Steering System - General Information: Other Jaguar XKR II рестайлинг 2

Functional

Boom

Rhythmic sound like a drum roll or distant thunder. May cause pressure on the ear drum.

Buzz

Low-pitched sound, like a bee. Usually associated with vibrations.

Chatter

Rapidly repeating metallic sound.

Chuckle

Rapid noise that sounds like a stick against the spokes of a spinning bicycle wheel.

Chirp

High pitched rapidly repeating sound, like chirping birds.

Click

Light sound, like a ball point pen being clicked.

Click/Thump

Heavy metal-to-metal sound, like a hammer striking steel.

Grind

Abrasive sound, like a grinding wheel or sandpaper rubbing against wood.

Groan/Moan

Continuous, low-pitched humming sound.

Groan/Howl

Low, guttural sound, like an angry dog.

Hiss

Continuous sound like air escaping from a tire valve.

Knock

Heavy, loud repeating sound like a knock on a door.

Ping

Similar to knock, except at higher frequency.

Roar

Deep, long, prolonged sound like an animal, or winds and ocean waves.

Rumble

Low, heavy continuous sound like that made by wagons or thunder.

Scrape

Grating noise like one hard plastic part rubbing against another.

Squeal

Continuous, high-pitched sound like running finger nails across a chalkboard.

Tap

Light, hammering sound like tapping pencil on edge of table. May be rhythmic or intermittent.

Whirr/Whine

High-pitched buzzing sound, like an electric motor or drill.

Whistle

Sharp, shrill sound, like wind passing a small opening.

Belt Squeal

Belt squeal is a high frequency air-borne noise generated by slippage of the ribbed Vee belt on the power steering pump pulley. Squeal increases with system loading and at full lock.

Clonk

Clonk is a structure-borne noise heard as a loose-sounding rattle or vibration coming from the steering column. Clonk can be identified by driving and turning over cobblestones, rough roads, or high frequency bumps such as 25-50 mm tall tar strips. Clonk requires a tie-rod load impact.

Column Knock

Column knock is a loose-sounding rattle or vibration generated by the steering column shaft contacting other portions of the column assembly. The noise is both audible and tactile. Column knock is generated by driving over cobblestones or rough pavement. It is not necessary to turn the steering wheel to create this noise.

Grinding/Scrape

Grinding is a low frequency noise in the column when the steering wheel is turned. It is generally caused by interference between moving components such as the steering wheel to steering column shroud.

Grunt (Squawk/Whoop)

Grunt is a 'honking' sound elicited when coming off one of the steering stops. Grunt is generally excited during parking manoeuvres with a low to medium speed steering input.

Hiss (Swish)

Hiss or Valve Hiss is a high-frequency sound coming from the steering gear when the system is loaded. It is a rushing or 'swish' noise that doesn't change frequency with RPM. Hiss is the general noise generated by the flow of hydraulic fluid through restrictions in the steering system. Restrictions include the rotary steering valve, power steering tubes, connectors, tuning orifices, etc. Hiss can be air-borne and structure-borne, but the structure-borne path through the steering intermediate shaft is usually dominant.

Moan (Groan)

Moan is the general structure-borne noise of the steering system. Moan is primarily transmitted to the driver via the body structure through the pump mount, engine mounts, power steering lines and power steering brackets. On some vehicles, moan is a loud humming noise, often present when the wheel is turned and the system is loaded. It may change frequency with engine RPM and if the system is loaded or unloaded.

Steering Gear Knock (Steering Gear Slap)

Steering gear knock is a rattle sound and steering wheel vibration caused by separation of the steering gear and pinion while driving over bumps. It is a structure-borne noise transmitted through the intermediate shaft and column. Steering gear knock can also be heard as a 'thump' or impact noise that occurs with the vehicle stationary when the steering wheel is released from a loaded position and allowed to return to rest. Noise occurs with the engine on or off.

Weep

Weep is an air-borne noise, occasionally generated when turning the steering across lock at a constant rate. When present on a vehicle the noise, once initiated can often be maintained across a large proportion of the available steering movement.

