Interior Fuses
The fuse panel is on the lower instrument panel just to the left of the steering column.
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| 1 | 30 Amp Green | Audio Amp (B+) | |
| 2 | 15 Amp Blue | Sunroof (B+) | |
| 3 | 10 Amp Red | Htd Mirror (EBL) | |
| 4 | 20 Amp Yellow | Rr Pwr Out (B+) | |
| 5 | 10 Amp Red | Rr HVAC (R/O) (XK Only) | |
| 6 | Spare (B+) | ||
| 7 | 20 Amp Yellow | Door Locks (B+) | |
| 8 | 15 Amp Blue | Steer Col Lock (B+) (ELV) | |
| 9 | 20 Amp Yellow | Pwr Outlet (B+) | |
| 10 | 10 Amp Red | Final Drive Control Module (FDCM), Heater Ventilation, Air Conditioning (HVAC), Switch Bank, Transfer Case Switch, O/H, Heater Ventilation, Air Conditioning (HVAC) Relay, Rear Park Assist | |
| 11 | Spare (B+) | ||
| 12 | 10 Amp Red | Door Mods, Mem. Sw, O/H Lamps, IP Courtesy Lamps, Glove Box Lamp (B+) | |
| 13 | 10 Amp Red | Autowipe (R/A) | |
| 14 | 20 Amp Yellow | Cigar Ltr (R/A) | |
| 15 | 10 Amp Red | Tire Pressure Transducers (R/O) | |
| 16 | 10 Amp Red | Steering Control Module (SCM), Diag. Connector, Cluster (B+) | |
| 17 | 15 Amp Blue | Flipper Glass (B+) | |
| 19 | Spare (R/S) | ||
| 20 | 10 Amp Red | Sentry Key Remote Entry Module (SKREEM), Cluster (R/S) | |
| 21 | Spare (Acc Delay) | ||
| 22 | 15 Amp Blue | Rear Wiper (B+) | |
| 24 | 10 Amp Red | Power Distribution Center (PDC) Relays, Final Drive Control Module (FDCM), Front Control Module (FCM) (R/S), A580 (R/S) | |
| 25 | 10 Amp Red | Shifter Assy (BTSI), Trans. Case Switch, ESP/ABS, Brake Supp Rly Coil (R/S) |
INTERIOR FUSES
Underhood Fuses (Power Distribution Center)
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| 1 | 40 Amp Green | HVAC Blower | |
| 2 | 30 Amp Pink | Power Outlets | |
| 3 | 30 Amp Pink | Rr Wiper/Ign R/O | |
| 4 | 30 Amp Pink | ABS Pump | |
| 5 | 50 Amp Red | Cabin Htr 1 (Diesel Only) | |
| 6 | 50 Amp Red | Auto Shut Down (ASD) | |
| 7 | 30 Amp Pink | Rr HVAC (XK Only) | |
| 8 | 40 Amp Green | Acc Delay/Seats | |
| 9 | 40 Amp Green | Pwr Liftgate (XK Only) | |
| 10 | 40 Amp Green | Starter/Junction Block (JB) Power | |
| 11 | 30 Amp Pink | Cig Ltr/T-Tow | |
| 12 | 40 Amp Green | Rear Window Defogger (EBL)/Htd Mirror | |
| 13 | 40 Amp Green | Junction Block (JB) Power | |
| 14 | 50 Amp Red | Cabin Htr 2 (Diesel Only) | |
| 15 | 50 Amp Red | Cabin Htr 3 (Diesel Only) | |
| 16 | 25 Amp Natural | Integrated Power Module (IPM)/Coils | |
| 17 | Spare | ||
| 18 | 20 Amp Yellow | EATX/AC Clutch | |
| 19 | 20 Amp Yellow | Ign Sw | |
| 20 | 20 Amp Yellow | PCM Batt (Gasoline Only) | |
| 21 | 30 Amp Green | ABS Valves | |
| 22 | 20 Amp Yellow | T-Tow (BUX) | |
| 23 | 20 Amp Yellow | Final Drive Control Module (FDCM) | |
| 24 | 20 Amp Yellow | Fuel Pump | |
| 25 | 20 Amp Yellow | Final Drive Control Module (FDCM) | |
| 26 | 15 Amp Blue | Powertrain Control Module (PCM) Auto Shut Down (ASD) (Diesel Only) | |
