CONTROL DIAGRAM
| Item Number | Description |
|---|---|
| 1 | SDARS Antenna (where fitted) |
| 2 | VICS beacon antenna (Japan) |
| 3 | GPS antenna |
| 4 | Integrated audio module |
| 5 | AM/FM electric antenna |
| 6 | FM antenna signal splitter |
| 7 | Navigation computer |
| 8 | Telephone control module |
| 9 | Bluetooth antenna |
| 10 | SDARS module |
Note. A=Hardwired; P=MOST; T=Coaxial
| Item Number | Description |
|---|---|
| 1 | SDARS Antenna (where fitted) |
| 2 | VICS beacon antenna (Japan) |
| 3 | GPS antenna |
| 4 | Integrated audio module |
| 5 | AM/FM antenna amplifier |
| 6 | FM antenna signal splitter |
| 7 | Navigation computer |
| 8 | Telephone control module |
| 9 | Bluetooth antenna |
| 10 | AM/FM antenna |
| 11 | SDARS module |
Note. A=Hardwired; P=MOST; T=Coaxial
Refer to Audio System article.
Scheme 1
Scheme 2
- Remove the RH rear quarter trim panel.
- Raise the vehicle on the lift.
- Release the antenna. Remove the 2 nuts.
- Lower the vehicle.
- Remove the antenna. Disconnect the antenna cable. Disconnect the electrical connector. Disconnect the antenna earth strap.
