Seating: Removal & Installation Jaguar XKR II рестайлинг 2

Seats 51 illustrations ~2061 words

REMOVAL

  1. Release the front seat. Position the front seat fully forwards. Remove and discard the 4 rear bolts.
  2. Position the front seat fully rearwards.
  3. Remove the cover and disconnect the battery ground cable. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  4. With assistance, remove the front seat. Remove and discard the front 2 Torx bolts. Disconnect the 3 electrical connectors.

INSTALLATION

  1. With assistance, install the front seat. Connect the electrical connectors. Install the new bolts and tighten to 40 Nm (30 lb.ft).
  2. Connect the battery ground cable and install the cover. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  3. Secure the front seat. Position the front seat fully forwards. Install the new bolts and tighten to 40 Nm (30 lb.ft). Install the bolt covers.

Scheme 1

Scheme 1: REMOVAL
Scheme 1: REMOVAL

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6
  1. Make the SRS system safe. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-574731-S00023799962013082800000) information.
  2. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  3. Remove the front seat head restraint. Depress the 2 clips.
  4. Remove the front seat head restraint guide tubes. Release from the seat frame.
  5. Remove the front seat backrest tilt handle. Remove the screw.
  6. Remove the front seat backrest tilt handle trim panel. Remove the 2 Torx screws.
  7. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  8. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  9. Release the 5 front seat backrest cover lower retaining clips. Release from the seat frame.
  10. Release the front seat backrest cover central tension straps. Release from the seat frame.
  11. Remove the side air bag module. Remove and discard the 2 nuts. Disconnect the electrical connector. Release the backrest cover.
  12. Release the front seat backrest cover upper tension straps. Release from the seat frame. Withdraw from the backrest pad.
  13. Remove the front seat backrest cover. Remove the 16 hog rings.
  1. Install the front seat backrest cover. Install the 16 hog rings.
  2. Secure the front seat backrest cover upper tension straps. Pass through the backrest pad. Attach to the seat frame.
  3. Install the side air bag module. Attach the backrest cover. Tighten the new nuts to 7 Nm (5 lb.ft). Connect the electrical connector.
  4. Secure the front seat backrest cover central tension straps. Attach to the seat frame.
  5. Secure the front seat backrest cover lower retaining clips. Attach to the seat frame.
  6. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  7. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  8. Install the front seat backrest tilt handle trim panel. Install and tighten the Torx screws.
  9. Install the front seat backrest tilt handle. Install the screw.
  10. Install the front seat head restraint guide tube. Release from the seat frame. Secure in the seat frame.
  11. Install the front seat head restraint.
  12. Install the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .

Note. Removal steps in this procedure may contain installation details.

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  2. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  3. Torque: 3 Nm
  4. Torque: 5 Nm
  5. Torque: 3 Nm
  6. Torque: 5 Nm
  7. Torque: 9 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 22

Scheme 22: REMOVAL
Scheme 22: REMOVAL

Scheme 23

Scheme 23
Scheme 23
  1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  2. See «Front Seat Backrest Cover»(ref-574739-S24601174212013082800000) .
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 24

Scheme 24: REMOVAL
Scheme 24: REMOVAL
  1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
  2. See «Front Seat Backrest Cover»(ref-574739-S24601174212013082800000) .
  1. To install, reverse the removal procedure.

Scheme 25

Scheme 25: REMOVAL
Scheme 25: REMOVAL
  1. Remove the front door trim panel. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.
  2. Remove the front seat control switch. Remove the 4 Torx screws. Disconnect the electrical connector.
  1. Install the front seat control switch. Connect the electrical connector. Fit and tighten the Torx screws.
  2. Install the front door trim panel. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.

Scheme 26

Scheme 26: REMOVAL
Scheme 26: REMOVAL

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Remove the cover and disconnect the battery ground cable.
  2. Make the SRS system safe. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-574731-S00023799962013082800000) information.
  3. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  4. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  5. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  6. Remove the front seat hinge covers. Remove the 2 Torx screws. Remove the hinge cover retainers.
  7. Release the front seat backrest cover lower tension straps.
  8. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Release the Velcro strap. Release the 5 clips.
  9. Remove the front seat cushion cover. Remove the 27 hog rings.
  10. Using WDS, calibrate a new front seat cushion cover.
  1. Install the front seat cushion cover.
  2. Secure the front seat cushion assembly. Connect and secure the electrical connectors. Secure the Velcro strap. Attach the clips.
  3. Secure the front seat backrest cover lower tension straps.
  4. Install the front seat cushion outer trim panel. Connect the electrical connector. Secure in the clips.
  5. Secure the front seat cushion outer trim panel. Tighten the Torx screws.
  6. Install the front seat hinge covers. Attach the hinge cover retainers. Tighten the Torx screws.
  7. Install the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  8. Connect the battery ground cable and install the cover.

