Interior Lighting: Removal & Installation Jaguar XKR I рестайлинг

Installation

1. Position guard lamp on door casing.
2. Install securing screws.
3. Install door casing. Refer to «DOOR TRIM PANEL - REMOVAL AND INSTALLATION»(ref-311064-S03084659962009032300000) .

Scheme 2

1. Using a small flat-bladed screwdriver, release guard lamp lens retaining tang and withdraw lens from door.
2. Rotate bulb 1/4 turn and remove bulb from guard lamp.

1. Install bulb in guard lamp and rotate 1/4 turn to engage.
2. Install lens on guard lamp, ensuring that securing tang is correctly engaged

Scheme 3

1. Remove battery cover and disconnect ground cable from battery terminal. Refer to «BATTERY GROUND CABLE - REMOVAL AND INSTALLATION»(ref-311034-S13267168892009032300000) .
2. Remove 'J' gate surround. Refer to «SELECTOR LEVER CABLE AND BRACKET - REMOVAL AND INSTALLATION»(ref-311060-S32835138532009032300000) .
3. Remove center console for access. Refer to «FLOOR CONSOLE - REMOVAL AND INSTALLATION»(ref-311041-S21848229192009032300000) .
4. Remove radio console for access. Refer to «AUDIO UNIT HOUSING - REMOVAL AND INSTALLATION»(ref-311041-S22727899652009032300000) .
5. Disconnect switch module harness multiplug, release module end locators and lightly press module out of console.
6. Rotate bulb holder 1/4 turn counter-clockwise and remove from module.
7. Remove bulb from holder.

1. Install bulb in holder.
2. Install bulb and holder in module and rotate 1/4 turn clockwise to fully seat.
3. Install switch module in console ensuring that end locators are fully seated.
4. Connect switch module harness multiplug.
5. Install radio console. Refer to «AUDIO UNIT HOUSING - REMOVAL AND INSTALLATION»(ref-311041-S22727899652009032300000) .
6. Install center console. Refer to «FLOOR CONSOLE - REMOVAL AND INSTALLATION»(ref-311041-S21848229192009032300000) .
7. Install 'J' gate surround. Refer to «SELECTOR LEVER CABLE AND BRACKET - REMOVAL AND INSTALLATION»(ref-311060-S32835138532009032300000) .
8. Connect ground cable to battery terminal and install battery cover. Refer to «BATTERY CONNECT - GENERAL PROCEDURES»(ref-311034-S33760101132009032300000) .

Scheme 4

1. Remove the footwell Lamp. Use a screwdriver with a wide flat blade to push the lamp assembly towards the front of the car. This movement will release the rear spring clip which is adjacent to the screwdriver blade. Release the front spring clip of the lamp by pulling the lamp rearwards. Remove the lamp from the aperture.
2. Turn the lamp through 90° to allow the connector to pass through the aperture, tilt it slightly and fully remove it.
3. Disconnect the harness connector and remove the lamp.
4. If required, remove the bulb holder and replace the bulb.

1. Installation is the reverse of removal. Install the new lamp so that the face marked 'REAR' is towards the rear of the vehicle; failure to do this will make the lamp very difficult to remove.

Removal

1. Remove the footwell Lamp. Use a screwdriver with a wide flat blade to push the lamp assembly towards the front of the car. This movement will release the rear spring clip which is adjacent to the screwdriver blade. Release the front spring clip of the lamp by pulling the lamp rearwards. Remove the lamp from the aperture.
2. Turn the lamp through 90° to allow the connector to pass through the aperture, tilt it slightly and fully remove it.
3. Disconnect the harness connector and remove the lamp.
4. If required, remove the bulb holder and replace the bulb.

1. Installation is the reverse of removal. Install the new lamp so that the face marked 'REAR' is towards the rear of the vehicle; failure to do this will make the lamp very difficult to remove.

Scheme 5

Scheme 6

1. Power front seat fully forward.
2. Carefully withdraw interior lamp assembly from headlining
3. Disconnect harness multiplug and remove lamp assembly.

1. Ensure that interior lamp finisher is correctly positioned on headlining.
2. Position lamp assembly at headlining and connect harness multriplug.
3. Install lamp assembly in finisher.
4. Return front seat to original position.

Scheme 7

Scheme 8

Scheme 9

1. Open glove box lid.
2. Carefully release and remove plastic lens from glove box light.
3. Remove bulb from glove box light.
4. Release light/switch assembly retaining tangs and partially withdraw assembly from glove box exterior.
5. Position light/switch assembly for access, disconnect harness spade connectors and remove assembly from glove box aperture.

1. Position light/switch assembly at glove box aperture and connect harness spade connectors.
2. Install light/switch assembly in aperture, ensuring that retaining tangs are fully seated.
3. Install bulb in light/switch assembly.
4. Check that harness leads are not in contact with the bulb glass.
5. Install plastic lens on light/switch assembly.
6. Close glove box lid.

Scheme 10

1. Remove the bulb from the glove box lamp. With the glove box lid open, carefully pry away the lens. Working through the lens aperture, carefully remove the bulb.

1. Installation is the reverse of removal.

Scheme 11

1. Open trunk lid.
2. Using a thin plastic lever, carefully release lamp retaining tangs from trunk rear finisher.
3. Withdraw lamp for access and disconnect harness.

1. Position lamp for access and connect harness multiplug.
2. Install and fully seat lamp assembly on trunk rear finisher ensuring that retaining tangs correctly engage.
3. Close trunk lid.

Scheme 12

Scheme 13

1. Carefully pry the lamp from the luggage compartment trim panel.
2. Remove the bulb. Squeeze the lens retaining lugs, located one each side of the bulb, and remove the lens. Remove the bulb.

1. Installation is the reverse of removal.

Scheme 14

Scheme 15

1. Remove the roof console. Very carefully pry the console from the roof trim panel.
2. Remove the bulb from the console. Remove the relevant bulb holder. Remove the bulb.

1. Installation is the reverse of removal.

Scheme 16

1. Remove the lamp from the roof. Carefully pry one side of the lamp assembly from the roof panel. Lower the lamp assembly.
2. Remove the bulb from the roof lamp. Squeeze the lens retaining lugs, located one each side of the bulb, and remove the lens. Remove the bulb.

1. Installation is the reverse of removal.

Scheme 17

Scheme 18

Scheme 19

1. Move sun visor to downward position and turn mirror cover upwards.
2. Using a small screwdriver or similar thin blade, carefully release illumination lens lower tangs and remove both lenses from mirror assembly.
3. Using a small screwdriver or similar thin blade, carefully release side tangs and remove mirror assembly from base.

1. Ensure that bulbs, bulb holders and switch contractors are correctly positioned and seated.
2. Position mirror assembly on base and press firmly at each side to fully engage tangs.
3. Fit and fully seat mirror illumination lenses.
4. Turn mirror cover downwards and reposition sun visor upwards.

Scheme 20

Scheme 21

1. Rotate the sun visor down and open the vanity mirror flap.
2. Remove the mirror / lens assembly. Use a flat screwdriver to very carefully pry the mirror / lens assembly from the visor.
3. Remove the bulb from the vanity mirror lamp(s). Remove the bulb(s) from the holder.

1. Installation is the reverse of removal.
