PANEL-TRIM Jeep Commander I

PANEL-TRIM

1. Install a new clip into the door at the mirror flag.
2. Position the door trim panel near the front door and connect the door wire harness connectors (2) to the power door switch assembly connectors (1).
3. Connect the interior door handle actuator rod (3) to the interior door handle (4) and engage the retainer.
4. Lift the trim panel (1) over the inside of the door far enough to engage the interior door latch lock link and knob into the hole at the upper rear corner of the trim panel and into the inner belt seal.
5. Position the trim panel to the inside of the door and fully engage the eight plastic door trim panel retention clips (3) to the door.
6. Install the three screws (2) that secure door trim panel to the door. Tighten the screws to 2 N.m (16 in. lbs.).
7. Reconnect the negative battery cable.

Scheme 270

1. Remove the watershield. See «REMOVAL»(ref-288230-S06790648092008062000000) .
2. Temporarily install the window switch and position the glass (2) fully up to gain access to the glass clamp screws (3).
3. Loosen the bolt in each of the window regulator glass clamps just far enough to release the door glass from the clamps. Do not completely remove.
4. Tape the glass securely into place.
5. Remove the mid-conduit clip and door harness clip prior to regulator removal.
6. Remove the bolts (1 and 3) that secure the window regulator rails to the inside of the door.
7. Lower the regulator rails within the door far enough to access and disconnect the wire harness connector (5) from the regulator motor through the large access hole in the center of the door and remove the regulator.
