Starting System: Removal & Installation Jaguar XKR II

Installation

1. Install the starter motor. Clean the component mating faces. Tighten the bolts to 45 Nm (33 lb.ft).
2. Connect the starter motor solenoid electrical connector. Tighten the new nut to 7 Nm (5 lb.ft).
3. Connect the battery positive and generator cables. Tighten the nut to 10 Nm (7 lb.ft). Secure the cover.
4. Install the RH engine mount.
5. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312564-S31890761012009041400000) article.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Remove the rear seat armrest. Refer to «Rear Seat Armrest»(ref-312549-S32221670662009041400000) article.
2. Remove the floor console veneer trim panel. Refer to «Floor Console Finish Panel»(ref-312550-S23819977062009041400000) article.
3. Remove the floor console rear panel. Carefully release the 2 clips.
4. Remove the floor console side panel trim. Remove the 2 Torx bolts. Carefully release 11 clips. Repeat the procedure and remove the opposite hand.
5. Remove the keyless start control module trim cover. Remove the 2 Torx screws.
6. Remove the keyless start control module. Remove the 2 Torx screws. Disconnect the electrical connector.

1. Install the keyless start control module. Connect the electrical connector. Install the Torx screws.
2. Install the keyless start control module trim cover. Install the Torx screws.
3. Install the floor console side panel trim. Carefully align and secure the clips. Tighten the Torx screws to 6 Nm (4 lb.ft). Install the opposite hand.
4. Install the floor console rear panel. Align the lugs and secure the clips.
5. Install the floor console veneer trim panel. Refer to «Floor Console Finish Panel»(ref-312550-S23819977062009041400000) article.
6. Install the rear seat armrest. Refer to «Rear Seat Armrest»(ref-312549-S32221670662009041400000) article.
7. Connect WDS to the vehicle and configure a new module.
