Seating: Removal & Installation Jaguar XKR II

Seats 28 illustrations ~2059 words

Installation

  1. With assistance, install the front seat. Connect the electrical connectors. Install the new bolts and tighten to 40 Nm (30 lb.ft).
  2. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312541) article.
  3. Secure the front seat. Position the front seat fully forwards. Install the new bolts and tighten to 40 Nm (30 lb.ft). Install the bolt covers.

Scheme 14

Scheme 14: Removal
Scheme 14: Removal

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  2. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  3. Remove the front seat head reatraint. Depress the 2 clips.
  4. Remove the front seat head restraint guide tubes. Release from the seat frame.
  5. Remove the front seat backrest tilt handle. Remove the screw.
  6. Remove the front seat backrest tilt handle trim panel. Remove the 2 Torx screws.
  7. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  8. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  9. Release the 5 front seat backrest cover lower retaining clips. Release from the seat frame.
  10. Release the front seat backrest cover central tension straps. Release from the seat frame.
  11. Remove the side air bag module. Remove and discard the 2 nuts. Disconnect the electrical connector. Release the backrest cover.
  12. Release the front seat backrest cover upper tension straps. Release from the seat frame. Withdraw from the backrest pad.
  13. Remove the front seat backrest cover. Remove the 16 hog rings.
  1. Install the front seat backrest cover. Install the 16 hog rings.
  2. Secure the front seat backrest cover upper tension straps. Pass through the backrest pad. Attach to the seat frame.
  3. Install the side air bag module. Attach the backrest cover. Tighten the new nuts to 7 Nm (5 lb.ft). Connect the electrical connector.
  4. Secure the front seat backrest cover central tension straps. Attach to the seat frame.
  5. Secure the front seat backrest cover lower retaining clips. Attach to the seat frame.
  6. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  7. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  8. Install the front seat backrest tilt handle trim panel. Install and tighten the Torx screws.
  9. Install the front seat backrest tilt handle. Install the screw.
  10. Install the front seat head restraint guide tube. Release from the seat frame. Secure in the seat frame.
  11. Install the front seat head reatraint.
  12. Install the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .

Scheme 20

Scheme 20: Removal
Scheme 20: Removal
  1. Remove the front door trim panel. Refer to «Front Door Trim Panel»(ref-312547-S41980094112009041400000) article.
  2. Remove the front seat control switch. Remove the 4 Torx screws. Disconnect the electrical connector.
  1. Install the front seat control switch. Connect the electrical connector. Fit and tighten the Torx screws.
  2. Install the front door trim panel. Refer to «Front Door Trim Panel»(ref-312547-S41980094112009041400000) article.

Scheme 21

Scheme 21: Removal
Scheme 21: Removal

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
  1. Remove the cover and disconnect the battery ground cable.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  3. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  4. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  5. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  6. Remove the front seat hinge covers. Remove the 2 Torx screws. Remove the hinge cover retainers.
  7. Release the front seat backrest cover lower tension straps.
  8. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Release the Velcro strap. Release the 5 clips.
  9. Remove the front seat cushion cover. Remove the 27 hog rings.
  10. Using WDS, calibrate a new front seat cushion cover.
  1. Install the front seat cushion cover.
  2. Secure the front seat cushion assembly. Connect and secure the electrical connectors. Secure the Velcro strap. Attach the clips.
  3. Secure the front seat backrest cover lower tension straps.
  4. Install the front seat cushion outer trim panel. Connect the electrical connector. Secure in the clips.
  5. Secure the front seat cushion outer trim panel. Tighten the Torx screws.
  6. Install the front seat hinge covers. Attach the hinge cover retainers. Tighten the Torx screws.
  7. Install the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  8. Connect the battery ground cable and install the cover.

Scheme 25

Scheme 25
Scheme 25
  1. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  2. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  3. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  4. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  5. Release the front seat lumbar assembly. Release the 3 electrical connectors. Remove the clip. Disconnect the electrical connector.
  6. Remove the front seat lumbar assembly.
  1. Install the front seat lumbar assembly.
  2. Secure the front seat lumbar assembly. Install the clip. Connect the electrical connector. Secure the electrical connectors.
  3. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  4. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  5. Install the front seat head reatraint.
  6. Install the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27
  1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  3. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  4. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  5. Remove the front seat hinge cover. Remove the 2 Torx screws. Remove the hinge cover retainer.
  6. Remove the front seat backrest cover. See «Front Seat Backrest Cover»(ref-312549-S34788088922009041400000) .
  7. Remove the front seat backrest pad. Disconnect the electrical connector.
  8. Release the front seat lumbar assembly. Release the 3 electrical connectors. Remove the clip. Disconnect the electrical connector.
  9. Remove the front seat lumbar assembly.
  10. Release the front seat recliner motor. Remove the front seat backrest shaft clip. Remove the front seat backrest shaft.
  11. Remove the front seat recliner motor. Disconnect the electrical connector. Drill out the rivet.
  1. To install, reverse the removal procedure.

Scheme 28

Scheme 28: Removal
Scheme 28: Removal
  1. Remove the rear seat armrest. Release from the 4 clips.
  1. Install the rear seat armrest. Secure with the clips.

