3.7L Engine - Service Information: Application Jeep Commander I

Mechanical 15 illustrations ~1071 words

SEALER APPLICATION

Mopar® Gasket Maker material should be applied sparingly 1 mm (0.040 in.) diameter or less of sealant to one gasket surface. Be certain the material surrounds each mounting hole. Excess material can easily be wiped off. Components should be torqued in place within 15 minutes. The use of a locating dowel is recommended during assembly to prevent smearing material off the location.

Mopar® Engine RTV GEN II or ATF RTV gasket material should be applied in a continuous bead approximately 3 mm (0.120 in.) in diameter. All mounting holes must be circled. For corner sealing and "T" joint locations, a 3.17 or 6.35 mm (1/8 or 1/4 in.) drop is placed in the center of the gasket contact area. Uncured sealant may be removed with a shop towel. Components should be torqued in place while the sealant is still wet to the touch (within 10 minutes). The usage of a locating dowel is recommended during assembly to prevent smearing material off the location.

Scheme 52

Scheme 52: 3.7L ENGINE
Scheme 52: 3.7L ENGINE

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63
  1. Release fuel rail pressure then disconnect the fuel supply quick connect fitting at the fuel rail. Refer to «STANDARD PROCEDURE»(ref-288225-S42279264532008062000000) and «STANDARD PROCEDURE»(ref-288225-S01749820952008062000000) .
  2. Remove the strut tower support (1).
  3. Disconnect the battery negative cable.
  4. Remove air cleaner assembly.
  5. Remove fan shroud with viscous fan assembly.
  6. Remove drive belt.
  7. Remove A/C compressor (2) and secure away from engine.
  8. Remove generator (3) and secure away from engine. NOTE: Do NOT remove the phenolic pulley from the P/S pump. It is not required for P/S pump removal.
  9. Remove power steering pump with lines attached and secure away from engine.
  10. Drain cooling system.
  11. Disconnect the heater hoses from the engine.
  12. Disconnect heater hoses from heater core and remove hose assembly.
  13. Remove upper radiator hose from engine.
  14. Remove lower radiator hose from engine.
  15. Remove radiator/cooling module assembly.
  16. Disconnect the engine to body ground straps at the left side of cowl. 1 - THROTTLE BODY 2 - TPS 3 - IAC MOTOR 4 - IAT SENSOR (THREADED TYPE) 5 - MOUNTING SCREWS
  17. Disconnect the engine wiring harness at the following points: Intake air temperature (IAT) sensor (4) Fuel Injectors Throttle Body (2) Idle Air Control (IAC) Motor (3) Engine Oil Pressure Switch Engine Coolant Temperature (ECT) Sensor Manifold Absolute Pressure MAP) Sensor Camshaft Position (CMP) Sensor Coil Over Plugs Crankshaft Position Sensor
  18. Remove coil over plugs.
  19. Remove fuel rail and secure away from engine. NOTE: It is not necessary to release the quick connect fitting from the fuel supply line for engine removal.
  20. Remove the PCV hose.
  21. Remove the breather hoses.
  22. Remove the vacuum hose for the power brake booster.
  23. Disconnect knock sensors.
  24. Remove engine oil dipstick tube.
  25. Remove the intake manifold. See «REMOVAL»(ref-288233-S36083521932008062000000) .
  26. Install Engine Lifting Fixture 8427 using original fasteners from the removed intake manifold, and fuel rail. Torque to factory specifications. NOTE: Recheck bolt torque on the Engine Lift Fixture before removing engine.
  27. Disconnect oxygen sensor wiring.
  28. Disconnect crankshaft position sensor.
  29. Disconnect the engine block heater power cable, if equipped.
  30. Disconnect the front propshaft at the front differential and secure out of way. NOTE: It is necessary to disconnect the front propshaft for access to the starter and left side exhaust flange.
  31. Remove the starter (4).
  32. Remove the ground straps from the left (2) and right (3) side of the block.
  33. Remove the structural cover.
  34. Disconnect the right and left exhaust pipes at the manifolds and from the crossover, and remove from the vehicle. NOTE: The exhaust clamps at the manifolds cannot be reused. New clamps must be used or leaks may occur. 1 - TRANSMISSION 2 - DRIVEPLATE 3 - TORQUE CONVERTER BOLTS
  35. Remove torque convertor bolts (3), and mark location for reassembly.
  36. Remove transmission bellhousing to engine bolts (3).
  37. Remove left and right engine mount thru bolts (3).
  38. Lower the vehicle.
  39. Support the transmission with a suitable jack.
  40. Connect a suitable engine hoist to the Engine Lifting Fixture 8427.
  41. Remove engine from vehicle.