| 27 | 15 Amp Blue | Brake/Stop Lamps | |
| 28 | 25 Amp Natural | Next Generation Controller (NGC)/Injectors |
UNDERHOOD FUSES (POWER DISTRIBUTION CENTER)
Underhood Fuses (Integrated Power Module)
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|---|---|---|
| 8 | 10 Amp Red | Lt Park Lamps | |
| 9 | 10 Amp Red | Trailer-Tow Park Lamps | |
| 10 | 10 Amp Red | Rt Park Lamps | |
| 12 | 20 Amp Yellow | Front Control Module (FCM) Batt #4 | |
| 13 | 20 Amp Yellow | Front Control Module (FCM) Batt #2 | |
| 14 | 20 Amp Yellow | Adjustable Pedal | |
| 15 | 20 Amp Yellow | Ft Fog Lamps | |
| 16 | 20 Amp Yellow | Horn | |
| 17 | 20 Amp Yellow | Rear Wiper | |
| 18 | 20 Amp Yellow | Front Control Module (FCM) Batt #1 | |
| 19 | 20 Amp Yellow | Lt Trailer-Tow Stop/Turn | |
| 20 | 20 Amp Yellow | Front Control Module (FCM) Batt #3 | |
| 21 | 20 Amp Yellow | Rt Trailer-Tow Stop/Turn | |
| 22 | 30 Amp Pink | Final Drive Control Module (FDCM) MOD | |
| 23 | 50 Amp Red | Radiator Fan | |
| 27 | 15 Amp Blue | Ignition Off Draw (IOD) #1 | |
| 28 | 20 Amp Yellow | Ignition Off Draw (IOD) #2 | |
| 29 | 10 Amp Red | Occupant Restraint Controller (ORC) R/S | |
| 30 | 10 Amp Red | Occupant Restraint Controller (ORC) R/O |
UNDERHOOD FUSES (INTEGRATED POWER MODULE)
Schedule "A"
| Kilometers | 20 000 | 40 000 | 60 000 | 80 000 |
|---|---|---|---|---|
| (Miles) | (12,500) | (25,000) | (37,500) | (50,000) |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air filter element. Replace as necessary. | X | X | ||
| Replace the engine air filter element. | X | X | ||
| Replace the fuel filter/water separator unit. | X | X | ||
| Inspect the brake linings. | X | X | ||
| Drain the transfer case and refill. | X | X |
MAINTENANCE SCHEDULE "A" (1 OF 2)
| Kilometers | 100 000 | 120 000 | 140 000 | 160 000 |
|---|---|---|---|---|
| (Miles) | (62,500) | (75,000) | (87,500) | (100,000) |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air filter element. Replace as necessary. | X | X | ||
| Replace the engine air filter element. | X | X | ||
| Replace the fuel filter/water separator unit. | X | X | ||
| Flush and replace the engine coolant/anti-freeze. | X | |||
| Replace the engine accessory drive belt. | X | |||
| Inspect the brake linings. | X | X | ||
| Drain the transfer case and refill. | X | X |
MAINTENANCE SCHEDULE "A" (2 OF 2)
Inspection and service should be performed anytime a malfunction is observed or suspected. Retain all receipts. <-- The replacement of such component is requested when there is superficial wear, bearing clearance, or evident grease leak.
Schedule "B"
Follow schedule "B" if you usually operate your vehicle under one or more of the following conditions.
- Day or night temperatures are below 0°C (32°F).
- Stop and go driving.
- Extensive engine idling.
- Driving in dusty conditions.
- Short trips of less than 16.2 km (10 miles).