Scheme 29

Scheme 29: Removal
Scheme 29: Removal
  1. Remove the LH rear seat cushion. See «Rear Seat Cushion»(ref-312549-S39745861382009041400000) .
  2. Repeat the above procedure for the RH seat cushion.
  3. Remove the auxiliary junction box access cover. Release the clip.
  4. Remove the rear seat backrest. Remove the 2 Torx bolts. Release from the 2 retainers.
  1. Install the rear seat backrest. Secure in the retainers. Tighten the Torx bolt to 10 Nm (7 lb.ft).
  2. Install the auxiliary junction box access cover. Align the pegs and secure the clip.
  3. Install the LH rear seat cushion. See «Rear Seat Cushion»(ref-312549-S39745861382009041400000) . Secure with the clips.
  4. Install the RH rear seat cushion.

Scheme 30

Scheme 30: Removal
Scheme 30: Removal
  1. Remove the rear seat armrest. See «Rear Seat Armrest»(ref-312549-S32221670662009041400000) .
  2. Remove the rear seat cushion. Release from the 2 clips.
  1. Install the rear seat cushion. Secure with the clips.
  2. Install the rear seat armrest. See «Rear Seat Armrest»(ref-312549-S32221670662009041400000) .

Scheme 31

Scheme 31
Scheme 31
  1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  3. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  4. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  5. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  6. Release the 5 front seat backrest cover lower retaining clips. Release from the seat frame.
  7. Release the front seat backrest cover central tension straps. Release from the seat frame.
  8. Remove the front seat backrest heater mat. Disconnect the electrical connector.
  1. Install the front seat backrest heater mat.
  2. Secure the front seat backrest cover central tension straps. Attach to the seat frame.
  3. Secure the front seat backrest cover lower retaining clips. Attach to the seat frame.
  4. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  5. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  6. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312541) article.

Removal

  1. Remove the cover and disconnect the battery ground cable.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  3. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  4. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  5. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  6. Remove the front seat hinge covers. Remove the 2 Torx screws. Remove the hinge cover retainers.
  7. Release the front seat backrest cover lower tension straps.
  8. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Release the Velcro strap. Release the 5 clips.
  9. Remove the front seat cushion cover. Remove the 27 hog rings.
  10. Remove the front seat cushion heater mat. Carefully release from the seat cushion pad.
  1. Install the front seat cushion heater mat. Secure to the seat cushion pad.
  2. Install the front seat cushion cover.
  3. Secure the front seat cushion assembly. Connect and secure the electrical connectors. Secure the Velcro strap. Attach the clips.
  4. Secure the front seat backrest cover lower tension straps.
  5. Install the front seat cushion outer trim panel. Connect the electrical connector. Secure in the clips.
  6. Secure the front seat cushion outer trim panel. Tighten the Torx screws.
  7. Install the front seat hinge covers. Attach the hinge cover retainers. Tighten the Torx screws.
  8. Install the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  9. Connect the battery ground cable and install the cover.

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33
  1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312556) or «Supplemental Restraint System (SRS) Depowering and Repowering»(ref-312557) article.
  3. Remove the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  4. Release the front seat backrest cover lower tension straps.
  5. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Release the Velcro strap. Release the 5 clips.
  6. Remove the front seat safety belt pretensioner. Remove and discard the Torx bolt. Release and disconnect the electrical connector.
  7. Release the seat module bracket. Disconnect the 4 electrical connectors. Release the 3 wiring harness clips. Remove and discard the cable tie. Remove the 4 Torx bolts.
  8. Remove the seat track assembly. Remove and discard the 4 Torx bolts.
  1. Install the seat track assembly. Tighten the new Torx bolts to 45 Nm (33 lb.ft).
  2. Secure the seat module bracket. Tighten the Torx bolts to 10 Nm (7 lb.ft). Secure the harness with a cable tie. Attach the wiring harness clips. Connect the electrical connectors.
  3. Install the front seat safety belt pretensioner. Connect and secure the electrical connector. Tighten the new Torx bolt to 45 Nm (33 lb.ft).
  4. Secure the front seat cushion assembly. Connect and secure the electrical connectors. Secure the Velcro strap. Attach the clips.
  5. Secure the front seat backrest cover lower tension straps.
  6. Install the front seat. See «Front Seat»(ref-312549-S36210189222009041400000) .
  7. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312541) article.

Scheme 34

Scheme 34: Disassembly
Scheme 34: Disassembly

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. Remove the rear outer seat backrest. Refer to «Rear Seat Backrest - Removal and Installation»(ref-312549-S17996963632009041400000) .
  2. Remove the rear seat head restraint.
  3. Detach the rear seat head restraint retaining post.
  4. Remove the rear seat head restraint retaining post.
  5. Detach the rear seat outer backrest cover.
  6. Detach the rear seat backrest cover and cushion.
  7. Remove the rear seat backrest cover and cushion. Disconnect the rear seat backrest heater pad electrical connector.
  8. Disconnect the rear seat lumbar support electrical connector.
  9. Detach the rear seat lumbar support control valve.
  10. Remove the rear seat lumbar support.
  11. Disconnect the rear seat head restraint motor electrical connector.
  12. Remove the rear seat head restraint motor.
