Pedestrian Protection System: Removal & Installation Jaguar XKR II рестайлинг 2

Collision/avoidance 7 illustrations ~555 words

REMOVAL

Note. The pedestrian protection module must be renewed if the system has deployed on 3 occasions.

Scheme 2

Scheme 2: REMOVAL
Scheme 2: REMOVAL
  1. Make the pedestrian protection system safe.
  2. Remove the front LH fender splash shield. Refer to «Fender Splash Shield»(ref-574757-S31398307062013082800000) information.
  3. Remove the pedestrian protection module. Remove and discard the 2 Torx bolts. Disconnect the electrical connector.

INSTALLATION

  1. Install the pedestrian protection module. Connect the electrical connector. Tighten the new Torx bolts to 10 Nm (7 lb.ft).
  2. Install the front LH fender splash shield. Refer to «Fender Splash Shield»(ref-574757-S31398307062013082800000) information.
  3. Using WDS, configure a new module.

Note. Removal steps in this procedure may contain installation details.

Scheme 3

Scheme 3: REMOVAL
Scheme 3: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Front Bumper Cover»(ref-574782-S41721728072013082800000) information.
  3. Torque: 9 Nm
  1. To install, reverse the removal procedure.
  1. Remove the pedestrian protection hood actuator and bracket. Refer to «Pedestrian Protection Hood Actuator LH»(ref-574776-S09594499882013082800000) and «Pedestrian Protection Hood Actuator RH»(ref-574776-S41158195242013082800000) .
  2. Remove the pedestrian protection latch actuator. Remove and discard the 2 Torx bolts. Disconnect the electrical connector.
  1. Install the pedestrian protection latch actuator. Connect the electrical connector. Tighten the new Torx bolts to 9 Nm (7 lb.ft).
  2. Install the pedestrian protection hood actuator and bracket. Refer to «Pedestrian Protection Hood Actuator LH»(ref-574776-S09594499882013082800000) and «Pedestrian Protection Hood Actuator RH»(ref-574776-S41158195242013082800000) .

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5
  1. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.
  2. Remove the front bumper air ducting. Remove the 7 clips. Release the 4 clips.
  3. Remove the pedestrian protection accelerometer. Disconnect the electrical connector. Remove the 2 bolts.
  1. Install the pedestrian protection accelerometer. Tighten the 6 bolts to 10 Nm (7 lb.ft). Connect the electrical connector.
  2. Install the front bumper air ducting. Secure with the clips.
  3. Install the radiator splash shield. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL
  1. Make the pedestrian protection system safe.
  2. Remove the pollen filter. Refer to «Pollen Filter»(ref-574759-S33113340252013082800000) information.
  3. Release the power distribution box and position aside. Remove the 2 Torx screws.
  4. Release the pedestrian protection actuator bracket. Release the 3 wiring harness clips. Remove the 4 bolts.
  5. Remove the pedestrian protection actuator and bracket. Disconnect the electrical connector.
  6. Remove the pedestrian protection actuator. Remove and discard the 4 Torx bolts.
  1. Install the pedestrian protection actuator. Tighten the new Torx bolts to 8 Nm (6 lb.ft).
  2. Install the pedestrian protection actuator and bracket. Connect the electrical connector.
  3. Secure the pedestrian protection actuator bracket. Attach the wiring harness clips. Tighten the bolts to 8 Nm (6 lb.ft).
  4. Position and install the power distribution box. Tighten the Torx bolts to 8 Nm (6 lb.ft).
  5. Install the pollen filter. Refer to «Pollen Filter»(ref-574759-S33113340252013082800000) information.

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8
  1. Make the pedestrian protection system safe. Refer to «Supplemental Restraint System (SRS) Health and Safety Precautions»(ref-574729-S16631063202013082800000) information.
  2. Remove the air intake cover. Remove the 3 clips.
  3. Release the pedestrian protection actuator bracket. Release the 3 wiring harness clips. Remove the 4 bolts.
  4. Remove the pedestrian protection actuator and bracket. Disconnect the electrical connector.
  5. Remove the pedestrian protection actuator. Remove and discard the 4 Torx bolts.
  1. Install the pedestrian protection actuator. Tighten the new Torx bolts to 8 Nm (6 lb.ft).
  2. Install the pedestrian protection actuator and bracket. Connect the electrical connector.
  3. Secure the pedestrian protection actuator bracket. Attach the wiring harness clips. Tighten the bolts to 8 Nm (6 lb.ft).
  4. Install the air intake cover. Carefully secure the clips.
