Power Mirrors - Electrical Diagnostics: Diagnosis Jeep Commander I

Mirrors 3 illustrations ~681 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1D04MIRROR ADJUST SWITCH INPUT CIRCUIT PERFORMANCE - DDM
B1D07MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK - DDM
B1D09 (DDM), B1D12 (PDM)MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT LOW
B1D0A (DDM), B1D13 (PDM)MIRROR POSITION SENSOR POWER SUPPLY CIRCUIT HIGH
B1D0C (DDM), B1D15 (PDM)MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT LOW
B1D0D (DDM), B1D16 (PDM)MIRROR VERTICAL POSITION SENSOR INPUT CIRCUIT HIGH
B1D0F (DDM), B1D18 (PDM)MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT LOW
B1D10 (DDM), B1D19 (PDM)MIRROR HORIZONTAL POSITION SENSOR INPUT CIRCUIT HIGH
B1D1B (DDM), B1D27 (PDM)MIRROR MOTOR COMMON CONTROL CIRCUIT LOW
B1D1C (DDM), B1D28 (PDM)MIRROR MOTOR COMMON CONTROL CIRCUIT HIGH
B1D1F (DDM), B1D2B (PDM)MIRROR VERTICAL MOTOR CONTROL CIRCUIT LOW
B1D20 (DDM), B1D2C (PDM)MIRROR VERTICAL MOTOR CONTROL CIRCUIT HIGH
B1D23, B1D2FMIRROR HORIZONTAL MOTOR CONTROL CIRCUIT LOW - MMM
B1D24 (DDM), B1D30 (PDM)MIRROR HORIZONTAL MOTOR CONTROL CIRCUIT HIGH
B1D33 (DDM), B1D37 (PDM)MIRROR HEATER CONTROL CIRCUIT LOW
B1D35 (DDM), B1D39 (PDM)MIRROR HEATER CONTROL CIRCUIT OPEN
B1D4CMEMORY SWITCH INPUT CIRCUIT HIGH - DDM
B1D4DMEMORY SWITCH INPUT CIRCUIT STUCK - DDM
B1D53SWITCH POWER SUPPLY CIRCUIT LOW - DRIVER MMM
B1DA7SWITCH POWER SUPPLY CIRCUIT LOW - PASSENGER MMM
B210DBATTERY VOLTAGE LOW - DDM - PDM
B210EBATTERY VOLTAGE HIGH - DDM - PDM
B2218DOOR MODULE INTERNAL - DDM
B2219DOOR MODULE INTERNAL - PDM
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0159LOST COMMUNICATION WITH PARKING ASSIST CONTROL MODULE
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0167LOST COMMUNICATION WITH INTRUSION TRANSCEIVER CONTROL MODULE
U0168LOST COM WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0169LOST COMMUNICATION WITH SUNROOF CONTROL MODULE
U0184LOST COMMUNICATION WITH RADIO
U0186LOST COMMUNICATION WITH AUDIO AMPLIFIER
U0195LOST COMMUNICATION WITH SDARS
U0196LOST COMMUNICATION WITH VEHICLE ENTERTAINMENT CONTROL MODULE
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE
U0199LOST COMMUNICATION WITH DRIVER DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE
U0208LOST COMMUNICATION WITH HEATED SEAT CONTROL MODULE
U0209LOST COMMUNICATION WITH MEMORY SEAT CONTROL MODULE
U0212LOST COMMUNICATION WITH SCCM - CAN-B
U0231LOST COMMUNICATION WITH RAIN SENSING MODULE
U0241LOST COMMUNICATION WITH AUTO HIGHBEAM HEADLAMP CONTROL MODULE
U1000CAN B BUS(+) CIRCUIT - DDM - PDM
U1001CAN B BUS(-) CIRCUIT - DDM - PDM

DIAGNOSTIC CODE INDEX

Scheme 1

Scheme 1: Circuit Schematic
Scheme 1: Circuit Schematic

Diagnostic Test

  1. 1) VERIFY IF DTC B1D04 MIRROR ADJUST SWITCH INPUT CIRCUIT/PERFORMANCE IS ACTIVE Turn the ignition on. With the scan tool, record and erase DTCs. Press the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display: B1D04 MIRROR ADJUST SWITCH INPUT CIRCUIT/PERFORMANCE? Yes Diagnose and repair the DTC. Refer to «DIAGNOSTIC CODE INDEX»(ref-288257-S22744555172008062000000) table for a complete list of Power Mirror System DTCs. No Go to 2) .
  2. 2) TEST THE MIRROR SWITCH Turn the ignition off. Remove the Mirror Switch in accordance with the Service Information. Disconnect the Mirror Switch connector. Test the Mirror Switch in all positions in accordance with the Service information. Refer to «DIAGNOSIS AND TESTING»(/jeep/commander/i-2005-2010/remont/mirrors/#power-mirrors-service-information) . Does the switch pass the test in all positions? Yes Go to 3) . No Replace the Mirror Switch in accordance with the Service information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
  3. 3) VERIFY THAT DTC B1D07 MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK IS STILL ACTIVE Turn the ignition off. Reconnect the Mirror Switch connector. Reinstall the Mirror Switch in accordance with the Service Information. Turn the ignition on. With the scan tool, erase DTCs. Press the Mirror Switch in all directions several times. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display: B1D07 MIRROR ADJUST SWITCH INPUT CIRCUIT STUCK? Yes Replace the Driver Door Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. If the conditions returns, replace the switch. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .

Scheme 2

Scheme 2: Circuit Schematic
Scheme 2: Circuit Schematic
  1. 1) REPLACE THE DRIVER MEMORY MIRROR MODULE Repair Replace the Driver Memory Mirror Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
  1. 1) REPLACE THE PASSENGER MEMORY MIRROR MODULE Repair Replace the Passenger Memory Mirror Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .

Scheme 3

Scheme 3: Circuit Schematic
Scheme 3: Circuit Schematic
  1. 1) CHECK FOR ENGINE DTCs Turn the ignition on. With the scan tool, read engine DTCs. Does the scan tool display any BATTERY VOLTAGE HIGH related DTCs? Yes Diagnose and repair the DTC(s). Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article for the diagnostic test procedure(s). No If DTC B210E BATTERY VOLTAGE HIGH set in the Driver Door Module (DDM), Go to 2) . If DTC B210E BATTERY VOLTAGE HIGH set in the Passenger Door Module (PDM), Go to 3) .
  2. 2) TEST FOR INTERMITTENT CONDITION - DDM With the scan tool, erase DTCs Start the engine and run for 2 minutes. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read Driver Door Module (DDM) DTCs. Does the scan tool display: B210E-BATTERY VOLTAGE HIGH? Yes Replace the Driver Door Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) . No The conditions that caused this code to set are not present at this time. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
  3. 3) TEST FOR INTERMITTENT CONDITION - PDM With the scan tool, erase DTCs Start the engine and run for 2 minutes. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read Passenger Door Module (PDM) DTCs. Does the scan tool display: B210E-BATTERY VOLTAGE HIGH? Yes Replace the Passenger Door Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) . No The conditions that caused this code to set are not present at this time. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
  1. 1) REPLACE THE DRIVER DOOR MODULE Repair Replace the Driver Door Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
  1. 1) REPLACE THE PASSENGER DOOR MODULE Repair Replace the Passenger Door Module in accordance with the Service Information. Perform «BODY VERIFICATION TEST»(ref-288232-S30638820392008062000000) .
