Multifunction Electronic Modules: Removal & Installation Jaguar XKR II рестайлинг

Communication Devices 7 illustrations ~360 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL
  1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  2. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.

INSTALLATION

  1. To install, reverse the removal procedure.

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL
  1. Remove the front seat. Refer to «FRONT SEAT»(ref-574739-S16689516712013082800000) information.
  2. Remove the front seat control module. Disconnect the 4 electrical connectors. Remove the 2 Torx bolts.
  1. Install the front seat control module. Connect the electrical connectors. Tighten the Torx bolts to 10 Nm (7 lb.ft).
  2. Install the front seat. Refer to «FRONT SEAT»(ref-574739-S16689516712013082800000) information.

Scheme 8

Scheme 8: REMOVAL
Scheme 8: REMOVAL

Scheme 9

Scheme 9
Scheme 9
  1. Disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  2. Remove the instrument panel center reinforcement trim panel. Release from the 5 clips.
  3. Release the navigation system module bracket. Remove the 4 Torx screws. Release the assembly.
  4. Remove the information and entertainment module. Remove the 4 Torx bolts. Disconnect the 2 electrical connectors.
  1. Install the information and entertainment module. Tighten the Torx bolts to 6 Nm (4 lb.ft). Connect the electrical connectors.
  2. Install the navigation system module bracket. Tighten the Torx screws.
  3. Install the instrument panel center reinforcement trim panel. Align the pegs and secure with the clips.
  4. Connect the battery ground cable. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  5. Connect WDS to the vehicle and configure a new module.

Note. Removal steps in this procedure may contain installation details.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL
  1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  2. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.
  1. To install, reverse the removal procedure.

Note. This module is installed on the inside of the RH A-pillar above the footwell and does not change with the hand of drive.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL

Scheme 12

Scheme 12
Scheme 12
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  2. Remove the RH side footwell trim panel. Remove the 3 clips.
  3. Remove the keyless entry module. Remove the 2 Torx screws. Disconnect the 5 electrical connectors.
  1. Install the keyless entry module. Connect the electrical connectors. Install the screws.
  2. Install the RH side footwell trim panel. Carefully secure the clips.
  3. Connect the battery ground cable and install the cover. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  4. Connect WDS to the vehicle and configure a new module.
