Specifications Jaguar XKR II рестайлинг 2

Exhaust 2 illustrations
DescriptionNm
Catalytic converter retaining bolts40
Rear muffler support retaining bolts25
Exhaust securing strap nuts55
Exhaust support retaining bolts25

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: COMPONENT LOCATION - NATURALLY ASPIRATED VEHICLES
Scheme 1: COMPONENT LOCATION - NATURALLY ASPIRATED VEHICLES
Item NumberDescription
1Rear section
2Center section
3LH (left hand) front section
4RH (right hand) front section

Scheme 2

Scheme 2: COMPONENT LOCATION - SUPERCHARGER VEHICLES
Scheme 2: COMPONENT LOCATION - SUPERCHARGER VEHICLES
Item NumberDescription
1Rear section
2Active exhaust system
3LH front section
4RH front section
5Center section
