Module Communications Network: Removal & Installation Jaguar XKR II рестайлинг 2

INSTALLATION

1. Install the auxiliary junction box. Tighten the nuts to 10 Nm (7 lb.ft).
2. Secure the auxiliary junction box. Connect the electrical connectors. Tighten the battery positive lead nut to 10 Nm (7 lb.ft).
3. Secure the auxiliary junction box access cover. Secure in the clip.
4. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574769) information.

Scheme 16

Scheme 17

1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574769) information.
2. Remove the passenger side footwell trim panel. Remove the 3 clips.
3. Remove the cowl side trim panel. Remove the Torx screw. Remove the hood release lever. Release the forward edge of the scuff plate trim panel. Carefully release the clips.
4. Release the CJB. Release the battery positive cables.
5. Remove the CJB. Disconnect the 10 electrical connectors. Remove the 2 nuts.

1. Install the CJB. Disconnect the electrical connectors. Tighten the nuts to 10 Nm (7 lb.ft).
2. Secure the CJB. Attach the battery positive cables. Tighten the nut to 25 Nm (18 lb.ft).
3. Install the cowl side trim panel. Align the pegs and secure the clip. Install the scuff plate trim panel. Install the hood release lever and secure with the screw.
4. Install the passenger side footwell trim panel. Carefully secure the clips.
5. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574769) information.
6. Using WDS, configure a new CJB.
