Specifications
| CAUTION | Nuts and bolts must be tightened with the weight of the vehicle on the suspension. |
| Description | Nm | Lb-ft |
|---|---|---|
| Front lower arm to rear lower arm - nut (1) | ||
| Stage 1 | 60 | 44 |
| Stage 2 | 135 degrees in clockwise direction | 135 degrees - clockwise direction |
| Front lower arm to subframe - nut (1) | 175 | 129 |
| Rear lower arm to subframe - nut (1) | 175 | 129 |
| Rear lower arm to wheel knuckle ball joint - nut (1) | 75 | 55 |
| Shock absorber to spring - nut | ||
| Active shock absorber | 50 | 37 |
| Passive shock absorber | 27 | 20 |
| Shock absorber and spring assembly to lower arm - bolt | 175 | 129 |
| Shock absorber and spring assembly to top mount - nuts | 27 | 20 |
| Stabilizer bar clamp to subframe - bolt | 55 | 40 |
| Stabilizer bar link to lower arm - nut (1) | 70 | 52 |
| Stabilizer bar link to stabilizer bar - nut (1) | 43 | 32 |
| Upper arm ball-joint - nut (1) | 90 | 66 |
| Upper arm to subframe brackets - nut (1) | 60 | 44 |
| Wheel bearing and hub assembly to wheel knuckle - bolts (1) | 90 | 66 |
| (1) New nut/bolt must be installed. | ||
| (1) | New nut/bolt must be installed. |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Right Hand (RH) wheel hub and bearing assembly |
| 2 | RH wheel knuckle |
| 3 | Upper control arm bush (2 off) |
| 4 | RH upper control arm |
| 5 | RH top mount plate |
| 6 | RH spring and damper assembly |
| 7 | Stabilizer link |
| 8 | RH lower lateral control arm |
| 9 | Front subframe |
| 10 | Left Hand (LH) lower lateral control arm |
| 11 | LH spring and damper assembly |
| 12 | Upper control arm bush (2 off) |
| 13 | LH top mount plate |
| 14 | LH upper control arm |
| 15 | LH wheel knuckle |
| 16 | LH wheel hub and bearing assembly |
| 17 | LH lower control arm |
| 18 | Mounting bracket (2 off) |
| 19 | Stabilizer bar |
| 20 | Stabilizer bar bush (2 off) |
| 21 | RH lower control arm |