- More than 50% of your driving is at sustained high speeds during hot weather, above 32°C (90°F).
- Trailer towing.
- Taxi, police, or delivery service (commercial service).
- Off-road or desert driving.
| Kilometers | 10 000 | 20 000 | 30 000 | 40 000 | 50 000 |
|---|---|---|---|---|---|
| (Miles) | (6,250) | (12,500) | (18,750) | (25,000) | (31,250) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Inspect the engine air filter element. Replace as necessary. | X | X | X | ||
| Replace the engine air filter element. | X | X | |||
| Replace the fuel filter/water separator unit. | X | ||||
| Inspect the brake linings. | X | X | |||
| Drain the transfer case and refill. | X | ||||
| Drain and refill the front and rear axles. | X | X |
MAINTENANCE SCHEDULE "B" (1 OF 3)
| Kilometers | 60 000 | 70 000 | 80 000 | 90 000 | 100 000 |
|---|---|---|---|---|---|
| (Miles) | (37,500) | (43,750) | (50,000) | (56,250) | (62,500) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Inspect the engine air filter element. Replace as necessary. | X | X | |||
| Replace the engine air filter element. | X | X | X | ||
| Replace the fuel filter/water separator unit. | X | ||||
| Replace the engine accessory drive belt. | X | ||||
| Inspect the brake linings. | X | X | X | ||
| Drain and refill the front and rear axles. | X | X | X | ||
| Drain and refill the transmission fluid, and change the filter. | X | ||||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULE "B" (2 OF 3)
| Kilometers | 110 000 | 120 000 | 130 000 | 140 000 | 150 000 | 160 000 |
|---|---|---|---|---|---|---|
| (Miles) | (68,750) | (75,000) | (81,250) | (87,500) | (93,750) | (100,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X | X |
| Rotate the tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | X |
| Inspect the engine air filter element. Replace as necessary. | X | X | X | |||
| Replace the engine air filter element. | X | X | X | |||
| Replace the engine accessory drive belt. | X | |||||
| Replace the fuel filter/water separator unit. | X | X | ||||
| Flush and replace the engine coolant/anti-freeze. | X | |||||
| Inspect the brake linings. | X | X | ||||
| Drain the transfer case and refill. | X | |||||
| Drain and refill the front and rear axles. | X | X |
MAINTENANCE SCHEDULE "B" (3 OF 3)
<-- Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.
! The replacement of such component is requested when there is superficial wear, bearing clearance, or evident grease leak.
Inspection and service should be performed anytime a malfunction is observed or suspected. Retain all receipts.
| Miles | 3,000 | 6,000 | 9,000 | 12,000 | 15,000 |
|---|---|---|---|---|---|
| (Kilometers) | (5 000) | (10 000) | (15 000) | (20 000) | (25 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X |
MAINTENANCE SCHEDULES "B" (1 OF 10)
| Miles | 18,000 | 21,000 | 24,000 | 27,000 | 30,000 |
|---|---|---|---|---|---|
| (Kilometers) | (30 000) | (35 000) | (40 000) | (45 000) | (50 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "B" (2 OF 10)
| Miles | 33,000 | 36,000 | 39,000 | 42,000 | 45,000 |
|---|---|---|---|---|---|
| (Kilometers) | (55 000) | (60 000) | (65 000) | (70 000) | (75 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X |
MAINTENANCE SCHEDULES "B" (3 OF 10)
| Miles | 48,000 | 51,000 | 54,000 | 57,000 | 60,000 |
|---|---|---|---|---|---|
| (Kilometers) | (80 000) | (85 000) | (90 000) | (95 000) | (100 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | X | |||
| Drain and refill the front and rear axles. | X | ||||
| Drain and refill the automatic transmission fluid, and replace main sump filter and cooler return filter (if equipped) (3.7L/4.7L/5.7L). | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Flush and replace engine coolant/anti-freeze. | X |
MAINTENANCE SCHEDULES "B" (4 OF 10)
