Interior lights — Instrument illumination circuit Jeep Cherokee V facelift
All systems — 36 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Electronic suspension 2
- Engine performance 3.6l
- Engine performance 5.7l
- Engine performance 6.2l supercharged
- Engine performance 6.4l
- Exterior lights 4
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 2
- Navigation 5
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 6
- Power top/sunroof 2
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Trunk, tailgate, fuel door 3
- Warning systems
- Wiper/washer
Components on these wiring diagrams 29
Click a component to highlight it on every diagram it appears on.