Scheme 30

Scheme 30
Scheme 30
  1. Make the SRS system safe. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-574731-S00023799962013082800000) information.
  2. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  3. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  4. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  5. Release the front seat lumbar assembly. Release the 3 electrical connectors. Remove the clip. Disconnect the electrical connector.
  6. Remove the front seat lumbar assembly.
  1. Install the front seat lumbar assembly.
  2. Secure the front seat lumbar assembly. Install the clip. Connect the electrical connector. Secure the electrical connectors.
  3. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  4. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  5. Install the front seat head restraint.
  6. Install the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  2. Make the SRS system safe. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-574731-S00023799962013082800000) information.
  3. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  4. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  5. Remove the front seat hinge cover. Remove the 2 Torx screws. Remove the hinge cover retainer.
  6. Remove the front seat backrest cover. See «Front Seat Backrest Cover»(ref-574739-S13480141592013082800000) .
  7. Remove the front seat backrest pad. Disconnect the electrical connector.
  8. Release the front seat lumbar assembly. Release the 3 electrical connectors. Remove the clip. Disconnect the electrical connector.
  9. Remove the front seat lumbar assembly.
  10. Release the front seat recliner motor. Remove the front seat backrest shaft clip. Remove the front seat backrest shaft.
  11. Remove the front seat recliner motor. Disconnect the electrical connector. Drill out the rivet.
  1. To install, reverse the removal procedure.

Scheme 33

Scheme 33: REMOVAL
Scheme 33: REMOVAL
  1. Remove the rear seat armrest. Release from the 4 clips.
  1. Install the rear seat armrest. Secure with the clips.

Scheme 34

Scheme 34: REMOVAL
Scheme 34: REMOVAL
  1. Remove the LH rear seat cushion. See «Rear Seat Cushion»(ref-574739-S17899454212013082800000) .
  2. Repeat the above procedure for the RH seat cushion.
  3. Remove the auxiliary junction box access cover. Release the clip.
  4. Remove the rear seat backrest. Remove the 2 Torx bolts. Release from the 2 retainers.
  1. Install the rear seat backrest. Secure in the retainers. Tighten the Torx bolt to 10 Nm (7 lb.ft).
  2. Install the auxiliary junction box access cover. Align the pegs and secure the clip.
  3. Install the LH rear seat cushion. See «Rear Seat Cushion»(ref-574739-S17899454212013082800000) . Secure with the clips.
  4. Install the RH rear seat cushion.

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Remove the rear seat armrest. See «Rear Seat Armrest»(ref-574739-S07509784782013082800000) .
  2. Remove the rear seat cushion. Release from the 2 clips.
  1. Install the rear seat cushion. Secure with the clips.
  2. Install the rear seat armrest. See «Rear Seat Armrest»(ref-574739-S07509784782013082800000) .