Scheme 64

Scheme 64: 3.7L ENGINE
Scheme 64: 3.7L ENGINE
1 - ENGINE
2 - TRANSMISSION
3 - BOLTS
4 - WIRING HARNESS CLIPS

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66
  1. Position the engine in the vehicle.
  2. Install the transmission bellhousing to engine mounting bolts (3). Tighten the bolts to 41 N.m (30 ft. lbs.)
  3. Install the engine mount thru bolts (3). 1 - TRANSMISSION 2 - DRIVEPLATE 3 - TORQUE CONVERTER BOLTS
  4. Install the torque convertor bolts (3).
  5. Install the starter (4).
  6. Connect the crankshaft position sensor.
  7. Install the engine block heater power cable, if equipped. CAUTION: The structural cover requires a specific torque sequence. Failure to follow this sequence may cause severe damage to the cover.
  8. Install the structural cover. NOTE: New clamps must be used on exhaust manifold flanges. Failure to use new clamps may result in exhaust leaks.
  9. Install the left and right exhaust pipes.
  10. Connect the left and right oxygen sensors.
  11. Remove the engine lift plate.
  12. Connect the knock sensors.
  13. Connect the engine to body ground straps at the left side of the cowl.
  14. Install the intake manifold using the sequence provided.
  15. Install the engine oil dipstick tube.
  16. Install the power brake booster vacuum hose.
  17. Install the breather hoses.
  18. Install the PCV hose.
  19. Install the fuel rail.
  20. Install the coil over plugs. 1 - THROTTLE BODY 2 - TPS 3 - IAC MOTOR 4 - IAT SENSOR (THREADED TYPE) 5 - MOUNTING SCREWS
  21. Connect the engine wiring harness at the following points: Intake air temperature (IAT) sensor (4) Fuel Injectors Throttle Position (TPS) Switch (2) Idle Air Control (IAC) Motor (3) Engine Oil Pressure Switch Engine Coolant Temperature (ECT) Sensor Manifold Absolute Pressure MAP) Sensor Camshaft Position (CMP) Sensor Coil Over Plugs Crankshaft Position Sensor
  22. Connect the ground straps on the right (3) side of the engine.
  23. Connect the ground straps on the left (2) side of the engine.
  24. Reinstall the radiator/cooling module assembly.
  25. Connect lower radiator hose.
  26. Connect upper radiator hose.
  27. Connect throttle and speed control cables.
  28. Install the heater hose assembly.
  29. Install coolant recovery bottle.
  30. Install the power steering pump.
  31. Install the generator (3).
  32. Install the A/C compressor (2).
  33. Install the drive belt.
  34. Install the fan shroud with the viscous fan assembly.
  35. Install the radiator core support bracket.
  36. Recharge the A/C system. Refer to «STANDARD PROCEDURE»(ref-288218-S28871183162008062000000) .
  37. Install the strut tower support (1).
  38. Install the air cleaner assembly.
  39. Refill the engine cooling system.
  40. Check and fill engine oil.
  41. Connect the battery negative cable.
  42. Start the engine and check for leaks.
