Control Components: Removal & Installation Jaguar XKR II facelift

A/c Compressor 11 illustrations ~715 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

  1. Refer to Exterior Mirror Cover information.
  2. See figure.
  3. See figure.
  4. See figure.
  5. See figure.

INSTALLATION

  1. To install, reverse the removal procedure.

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the servo motor assembly. Disconnect the electrical connector. Remove the 3 screws.
  1. Install the servo motor assembly. Align the servo motor drive. Install the screws. Connect the electrical connector.
  2. Install the instrument panel. Refer to Instrument Panel information.
  3. Connect the battery ground cable and install the cover. Refer to Specifications information.

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the servo motor assembly. Disconnect the electrical connector. Remove the 3 screws.
  1. Install the servo motor assembly. Align the servo motor drive. Install the screws. Connect the electrical connector.
  2. Install the instrument panel. Refer to Instrument Panel information.
  3. Connect the battery ground cable and install the cover. Refer to Specifications information.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the LH side footwell heater duct. Release the lampholder. Remove the 2 screws.
  4. Remove the support bracket. Remove the screw.
  5. Remove the servo motor assembly. Disconnect the electrical connector. Remove the 3 screws.
  1. Install the servo motor assembly. Align the servo motor drive. Install the screws. Connect the electrical connector.
  2. Install the support bracket. Install the screw.
  3. Install the LH side footwell heater duct. Install the screws.
  4. Install the instrument panel. Refer to Instrument Panel information.
  5. Connect the battery ground cable and install the cover. Refer to Specifications information.

Scheme 9

Scheme 9: REMOVAL
Scheme 9: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the LH side footwell heater duct. Release the lampholder. Remove the 2 screws.
  4. Remove the servo motor assembly. Disconnect the electrical connector. Remove the 3 screws.
  1. Install the servo motor assembly. Align the servo motor drive. Install the screws. Connect the electrical connector.
  2. Install the LH side footwell heater duct. Install the screws.
  3. Install the instrument panel. Refer to Instrument Panel information.
  4. Connect the battery ground cable and install the cover. Refer to Specifications information.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL
  1. Remove the instrument panel, lower trim panel. Refer to Instrument Panel Lower Trim Panel information.
  2. Remove the in-vehicle temperature sensor. Remove the Torx screw. Disconnect the electrical connector.
  1. Install the in-vehicle temperature sensor. Position the electrical harness. Connect and secure the electrical connector. Install the Torx screw.
  2. Install the instrument panel, lower trim panel. Refer to Instrument Panel Lower Trim Panel information.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the servo motor assembly. Disconnect the electrical connector. Remove the 3 screws.
  1. Install the servo motor assembly. Align the servo motor drive. Install the screws. Connect the electrical connector.
  2. Install the instrument panel. Refer to Instrument Panel information.
  3. Connect the battery ground cable and install the cover. Refer to Specifications information.

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL

Scheme 13

Scheme 13
Scheme 13
  1. Remove the center speaker grille. Carefully release the 4 clips. Disconnect the electrical connector.
  2. Remove the sunload sensor. Remove the 2 screws.
  1. Install the sunload sensor. Install the screws.
  2. Install the center speaker grille. Connect the electrical connector. Secure the clips.

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL
  1. Remove the cover and disconnect the battery ground cable. Refer to Specifications information.
  2. Remove the instrument panel. Refer to Instrument Panel information.
  3. Remove the A/C control module. Remove the 4 Torx screws. Disconnect the electrical connector.
  1. Install the A/C control module. Install the Torx screws. Connect the electrical connector.
  2. Install the instrument panel. Refer to Instrument Panel information.
  3. Connect the battery ground cable and install the cover. Refer to Specifications information.
  4. Connect WDS to the vehicle and configure a new module.

Note. Removal of this component is part of the audio removal procedure.

  1. Disconnect the battery ground cable.
  2. Remove the audio unit. Refer to Audio Unit information.
  1. Install the audio unit. Refer to Audio Unit information.
  2. Connect the battery ground cable.