Scheme 36

Scheme 36
Scheme 36
  1. Remove the cover and disconnect the battery ground cable. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  2. Make the SRS system safe. Refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-574731-S00023799962013082800000) information.
  3. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  4. Release the front seat backrest cover lower tension straps. Release from the seat frame.
  5. Release the 9 front seat backrest cover rear panel retaining clips. Release from the backrest cover. Release from the seat frame.
  6. Release the 5 front seat backrest cover lower retaining clips. Release from the seat frame.
  7. Release the front seat backrest cover central tension straps. Release from the seat frame.
  8. Remove the front seat backrest heater mat. Disconnect the electrical connector.
  1. Install the front seat backrest heater mat.
  2. Secure the front seat backrest cover central tension straps. Attach to the seat frame.
  3. Secure the front seat backrest cover lower retaining clips. Attach to the seat frame.
  4. Secure the front seat backrest cover rear panel retaining clips. Attach to the seat frame. Attach to the backrest cover.
  5. Secure the front seat backrest cover lower tension straps. Attach to the seat frame.
  6. Connect the battery ground cable and install the cover. Refer to «SPECIFICATIONS»(ref-574738-S14876381072013082800000) information.
  1. Remove the cover and disconnect the battery ground cable.
  2. Make the SRS system safe. Refer to «Supplemental Restraint System (SRS) Health And Safety Precautions»(ref-574729-S16631063202013082800000) information.
  3. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  4. Release the front seat cushion outer trim panel. Remove the 2 Torx screws.
  5. Remove the front seat cushion outer trim panel. Release the 2 clips. Disconnect the electrical connector.
  6. Remove the front seat hinge covers. Remove the 2 Torx screws. Remove the hinge cover retainers.
  7. Release the front seat backrest cover lower tension straps.
  8. Remove the front seat cushion assembly. Release and disconnect the 2 electrical connectors. Release the Velcro strap. Release the 5 clips.
  9. Remove the front seat cushion cover. Remove the 27 hog rings.
  10. Remove the front seat cushion heater mat. Carefully release from the seat cushion pad.
  1. Install the front seat cushion heater mat. Secure to the seat cushion pad.
  2. Install the front seat cushion cover.
  3. Secure the front seat cushion assembly. Connect and secure the electrical connectors. Secure the Velcro strap. Attach the clips.
  4. Secure the front seat backrest cover lower tension straps.
  5. Install the front seat cushion outer trim panel. Connect the electrical connector. Secure in the clips.
  6. Secure the front seat cushion outer trim panel. Tighten the Torx screws.
  7. Install the front seat hinge covers. Attach the hinge cover retainers. Tighten the Torx screws.
  8. Install the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  9. Connect the battery ground cable and install the cover.
WARNINGTo avoid accidental deployment, the restraints control module backup power supply must be depleted. Wait at least one minute after disconnecting the battery ground cable(s) before commencing any repair or adjustment to the supplemental restraint system (SRS), or any component(s) adjacent to the SRS sensors. Failure to follow these instructions may result in personal injury.
WARNINGAlways wear safety glasses when working on an air bag equipped vehicle and when handling an air bag module. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, do not use radio key code savers when working on the supplemental restraint system. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of injury in the event of premature deployment, always carry a live air bag module with the bag and trim cover pointed away from the body. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, live air bag modules must only be placed on work benches which have been ground bonded and with the trim cover facing up. Failure to follow these instructions may result in personal injury.
WARNINGNever probe the electrical connectors of air bag modules or any other supplemental restraint system component. Failure to follow this instruction may result in personal injury.
WARNINGPainting over the driver air bag module trim cover or instrument panel could lead to deterioration of the trim cover and air bags. Do not for any reason attempt to paint discolored or damaged air bag module trim covers or instrument panel. Install a new component. Failure to follow this instruction may result in personal injury.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Removal steps in this procedure may contain installation details.

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-574729-S09216725292013082800000) information.
  2. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  3. Refer to «Front Safety Belt Buckle»(ref-574730-S17424607662013082800000) information.
  4. See «Front Seat Cushion Cover»(ref-574739-S22456497402013082800000) . .
  5. Torque: 35 Nm
  1. To install, reverse the removal procedure.

Scheme 41

Scheme 41: REMOVAL
Scheme 41: REMOVAL

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-574729-S09216725292013082800000) information.
  2. Remove the front seat. See «Front Seat»(ref-574739-S22456497402013082800000) . .
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Scheme 44

Scheme 44: DISASSEMBLY
Scheme 44: DISASSEMBLY

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51
  1. Remove the rear outer seat backrest.
  2. Remove the rear seat head restraint.
  3. Detach the rear seat head restraint retaining post.
  4. Remove the rear seat head restraint retaining post.
  5. Detach the rear seat outer backrest cover.
  6. Detach the rear seat backrest cover and cushion.
  7. Remove the rear seat backrest cover and cushion. Disconnect the rear seat backrest heater pad electrical connector.
  8. Disconnect the rear seat lumbar support electrical connector.
  9. Detach the rear seat lumbar support control valve.
  10. Remove the rear seat lumbar support.
  11. Disconnect the rear seat head restraint motor electrical connector.
  12. Remove the rear seat head restraint motor.

More articles — Seating