| Miles | 63,000 | 66,000 | 69,000 | 72,000 | 75,000 |
|---|---|---|---|---|---|
| (Kilometers) | (105 000) | (110 000) | (115 000) | (120 000) | (125 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axle fluid. | X |
MAINTENANCE SCHEDULES "B" (5 OF 10)
| Miles | 78,000 | 81,000 | 84,000 | 87,000 | 90,000 |
|---|---|---|---|---|---|
| (Kilometers) | (130 000) | (135 000) | (140 000) | (145 000) | (150 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axle fluid. | X |
MAINTENANCE SCHEDULES "B" (6 OF 10)
| Miles | 93,000 | 96,000 | 99,000 | 102,000 | 105,000 |
|---|---|---|---|---|---|
| (Kilometers) | (155 000) | (160 000) | (165 000) | (170 000) | (175 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axle fluid. | X | ||||
| Flush and replace the engine coolant/anti-freeze, if not done at 60 months. | X |
MAINTENANCE SCHEDULES "B" (7 OF 10)
| Miles | 108,000 | 111,000 | 114,000 | 117,000 | 120,000 |
|---|---|---|---|---|---|
| (Kilometers) | (180 000) | (185 000) | (190 000) | (195 000) | (200 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Inspect the brake linings. | X | X | |||
| Drain and refill the front and rear axle fluid. | X | ||||
| Drain and refill the automatic transmission fluid, and replace main sump filter and cooler return filter (if equipped) (3.7L/4.7L/5.7L). | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Flush and replace the engine coolant/anti-freeze, if not replaced at 102,000 miles (170 000 km). | X |
MAINTENANCE SCHEDULES "B" (8 OF 10)
| Miles | 123,000 | 126,000 | 129,000 | 132,000 | 135,000 |
|---|---|---|---|---|---|
| (Kilometers) | (205 000) | (210 000) | (215 000) | (220 000) | (225 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axle fluid. | X |
MAINTENANCE SCHEDULES "B" (9 OF 10)
| Miles | 138,000 | 141,000 | 144,000 | 147,000 | 150,000 |
|---|---|---|---|---|---|
| (Kilometers) | (230 000) | (235 000) | (240 000) | (245 000) | (250 000) |
| Change the engine oil and engine oil filter, if not replaced at 3 months. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the engine accessory drive belt, replace if necessary.* | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axle fluid. | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Flush and replace the engine coolant/anti-freeze, if not replaced at 120,000 miles (200 000 km). | X |
MAINTENANCE SCHEDULES "B" (10 OF 10)
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.
* This maintenance is not required if the belt was previously replaced.
| Miles | 6,000 | 12,000 | 18,000 | 24,000 | 30,000 |
|---|---|---|---|---|---|
| (Kilometers) | (10 000) | (20 000) | (30 000) | (40 000) | (50 000) |
| [Months] | [6] | [12] | [18] | [24] | [30] |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (1 OF 6)
| Miles | 36,000 | 42,000 | 48,000 | 54, 000 |
|---|---|---|---|---|
| (Kilometers) | (60 000) | (70 000) | (80 000) | (90 000) |
| [Months] | [36] | [42] | [48] | [54] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the brake linings. | X | X |
MAINTENANCE SCHEDULES "A" (2 OF 6)
| Miles | 60,000 | 66,000 | 72,000 | 78,000 |
|---|---|---|---|---|
| (Kilometers) | (100 000) | (110 000) | (120 000) | (130 000) |
| [Months] | [60] | [66] | [72] | [78] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the engine accessory drive belt, replace if necessary. | X | |||
| Flush and replace the engine coolant/anti-freeze. | X | |||
| Inspect the brake linings. | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (3 OF 6)
| Miles | 84,000 | 90,000 | 96,000 | 102, 000 |
|---|---|---|---|---|
| (Kilometers) | (140 000) | (150 000) | (160 000) | (170 000) |
| [Months] | [84] | [90] | [96] | [102] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the engine accessory drive belt, replace if necessary.* | X | |||
