Multifunction Electronic Modules: Removal & Installation Jaguar XKR II

Communication Devices 4 illustrations ~269 words

Installation

  1. Install the front seat control module. Connect the electrical connectors. Tighten the Torx bolts to 10 Nm (7 lb.ft).
  2. Install the front seat. Refer to «Front Seat»(ref-312549-S36210189222009041400000) article.

Scheme 14

Scheme 14: Removal

Scheme 15

Scheme 15
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  2. Remove the instrument panel center reinforcement trim panel. Release from the 5 clips.
  3. Release the navigation system module bracket. Remove the 4 Torx screws. Release the assembly.
  4. Remove the information and entertainment module. Remove the 4 Torx bolts. Disconnect the 2 electrical connectors.
  1. Install the information and entertainment module. Tighten the Torx bolts to 6 Nm (4 lb.ft). Connect the electrical connectors.
  2. Install the navigation system module bracket. Tighten the Torx screws.
  3. Install the instrument panel center reinforcement trim panel. Align the pegs and secure with the clips.
  4. Connect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  5. Connect WDS to the vehicle and configure a new module.

Removal

Note. This module is installed on the inside of the RH A-pillar above the footwell and does not change with the hand of drive.

Scheme 16

Scheme 16: Removal

Scheme 17

Scheme 17
  1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-312541) article.
  2. Remove the RH side footwell trim panel. Remove the 3 clips.
  3. Remove the keyless entry module. Remove the 2 Torx screws. Disconnect the 5 electrical connectors.
  1. Install the keyless entry module. Connect the electrical connectors. Install the screws.
  2. Install the RH side footwell trim panel. Carefully secure the clips.
  3. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312541) article.
  4. Connect WDS to the vehicle and configure a new module.
