Steering Column: Removal & Installation Jaguar XKR II рестайлинг 2

Steering Column 9 illustrations ~666 words

INSTALLATION

  1. Install the steering angle sensor. Install the reluctor ring. Install the bolts and tighten to 3 Nm (2.2 lb.ft).
  2. Install the clockspring. Install the Torx bolts and tighten to 6 Nm (4 lb.ft).
  3. Remove the special tool.
  4. Install the steering wheel. Check the clockspring is aligned. Position the electrical harness. Tighten the bolt to 40 Nm (30 lb.ft). Connect the electrical connector.
  5. Install the driver air bag module. Connect the electrical connectors. Carefully align and secure the clips.
  6. Install the steering column. Install the 4 nuts, do not tighten at this time.
  7. Connect the steering angle sensor electrical connector. Secure the 3 clips.
  8. Connect the steering harness electrical connectors Secure the 3 clips.
  9. Install the steering column upper cowl. Install the screws.
  10. Secure the steering column. Tighten the nuts to 30 Nm (22 lb.ft).
  11. Connect the steering column lower shaft to the steering column. Align the shafts. Tighten the nuts to 30 Nm (22 lb.ft).
  12. Install the steering column lower cowl. If installed, connect the steering column and foot pedal switch electrical connector. Secure in the clips. Install the screws.
  13. Install the instrument panel lower trim panel. Refer to «Instrument Panel Lower Trim Panel»(ref-574770-S27488087262013082800000) information.
  14. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
  15. Raise and support the vehicle.
  16. Loosen the upper bolt from the steering column lower universal joint. Allow the steering column lower universal joint to settle. Tighten the bolt to 30 Nm (22 lb.ft).
  17. Connect WDS and configure the steering angle sensor.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL

Scheme 3

Scheme 3
Scheme 3
  1. Turn the steering wheel to the straight ahead position.
  2. Raise and support the vehicle.
  3. Remove the steering column lower universal joint assembly for access. Remove and discard the 2 bolts.
  4. Remove the instrument panel lower trim panel. Refer to «Instrument Panel Lower Trim Panel»(ref-574770-S27488087262013082800000) information.
  5. Disconnect the steering column lower shaft from the steering column. Remove the bolt.
  6. Remove the steering column lower shaft. Remove the 2 nuts. Release the bearing carrier. Discard the gasket.
  7. Remove the bearing carrier. Remove the 2 bolts.
  1. Install the bearing carrier. Install a new gasket. Tighten the bolts to 10 Nm (7 lb.ft).
  2. Install the steering column lower shaft. Install a new gasket. Tighten the nuts to 10 Nm (7 lb.ft).
  3. Connect the steering column lower shaft to the steering column. Align the shafts. Tighten the nuts to 30 Nm (22 lb.ft).
  4. Raise the vehicle.
  5. Install the steering column lower universal joint assembly. Align the shafts. Tighten the new bolts to 30 Nm (22 lb.ft).
  6. Install the instrument panel lower trim panel. Refer to «Instrument Panel Lower Trim Panel»(ref-574770-S27488087262013082800000) information.
  1. Install the air bag ground cable. Install the Torx screw.
  2. Install the air bag housing. Secure the electrical harness. Install the Torx bolts and tighten to 6 Nm (4 lb.ft).
  3. Install the steering wheel switch assembly. Connect and secure the electrical connectors. Tighten the Torx bolt to 3 Nm (2 lb.ft). Repeat the above procedure on the opposite hand.
  4. Install the upshift and downshift paddle switches. Connect and secure the electrical connector. Tighten to 3 Nm. Repeat the above procedure on the opposite hand.
  5. Remove the special tool.
  6. Install the steering wheel. Position the electrical harness. Tighten the bolt to 40 Nm (30 lb.ft). Connect the electrical connector.
  7. Install the driver air bag module. Refer to «Driver Air Bag Module»(ref-574731-S05491284792013082800000) information.
  8. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.

REMOVAL

WARNINGAlways wear safety glasses when repairing an air bag supplemental restraint system (SRS) vehicle and when handling an air bag module.
WARNINGCarry a live air bag module with the air bag and trim cover pointed away from your body. This will reduce the risk of injury in the event of an accidental deployment. Failure to follow this instruction may result in personal injury.
WARNINGDo not set a live air bag module down with the trim cover face down. Failure to follow this instruction may result in personal injury.
WARNINGAfter deployment, the air bag surface can contain deposits of sodium hydroxide, a product of the gas generant combustion that is irritating to the skin. Wash your hands with soap and water afterwards. Failure to follow this instruction may result in personal injury.
WARNINGNever probe the connectors on the air bag module. Doing so may result in air bag deployment, which may result in personal injury. Failure to follow this instruction may result in personal injury.
WARNINGAir bag modules with discolored or damaged trim covers must be replaced, not repainted.
WARNINGVehicle sensor orientation is critical for correct system operation. If a vehicle equipped with an air bag supplemental restraint system (SRS) is involved in a collision, inspect the sensor mounting bracket and wiring pigtail for deformation. If damaged, replace the sensor whether or not the air bag is deployed.
WARNINGTo avoid accidental deployment and possible personal injury, the backup power supply must be depleted before repairing or replacing any air bag supplemental restraint system (SRS) components. To deplete the backup power supply energy, disconnect the battery ground cable and wait one minute. Failure to follow this instruction may result in personal injury.
CAUTIONMake sure the wheels are in the straight-ahead position. Failure to follow this instruction may result in damage to the component.

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Remove the cover and disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-574738) information.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Health and Safety Precautions»(ref-574729-S16631063202013082800000) information.
  3. Refer to «Driver Air Bag Module»(ref-574731-S05491284792013082800000) information.
  4. Remove the steering wheel. Disconnect the electrical connector. Loosen, but do not fully remove the bolt. Release the steering wheel from the spline. Remove the bolt. Release the electrical harness.
  5. Torque: 6 Nm
  6. Remove the special tool.
  1. To install, reverse the removal procedure.
