TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Cherokee |
| Rear Wiper Arm Retaining Nut | 13 (18) |
| INCH Lbs. (N.m) |
| Front Wiper Motor |
| Mounting Screws & Nuts | 53 (6) |
| Rear Wiper Motor |
| Mounting Screws | 44 (5) |
| Mounting Nut | 27 (3) |
| Wrangler |
| Crank Arm Nut | 101 (11.5) |
| Front Wiper Motor Mounting Screws | 53 (6) |
| Module Bracket Screws | 70 (9) |
| Rear Wiper Motor Output Shaft Nut | 30 (3.3) |
Front Wiper/Washer System Wiring Diagram (Cherokee - 1999). Scheme 1
Scheme 1: Front Wiper/Washer System Wiring Diagram (Cherokee - 1999)
Rear Wiper/Washer System Wiring Diagram (Cherokee - 1999). Scheme 2
Scheme 2: Rear Wiper/Washer System Wiring Diagram (Cherokee - 1999)
Front Wiper/Washer System Wiring Diagram (Wrangler - 2-Speed Wipers - 1999). Scheme 3
Scheme 3: Front Wiper/Washer System Wiring Diagram (Wrangler - 2-Speed Wipers - 1999)
Front Wiper/Washer System Wiring Diagram (Wrangler - Interval Wipers - 1999). Scheme 4
Scheme 4: Front Wiper/Washer System Wiring Diagram (Wrangler - Interval Wipers - 1999)
Rear Wiper/Washer System Wiring Diagram (Wrangler - 1999). Scheme 5
Scheme 5: Rear Wiper/Washer System Wiring Diagram (Wrangler - 1999)
