Starting/charging 4.0l — Charging circuit Jeep Cherokee II facelift
All systems — 36 systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Body computer
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 2.5l
- Engine performance 4.0l
- Engine performance 4.7l
- Exterior lights 3
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 3
- Memory systems 2
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlocks
- Starting/charging 2
- Starting/charging 2.5l 2
- Starting/charging 4.0l 2
- Supplemental restraints
- Transmission 2.5l
- Transmission 4.0l
- Transmission 4.7l
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 3
Components on these wiring diagrams 18
Click a component to highlight it on every diagram it appears on.