| Inspect the brake linings. | X | |||
| Flush and replace the engine coolant/anti-freeze if not replaced at 60 months. | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (4 OF 6)
| Miles | 108,000 | 114,000 | 120,000 | 126,000 |
|---|---|---|---|---|
| (Kilometers) | (180 000) | (190 000) | (200 000) | (210 000) |
| [Months] | [108] | [114] | [120] | [126] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the engine accessory drive belt, replace if necessary.* | X | |||
| Inspect the brake linings. | X | X | ||
| Flush and replace the engine coolant/anti-freeze if not done at 102,000 miles (170 000 km). | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (5 OF 6)
| Miles | 132,000 | 138,000 | 144,000 | 150,000 |
|---|---|---|---|---|
| (Kilometers) | (220 000) | (230 000) | (240 000) | (250 000) |
| [Months] | [132] | [138] | [144] | [150] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the engine accessory drive belt, replace if necessary.* | X | |||
| Inspect the brake linings. | X | |||
| Flush and replace the engine coolant/anti-freeze if not done at 120,000 miles (200 000 km). | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (6 OF 6)
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.
* This maintenance is not required if the belt was previously replaced.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
| Kilometers | 12 000 | 24 000 | 36 000 | 48 000 | 60 000 |
|---|---|---|---|---|---|
| (Miles) | (7,500) | (15,000) | (22,500) | (30,000) | (37,500) |
| [Months] | [6] | [12] | [18] | [24] | [30] |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct storage. | X | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (1 OF 4)
| Kilometers | 72 000 | 84 000 | 96 000 | 108 000 |
|---|---|---|---|---|
| (Miles) | (45,000) | (52,500) | (60,000) | (67,500) |
| [Months] | [36] | [42] | [48] | [54] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct storage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the drive belt, replace if necessary. | X | |||
| Inspect the brake linings. | X | X | ||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (2 OF 4)
| Kilometers | 120 000 | 132 000 | 144 000 | 156 000 |
|---|---|---|---|---|
| (Miles) | (75,000) | (82,500) | (90,000) | (97,500) |
| [Months] | [60] | [66] | [72] | [78] |
| Change the engine oil and engine oil filter. | X | X | X | X |
| Rotate the tires. | X | X | X | X |
| Check spare tire for proper pressure and correct storage. | X | X | X | X |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | X | ||
| Replace the spark plugs. | X | X | ||
| Inspect the drive belt, replace if necessary. | X | |||
| Flush and replace the engine coolant/anti-freeze. | X | |||
| Inspect the brake linings. | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (3 OF 4)
| Kilometers | 160 000 | 168 000 | 180 000 | 192 000 |
|---|---|---|---|---|
| (Miles) | (100,000) | (105,000) | (112,500) | (120,000) |
| [Months] | [84] | [90] | [96] | |
| Change the engine oil and engine oil filter. | X | X | X | |
| Rotate the tires. | X | X | X | |
| Check spare tire for proper pressure and correct storage. | X | X | X | |
| Inspect the engine air cleaner filter, and replace if necessary. | X | |||
| Inspect the PCV Valve, replace if necessary.< | X | |||
| Replace the spark plugs. | X | |||
| Inspect the drive belt, replace if necessary. | X | |||
| Inspect the brake linings. | X | |||
| Flush and replace the engine coolant/anti-freeze if not replaced at 60 months. | X | |||
| Flush and replace the engine coolant/anti-freeze if not replaced at 160 000 km (100,000 miles). | X | |||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "A" (4 OF 4)
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.
Follow this schedule if you usually operate your vehicle under one or more of the following conditions.