Whistle is similar to hiss but is louder and of a higher frequency. It is also more of a pure tone noise than hiss. Whistle is air-borne and is generated by a high flow rate of hydraulic fluid through a small restriction.

Zip

Zip noise is the air-borne noise generated by power steering pump cavitation when power steering fluid does not flow freely through the suction hose from the reservoir to the pump. Zip primarily occurs during cold weather at start-up.

Buzz is a tactile rotary vibration felt in the steering wheel when steering inputs are slow. Buzz can also be called a grinding feel and it is closely related to grunt and is caused by high system gain with low damping. Buzz is generally excited during parking manoeuvres with low to medium speed steering input.

Buzz (Electrical)

A different steering buzz can be caused by pulse width modulated (PWM) electric actuators used in variable assist steering systems. This buzz is felt by turning the ignition key to run without starting the engine and holding onto the steering wheel. In extreme cases, the buzz can be felt with the engine running also.

Column/Steering Wheel Shake

Column shake is a low frequency vertical vibration excited by primary engine vibrations.

Nibble (Shimmy)

Steering nibble is a rotary oscillation or vibration of the steering wheel, which can be excited at a specific vehicle speed. Nibble is driven by wheel and tire imbalance exciting a suspension recession mode, which then translates into steering gear travel and finally steering wheel nibble.

Shudder (Judder)

Shudder is a low frequency oscillation of the entire steering system (tire, wheels, steering gear and linkage, etc.) when the vehicle is steered during static-park or at low speeds. Shudder is very dependent on road surface.

Wheel Fight (Kick Back)

Wheel fight is excess feedback of sudden road forces through the steering system and back to the driver. It is evaluated at all vehicle speeds over cobblestones, rough roads, and potholes. The tires, wheels, and suspension generate forces into the steering systems. Steering friction, hydraulic damping, hydraulic compliance, mechanical compliance, steering ratio, and assist gain all affect how much is transmitted to the driver.

Scheme 10

1. Clean power steering fluid reservoir around the filler cap and fluid indicator. Check the power steering fluid, if aerated, wait until fluid is free from bubbles then top-up reservoir to UPPER level mark with recommended fluid.
2. Remove the filler cap and fill to the MAX level mark. Install the reservoir filler cap.
3. Start the engine and allow to run for 10 seconds, stop the engine. Check the power steering fluid, if aerated, wait until fluid is free from bubbles then top-up reservoir to UPPER level mark with recommended fluid.
4. Start the engine and turn steering fully lock to lock, stop the engine. Check and top-up power steering fluid level.
5. Start and run the engine for 2 minutes, turn the steering fully lock to lock. Check and top-up power steering fluid level.

Scheme 11

Scheme 12

1. Raise and support the vehicle.
2. Refer to «Air Deflector»(ref-574757-S24500562812013082800000) information.
3. Using a syringe, remove the PAS fluid from the reservoir.

Scheme 13

1. Torque: 20 Nm
2. Fill the power steering reservoir.
3. Install the vacuum hand pump to the power steering fluid reservoir.
4. Apply a vacuum to the power steering fluid reservoir.
5. Remove the vacuum hand pump from the power steering fluid reservoir.
6. Fill the power steering reservoir.
7. Run the engine for 30 seconds. Turn the steering fully lock-to-lock, stop the engine.
8. Install the vacuum hand pump to the power steering fluid reservoir.
9. Apply a vacuum to the power steering fluid reservoir.
10. Remove the vacuum hand pump from the power steering fluid reservoir.
11. Fill the power steering reservoir.
12. Run the engine for 30 seconds. Turn the steering fully lock-to-lock, stop the engine
13. Install the vacuum hand pump to the power steering fluid reservoir.
14. Apply a vacuum to the power steering fluid reservoir.
15. Remove the vacuum hand pump from the power steering fluid reservoir.
16. Fill the power steering reservoir.
17. Run the engine for 30 seconds. Turn the steering fully lock-to-lock, stop the engine.
18. Install the power steering fluid reservoir cap.
19. Refer to «Air Deflector»(ref-574757-S24500562812013082800000) information.
