Wiring diagram: Interior lights — Interior light circuit Jeep Cherokee II
All systems
- Anti-lock brakes
- Anti-theft
- Computer data lines
- Computer data lines 5.2l
- Cruise control
- Defoggers
- Engine performance 2.5l
- Engine performance 4.0l
- Engine performance 5.2l
- Exterior lights 5
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster 3
- Interior lights
- Power distribution
- Power door locks 2
- Power mirrors 3
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 3
- Starting/charging 2
- Supplemental restraints
- Transmission
- Warning systems
- Wiper/washer 3
Interior light circuit (1 of 2) — Interior lights Jeep Cherokee II
Components on the diagram
Interior light circuit (2 of 2) — Interior lights Jeep Cherokee II
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