- Day or night temperatures are below 32°F (0°C)
- Stop and go driving
- Excessive engine idling
- Driving in dusty conditions
- Short trips of less than 10 miles (16.2 km)
- More than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C)
- Trailer towing
- Taxi, police, or delivery service (commercial service)
- Off-road or desert driving
- If equipped for and operated with E-85 (ethanol) fuel.
| Kilometers | 5 000 | 10 000 | 14 000 | 19 000 | 24 000 |
|---|---|---|---|---|---|
| (Miles) | (3,000) | (6,000) | (9,000) | (12,000) | (15,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct storage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X |
MAINTENANCE SCHEDULES "B" (1 OF 8)
| Kilometers | 29 000 | 34 000 | 38 000 | 43 000 | 48 000 |
|---|---|---|---|---|---|
| (Miles) | (18,000) | (21,000) | (24,000) | (27,000) | (30,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct storage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain the transfer case and refill. | X |
MAINTENANCE SCHEDULES "B" (2 OF 8)
| Kilometers | 53 000 | 58 000 | 62 000 | 67 000 | 72 000 |
|---|---|---|---|---|---|
| (Miles) | (33,000) | (36,000) | (39,000) | (42,000) | (45,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct storage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Inspect the brake linings. | X |
MAINTENANCE SCHEDULES "B" (3 OF 8)
| Kilometers | 77 000 | 82 000 | 86 000 | 91 000 | 96 000 |
|---|---|---|---|---|---|
| (Miles) | (48,000) | (51,000) | (54,000) | (57,000) | (60,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct storage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | X | |||
| Drain and refill the front and rear axles. | X | ||||
| Drain and refill the automatic transmission fluid, and replace main sump filter (4.7L/5.7L Only). | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Flush and replace engine coolant/anti-freeze at 60 months, if not done at 102,000 miles (163 000 km). | X |
MAINTENANCE SCHEDULES "B" (4 OF 8)
Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.
| Kilometers | 101 000 | 106 000 | 110 000 | 115 000 | 120 000 |
|---|---|---|---|---|---|
| (Miles) | (63,000) | (66,000) | (69,000) | (72,000) | (75,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct storage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axles. | X |
MAINTENANCE SCHEDULES "B" (5 OF 8)
| Kilometers | 125 000 | 130 000 | 134 000 | 139 000 | 144 000 |
|---|---|---|---|---|---|
| (Miles) | (78,000) | (81,000) | (84,000) | (87,000) | (90,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct storage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the drive belt, replace if necessary. | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axles. | X |
MAINTENANCE SCHEDULES "B" (6 OF 8)
| Kilometers | 149 000 | 154 000 | 158 000 | 163 000 | 168 000 |
|---|---|---|---|---|---|
| (Miles) | (93,000) | (96,000) | (99,000) | (102,000) | (105,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | |||
| Check spare tire for proper pressure and correct storage. | X | X | |||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | ||||
| Drain and refill the front and rear axles. | X | ||||
| Flush and replace the engine coolant/anti-freeze, if not done at 60 months. | X |
MAINTENANCE SCHEDULES "B" (7 OF 8)
| Kilometers | 173 000 | 178 000 | 182 000 | 187 000 | 192 000 |
|---|---|---|---|---|---|
| (Miles) | (108,000) | (111,000) | (114,000) | (117,000) | (120,000) |
| Change the engine oil and engine oil filter. | X | X | X | X | X |
| Rotate the tires. | X | X | X | ||
| Check spare tire for proper pressure and correct storage. | X | X | X | ||
| Inspect the engine air cleaner filter, replace if necessary. | X | ||||
| Inspect the PCV Valve, replace if necessary.< | X | ||||
| Replace the spark plugs. | X | ||||
| Inspect the drive belt, replace if necessary. | X | ||||
| Inspect the brake linings. | X | X | |||
| Drain and refill the front and rear axles. | X | ||||
| Drain and refill the automatic transmission fluid, replace main sump filter, and spin-on cooler return filter (if equipped). (4.7L/5.7L Only). | X | ||||
| Drain and refill the transfer case fluid. | X | ||||
| Flush and replace the engine coolant/anti-freeze at 120 months, if not replaced at 102,000 miles (163 000 km). | X |
MAINTENANCE SCHEDULES "B" (8 OF 8)
Note. Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
Common Towing Definitions
The following trailer towing related definitions will assist you in understanding the following information
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, cargo and tongue weight. The total load must be limited so that you do not exceed the GVWR.
