Audio Unit: Removal & Installation Jaguar XKR II рестайлинг 2

REMOVAL

Note. The component is situated in the passenger footwell. LHD is illustrated the procedure to remove the component on a RHD vehicle is similar.

Scheme 7

1. Remove the instrument panel assembly. Refer to «Instrument Panel»(ref-574770-S10277238402013082800000) information.
2. Remove the heater duct. Remove the 2 Torx screws. Release the lampholder.
3. Carefully release the carpet for access.
4. Remove the subwoofer cover. Remove the 4 bolts.
5. Disconnect the 2 electrical connectors. Carefully disconnect the MOST connector.
6. Remove the amplifier. Remove the 4 Torx screws.

INSTALLATION

1. Install the amplifier.
2. Connect the electrical connectors. Connect the MOST connector.
3. Install the subwoofer cover. Tighten the bolts to 10 Nm (7 lb.ft).
4. Install the carpet.
5. Install the heater duct. Install the Torx screws. Install the lampholder.
6. Install the instrument panel assembly. Refer to «Instrument Panel»(ref-574770-S10277238402013082800000) information.

Note. This component is easily recognized as a CD multichanger, it is however an audio module and links to the MOST.

Scheme 8

Scheme 9

1. Disconnect the battery ground cable. Refer to «Specifications»(ref-574769) information.
2. Remove the navigation screen module. Refer to «Navigation System Display Module»(ref-574775-S34907115872013082800000) information.
3. Release the audio/CD module and climatic control assembly. Remove the 4 module bracket Torx bolts.
4. Separate the climatic control and audio/CD module from the module bracket. Remove 2 Torx screws securing the navigation screen to the climatic control assembly. Remove the 4 Torx bolts.
5. Remove the CD unit. Remove the 2 Torx screws.

1. Carefully install the audio/CD module to the climatic control assembly. Tighten the Torx screws.
2. Install the climatic control assembly and audio/CD module to the module bracket. Install and tighten the navigation screen Torx screws. Install the CD module bracket Torx bolts and tighten to 6 Nm (4 lb.ft). Install the climatic control assembly Torx bolts and tighten to 6 Nm (4 lb.ft).
3. Install the navigation screen module. Refer to «Navigation System Display Module»(ref-574775-S34907115872013082800000) information.
4. Connect the battery ground cable. Refer to «Specifications»(ref-574769) information.
5. Connect WDS to the vehicle and configure a new module.

Note. This procedure is identical to the removal of the steering wheel speed control switch.

1. Remove the steering wheel switch assembly. Refer to «Speed Control Switch»(ref-574809) information.

1. To install, reverse the removal procedure. Refer to «Speed Control Switch»(ref-574809) information.

Note. Removal steps in this procedure may contain installation details.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Torque: 10 Nm

Scheme 14

1. To install, reverse the removal procedure.
