Control Components: Removal & Installation Jaguar XKR I facelift

A/c Compressor 5 illustrations ~293 words

Installation

  1. Installation is a reversal of the removal procedure.

Scheme 2

Scheme 2: Removal
Scheme 2: Removal
  1. Remove battery cover and disconnect ground cable from battery terminal. Refer to BATTERY GROUND CABLE - REMOVAL AND INSTALLATION .
  2. Remove 'J' gate surround. Refer to SELECTOR LEVER CABLE AND BRACKET - REMOVAL AND INSTALLATION .
  3. Remove center console. Refer to FLOOR CONSOLE - REMOVAL AND INSTALLATION .
  4. Remove radio console securing screws and position console for access.
  5. Disconnect air conditioning control module harness multi-plug and cut and remove securing tie strap.
  6. Remove remaining switch control module central securing screw and withdraw module from vehicle.
  1. Position air conditioning switch control module on radio console and install module securing screws.
  2. Connect switch control module harness multi-plug.
  3. Install new harness securing tie strap.
  4. Position radio and install console securing screws.
  5. Install center console. Refer to FLOOR CONSOLE - REMOVAL AND INSTALLATION .
  6. Install 'J' gate surround. Refer to SELECTOR LEVER CABLE AND BRACKET - REMOVAL AND INSTALLATION .
  7. Connect ground cable to battery terminal and install battery cover. Refer to BATTERY CONNECT - GENERAL PROCEDURES .

Scheme 3

Scheme 3: Removal
Scheme 3: Removal
  1. Remove instrument panel for access.
  2. Remove motor from heater / cooler assembly. Remove connector. Remove screws. Remove motor.
  1. Installation is a reversal of the removal procedure.

Scheme 4

Scheme 4: Removal
Scheme 4: Removal
  1. Remove air distribution box.
  2. Remove motor from air distribution box. Remove connector. Remove screws. Remove motor.
  1. Installation is a reversal of the removal procedure.

Scheme 5

Scheme 5: Removal
Scheme 5: Removal
  1. Remove instrument panel for access.
  2. Remove motor from heater / cooler assembly. Remove connector. Remove screws. Remove motor complete with bracket. Remove motor.
  1. Installation is a reversal of the removal procedure.

Scheme 6

Scheme 6: Removal
Scheme 6: Removal
  1. Remove air distribution box.
  2. Remove motor from air distribution box. Remove connector. Remove screws. Remove motor.
  1. Installation is a reversal of the removal procedure.