Gross Trailer Weight (GTW)
The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its "loaded and ready for operation" condition. The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be supported by the scale.
Gross Combination Weight Rating (GCWR)
The gross combination weight rating (GCWR) is the total permissible weight of your vehicle and trailer when weighed in combination. (Note that GCWR ratings include a 150 lbs (68 kg) allowance for the presence of a driver).
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
| WARNING | It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. |
Tongue Weight (TW)
The downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle.
Frontal Area
The maximum height and maximum width of the front of a trailer.
Trailer Sway Control
The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Weight-Carrying Hitch
A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or some other connecting point of the vehicle. These kind of hitches are the most popular on the market today and they're commonly used to tow small- and medium-sized trailers.
Weight-Distributing Hitch
A weight-distributing system works by applying leverage through spring (load) bars. They are typically used for heavier loads, to distribute trailer tongue weight to the tow vehicle's front axle and the trailer axle(s). When used in accordance with the manufacturers' directions, it provides for a more level ride, offering more consistent steering and brake control thereby enhancing towing safety. The addition of a friction/hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier Tongue Weights (TW) and may be required depending on Vehicle and Trailer configuration/loading to comply with gross axle weight rating (GAWR) requirements.
| WARNING | An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking performance, and could result in an accident. Weight Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional information. |
Scheme 9
Scheme 10
Trailer Hitch Classification
Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your dealer for package content.
The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Refer to the TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) table for the Max. GTW towable for your given drivetrain.
| Class | Max. GTW (Gross Trailer Wt.) |
|---|---|
| Class I - Light Duty | 2,000 lbs (907 kg) |
| Class II - Medium Duty | 3,500 lbs (1587 kg) |
| Class III - Heavy Duty | 5,000 lbs (2268 kg) |
| Class IV - Extra Heavy Duty | 10,000 lbs (4540 kg) |
TRAILER HITCH CLASSIFICATION
All trailer hitches should be professionally installed on your vehicle.
Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
| Engine/Transmission | Model | GCWR (Gross Combined Wt. Rating) | Frontal Area | Max. GTW (Gross Trailer Wt.) | Max. Tongue Wt. (See Note at end of table) |
|---|---|---|---|---|---|
| 3.7L/Automatic | 4x2 | 8,670 lbs (3 933 kg) | 40 Sq. Ft (3.72 square meters) | 3,500 lbs (1 587 kg) | 350 lbs (159 kg) |
| 3.7L/Automatic | 4x4 | 8,755 lbs (3 971 kg) | 40 Sq. Ft (3.72 square meters) | 3,500 lbs (1 587 kg) | 350 lbs (159 kg) |
| 4.7L/Automatic | 4x2 | 11,665 lbs (5 291 kg) | 60 Sq. Ft (5.57 square meters) | 6,500 lbs (2 948 kg) | 650 lbs (295 kg) |
| 4.7L/Automatic | 4x4 | 11,800 lbs (5 352 kg) | 60 Sq. Ft (5.57 square meters) | 6,500 lbs (2 948 kg) | 650 lbs (295 kg) |
| 5.7L/Automatic | 4x2 | 12,470 lbs (5 656 kg) | 60 Sq. Ft (5.57 square meters) | 7,200 lbs (3 266 kg) | 720 lbs (327 kg) |
| 5.7L/Automatic | 4x4 | 12,620 lbs (5 724 kg) | 60 Sq. Ft (5.57 square meters) | 7,200 lbs (3 266 kg) | 720 lbs (327 kg) |
| Refer to local laws for maximum trailer towing speeds. | |||||
TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS)
Note. The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to the Tire-Safety Information in TIRES/WHEELS - SERVICE INFORMATION article and VEHICLE DATA article.
