Intake Air Distribution and Filtering: Specifications Jaguar XKR I рестайлинг

Mechanical 2 illustrations ~339 words

Specifications

DescriptionNm
Air cleaner retaining bolt8
Charge air cooler intake assembly retaining bolts21
Supercharger outlet pipe to charge air cooler intake assembly retaining bolts21
Supercharger outlet pipe retaining bolts10
Supercharger retaining bolts24
Throttle body elbow retaining bolts24
Throttle body elbow lower retaining bracket retaining bolts20
Exhaust gas recirculation (EGR) valve retaining bolts10
Exhaust manifold to EGR valve tube retaining bolts21
Exhaust manifold to EGR valve tube retaining nuts21
Thermostat housing retaining bolts10
Throttle body intake hose retaining clip5

Torque Specifications

Scheme 1

Scheme 1: Intake Air Distribution and Filtering - Description & Operation
Item NumberDescription
1Air cleaner outlet pipe
2Air cleaner
3Additional air inlet actuator - vehicles fitted with supercharger
4Air cleaner intake pipe

Scheme 2

Scheme 2
Item NumberDescription
1Charge air cooler
2Throttle body elbow
3Charge air cooler
4Supercharger outlet pipe
5Supercharger

Air is supplied to the supercharger via the air cleaner intake pipe, air cleaner, air cleaner outlet pipe, throttle body and throttle body elbow. The supercharger delivers pressurized air to two separate charge air coolers, each being mounted on the cylinders it supplies. Pressurized cooled air is fed from the charge air coolers directly into each intake port. The air cleaner outlet pipe differs from the normally aspirated by having tuned resonators to reduce intake air noise levels. An intake air temperature (IAT) sensor is fitted at the outlet of the right-hand charge air cooler. The IAT sensor provides an input to the engine control module (ECM). Refer to Electronic Engine Controls . The intake elbow directs the metered airflow from the throttle body outlet (underside of the throttle body) into the intake of the supercharger. The supercharger by-pass valve assembly is part of the intake elbow. The butterfly valve inside the assembly is opened by a diaphragm actuator operated by vacuum feed from the elbow. At closed or partially open throttle positions, the butterfly valve opens, allowing the airflow from the two charge air cooler inlets to be directed back to the supercharger inlet. This action inhibits the supercharging effect and reduces engine torque. Progressive opening of the throttle causes the by-pass valve to gradually close.

Supercharger

The supercharger is attached to the three mounting bosses between the two cylinder heads. The supercharger has a filled for life internal lubrication system. The supercharger is positively aligned with the drive belt by a doweled mounting bracket.

Charge Air Cooler

Each cylinder bank is fitted with a charge air cooler which supplies pressurized air to the four cylinders. The intake ports to the two charge air coolers are connected to the supercharger via the supercharger outlet pipe consisting of adjustable metal ducts with bonded rubber seals. The charge air coolers are water cooled via a radiator and water pump. Refer to Engine Cooling or Supercharger Cooling .
