STARTER SPECIFICATIONS
| Application | Specification | ||
|---|---|---|---|
| Cranking Test | |||
| Test Voltage | 12.5 Volts | ||
| Minimum Voltage | 9.6 Volts | ||
| Amperage Draw | |||
| 2.5L | 130 Amps | ||
| 4.0L & 4.7L | 160 Amps | ||
| No-Load Test @ 11.2 Volts | |||
| Maximum Amps | |||
| 2.5L, 4.0L & 4.7L | 90 Amps | ||
| Minimum RPM | |||
| 2.5L | 2600 RPM | ||
| 4.0L | 2500 RPM | ||
| 4.7L | 2400 RPM | ||
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Starter-To-Block Bolts | |||
| 2.5L | 33 (45) | ||
| 4.0L | |||
| Upper Bolt | 40 (54) | ||
| Lower Bolt | 30 (41) | ||
| 4.7L | 50 (68) | ||
TORQUE SPECIFICATIONS