Note. For proper tire pressure specification, refer to the tire label placard usually located on the drivers door latch pillar.
Trailer and Tongue Weight
Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely side to side which will cause loss of control of the vehicle and trailer. Failure to load trailers heavier in front is the cause of many trailer accidents.
Never exceed the maximum tongue weight stamped on your bumper or trailer hitch.
Scheme 11
Consider the following items when computing the weight on the rear axle of the vehicle
- The tongue weight of the trailer.
- The weight of any other type of cargo or equipment put in or on your vehicle.
- The weight of the driver and all passengers.
Note. Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard for the maximum combined weight of occupants and cargo for your vehicle. Refer to TIRES/WHEELS - SERVICE INFORMATION article and VEHICLE DATA article.
Note. For proper tire pressure specification, refer to the tire label placard usually located on the drivers door latch pillar.
Towing Requirements
To promote proper break-in of your new vehicle drivetrain components the following guidelines are recommended
| CAUTION | Avoid towing a trailer for the first 500 miles (805 km) of vehicle operation. Doing so may damage your vehicle. During the first 500 miles (805 km) of trailer towing, limit your speed to 50 mph (80 km/h). |
Perform the maintenance listed in LUBRICATION & MAINTENANCE article. When towing a trailer, never exceed the GAWR, or GCWR, ratings.
| WARNING | Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control. You could lose control of your vehicle and have an accident. |
- When hauling cargo or towing a trailer, do not overload your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to brakes, axle, engine, transmission, steering, suspension, chassis structure or tires.
- Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners.
- Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the tow vehicle. Put the tow vehicle automatic transmission in P for Park. Always, block or "chock" the trailer wheels.
- GCWR must not be exceeded.
- Total weight must be distributed between the tow vehicle and the trailer such that the following four ratings are not exceeded: GVWR GTW GAWR Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight).
Towing Requirements - Tires
- Do not attempt to tow a trailer while using a compact spare tire.
- Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle.
- Also, check the trailer tires for proper tire inflation pressures before trailer usage.
- Check for signs of tire wear or visible tire damage before towing a trailer. Refer to «DESCRIPTION»(ref-288223-S08396693852008062000000) on Tread Wear Indicators for the proper inspection procedure.
- When replacing tires, refer to «DESCRIPTION»(ref-288223-S08396693852008062000000) on Replacement Tires for proper tire replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle's GVWR and GAWR limits.
Towing Requirements - Trailer Brakes
- Do not interconnect the hydraulic brake system or vacuum system of your vehicle with that of the trailer. This could cause inadequate braking and possible personal injury.
- An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required.
- Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
| CAUTION | If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances. |
| WARNING | Do not connect trailer brakes to your vehicle's hydraulic brake lines. It can overload your brake system and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping distance. When towing you should allow for additional space between your vehicle and the vehicle in front of you. Failure to do so could result in an accident. |
Towing Tips
Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic.
Towing Tips - Automatic Transmission
The "D" range can be selected when towing. However, if frequent shifting occurs while in this range, the "3" range should be selected.
Using the "3" range while operating the vehicle under heavy operating conditions will improve performance and extend transmission life by reducing excessive shifting and heat build up. This action will also provide better engine braking.
The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. See Schedule "B" in LUBRICATION & MAINTENANCE article for transmission fluid change intervals.
Note. Check the automatic transmission fluid level before towing.
Towing Tips - Electronic Speed Control (If Equipped)
- Don't use in hilly terrain or with heavy loads.
- When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.
- Use speed control in flat terrain and with light loads to maximize fuel efficiency.
Towing Tips - Cooling System
To reduce potential for engine and transmission overheating, take the following actions
- City Driving - When stopped for short periods of time, put transmission in neutral and increase engine idle speed.
- Highway Driving - Reduce speed.
- Air Conditioning - Turn off temporarily.
- Refer to Cooling System «OPERATION»(ref-288235-S00622671902008062000000) for more information.
