Remove the two bolt (2) securing the thermostat housing.
26. Remove the bolts (1) from the accessory carrier.
27. Disconnect the coolant hose (1) to the oil cooler and remove the accessory carrier.
28. Remove the upper bolts (2).
29. Remove the lower bolts (3) and the oil filter housing (1).
30. Remove and discard the O-ring seals.

Scheme 567

Scheme 568

Scheme 569

1. Install new O-ring seals (2) onto the oil filter housing (1).
2. Install the oil filter housing (1). Tighten the M6 bolts (2) to 10 N.m (89 in. lbs.). Tighten the M8 bolts (3) to 20 N.m (177 in. lbs.).
3. Clean the gasket surfaces and install a new O-ring gasket (1) onto the accessory carrier.
4. Position the accessory carrier to the engine and install bolts finger tight.
5. Connect the coolant hose (1) to the oil cooler and set the lock tab.
6. Tighten the accessory carrier bolts (1) to 20 N.m (177 in. lbs.).
7. Install the two bolt (2) securing the thermostat housing to engine block. Tighten bolts to 9 N.m (80 in. lbs.).
8. Connect the coolant temperature sensor wire harness connector (1).
9. Connect the piston cooling oil control valve wire harness connector (1).
10. Install the three accessory carrier upper bolts (2). Tighten bolts to 9 N.m (80 in. lbs.).
11. Connect the upper coolant temp sensor wire harness connector (1).
12. Install the wire harness support bracket (2). Tighten bolt (1) to 9 N.m (80 in. lbs.).
13. Position the wire harness and push down to lock tabs (1).
14. Install the mixing chamber support bracket (2). Tighten bolts to 9 N.m (80 in. lbs.).
15. Install the accessory drive belt tensioner (2). Tighten M8 bolts (1) to 20 N.m (177 in. lbs.). Tighten M10 bolt (3) to 45 N.m (33 ft. lbs.).
16. Install the EGR vacuum solenoid (1). Tighten bolts (2) to 9 N.m (80 in. lbs.).
17. Install the mixing chamber (3). Refer to «MANIFOLD, INTAKE, INSTALLATION»(ref-612696-S03292169752014043000000) .
18. Install the generator. Refer to «GENERATOR, INSTALLATION»(ref-612723-S15110375682014043000000) .
19. Install the A/C compressor. Refer to «COMPRESSOR, A/C, INSTALLATION»(ref-612707-S19078228292014043000000) .
20. Connect the air inlet hose at intake manifold.
21. Lower the radiator and cooling fan assembly in vehicle. Attach charge air cooler to radiator.
22. Attach the A/C condenser to radiator. Tighten the bolts to 5 N.m (44 in. lbs.).
23. Remove the tape or plug from the condenser ports.
24. Lubricate the new rubber O-ring seal with clean refrigerant oil and install it and a new gasket onto the liquid line fitting. Use only the specified O-ring as it is made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
25. Connect both A/C lines to the condenser. Tighten the nuts to 5 N.m (44 in. lbs.).
26. Connect the cooling fan electrical connector.
27. Connect the lower radiator hose at radiator.
28. Connect the upper radiator hose at radiator.
29. Install the underbody belly pan.
30. Fill the cooling system. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .
31. Fill the engine with recommended engine oil. Refer to «CAPACITIES AND RECOMMENDED FLUIDS, SPECIFICATIONS»(ref-612692-S36910053762014043000000) .
32. Install the engine cover (1).
33. Connect the negative battery cable.
34. Start the engine and check for leaks.

Scheme 570

There are four oil jets (3) installed in the engine block (2). These oil jets are used to cool and lubricate the piston assemblies.
