Emission System: Specifications Jeep Commander I

Emission Applications 4 illustrations ~151 words

TORQUE SPECIFICATIONS

DESCRIPTIONN.mFt. Lbs.In. Lbs.
EVAP Canister Mounting Nuts1195
EVAP Canister Mounting Bracket-to-Frame Bolts1410125
NVLD Pump Mounting Bolts1195
NVLD Pump Filter Mounting Bolt1195
PCV Breather12106

TORQUE SPECIFICATIONS

Scheme 3

Scheme 3: EVAPORATIVE SYSTEM AND PURGE SOLENOID

The duty cycle EVAP canister purge solenoid (2) is located in the engine compartment attached to a bracket.

SPECIFICATIONS - TORQUE

DESCRIPTIONN.mFt. lbs.Inch lbs.
EGR Valve-to-Cyl. Head 3.7L/4.7L2821248
ERG Tube-to-EGR Valve Bolts139.6115
EGR Valve-to-Cyl. Head 5.7L/6.1L2821248

TORQUE SPECIFICATIONS

Scheme 4

Scheme 4: VALVE - EGR - 3.7L

The electronic EGR valve and solenoid assembly (1) is attached to the rear of the left cylinder head.

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. Use a diagnostic scan tool to record any DTC's (Diagnostic Trouble Codes).
  2. Disconnect and isolate the negative battery cable. An exhaust gas routing tube (1) connects the EGR valve (4) to the intake manifold.
  3. Remove two tube mounting bolts (2).
  4. Remove tube (1) from solenoid (4). Slip opposite end of tube (6) from intake manifold.
  5. Remove gasket (3) located between EGR valve solenoid and tube flange.
  6. Disconnect electrical connector (3) at solenoid (1).
  7. Remove two EGR valve solenoid mounting bolts (2).
  8. Remove solenoid (1) from engine.
  9. Remove and discard gasket (1) located under EGR solenoid.
