TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Engine cradle bolts - front | 203 | 150 | |
| Engine cradle bolts - rear | 122 | 90 | |
| Engine mount bolts | 111 | 82 | |
| Front differential - front support bolts | 54 | 40 | |
| Front differential - rear support bolt | 102 | 75 | |
| Front differential - right support bolt | 102 | 75 | |
| Front skid plate bolt | 28 | 21 | |
| Fuel filler tube support bolt | 14 | 10 | |
| Halfshaft nuts | 251 | 185 | |
| Lower ball joint nut | 81 | 60 | |
| Lower clevis bolts | 169 | 125 | |
| Outer tie rod end ball stud nut | 75 | 55 | |
| Rear body cradle rail bolts | 108 | 80 | |
| Rear body cradle rail bracket bolts/nuts | 102 | 75 | |
| Rear fascia to quarter panel nuts | 9 | 80 | |
| Rear track bar bolts/nuts | 190 | 140 | |
| Tow eye nuts - rear | 88 | 65 | |
| Tow hook nuts - front | 68 | 50 | |
| Tow hook bolt/nut - rear brace | 88 | 65 | |
| Tow hook nuts - rear mounting | 88 | 65 | |
| Trailer hitch bolts | 156 | 115 | |
| Transfer case skid plate bolts | 47 | 35 | |
| Transfer case skid plate nuts | 81 | 60 | |
| Transmission crossmember bolts | 54 | 40 | |
| Transmission mount bolts | 54 | 40 | |
| Upper ball joint nut | 81 | 60 | |
| Vapor canister nuts | 24 | 17 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Remove the fascia. See «REMOVAL»(ref-288249-S09630054822008062000000) .
- Remove the bolts (3).
- Remove the push pin fasteners and remove the fascia mounting bracket (1).
SPECIFICATIONS - FRAME DIMENSION
Frame dimensions are listed in metric scale. All dimensions are from center to center of Principal Locating Point (PLP), or from center to center of PLP and fastener location.
