Interior Lighting: Removal & Installation Jaguar XKR I

Interior/illumination Lights 23 illustrations ~1187 words

Installation

  1. Position guard lamp on door casing.
  2. Install securing screws.
  3. Install door casing. Refer to «DOOR TRIM PANEL»(ref-198049-S08318676492005101500000) .

Scheme 2

Scheme 2: Removal
Scheme 2: Removal
  1. Using a small flat-bladed screwdriver, release guard lamp lens retaining tang and withdraw lens from door. see scheme 2: Removing Lens From Door
  2. Rotate bulb 1/4 turn and remove bulb from guard lamp.
  1. Install bulb in guard lamp and rotate 1/4 turn to engage.
  2. Install lens on guard lamp, ensuring that securing tang is correctly engaged

Scheme 3

Scheme 3: Removal
Scheme 3: Removal

Scheme 4

Scheme 4
Scheme 4
  1. Remove battery cover and disconnect ground cable from battery terminal. Refer to «BATTERY DISCONNECTION PROCEDURE»(ref-171253-S19302448882005020100000).
  2. Remove 'J' gate surround. Refer to «FLOOR CONSOLE FINISH PANEL»(ref-198054-S41372053992005101500000).
  3. Remove center console for access. Refer to «FLOOR CONSOLE»(ref-198054-S41022631022005101500000).
  4. Remove radio console for access. Refer to «AUDIO UNIT HOUSING»(ref-198054-S35383443072005101500000).
  5. Disconnect switch module harness multiplug, release module end locators and lightly press module out of console. (Scheme 2): Releasing Module End Locators
  6. Rotate bulb holder 1/4 turn counter-clockwise and remove from module. (Scheme 3): Removing Door Lock Control Switch Bulbs
  7. Remove bulb from holder.
  1. Install bulb in holder.
  2. Install bulb and holder in module and rotate 1/4 turn clockwise to fully seat.
  3. Install switch module in console ensuring that end locators are fully seated.
  4. Connect switch module harness multiplug.
  5. Install radio console. Refer to «AUDIO UNIT HOUSING»(ref-198054-S35383443072005101500000)
  6. Install center console. Refer to «FLOOR CONSOLE»(ref-198054-S41022631022005101500000)
  7. Install 'J' gate surround. Refer to «FLOOR CONSOLE FINISH PANEL»(ref-198054-S41372053992005101500000) .
  8. Connect ground cable to battery terminal and install battery cover. Refer to «BATTERY RECONNECTION PROCEDURE»(ref-171253-S14708357522005020100000) .

Scheme 5

Scheme 5: Removal
Scheme 5: Removal
  1. Remove the footwell Lamp. Use a screwdriver with a wide flat blade to push the lamp assembly towards the front of the car. This movement will release the rear spring clip which is adjacent to the screwdriver blade. Release the front spring clip of the lamp by pulling the lamp rearwards. Remove the lamp from the aperture. (Scheme 4): Releasing Front Spring Clip Of Lamp
  2. Turn the lamp through 90°to allow the connector to pass through the aperture, tilt it slightly and fully remove it.
  3. Disconnect the harness connector and remove the lamp.
  4. If required, remove the bulb holder and replace the bulb.
  1. Installation is the reverse of removal. Install the new lamp so that the face marked 'REAR' is towards the rear of the vehicle; failure to do this will make the lamp very difficult to remove.

Scheme 6

Scheme 6: Removal
Scheme 6: Removal
  1. Remove the footwell Lamp. Use a screwdriver with a wide flat blade to push the lamp assembly towards the front of the car. This movement will release the rear spring clip which is adjacent to the screwdriver blade. Release the front spring clip of the lamp by pulling the lamp rearwards. Remove the lamp from the aperture. (Scheme 5): Releasing Front Spring Clip Of Lamp
  2. Turn the lamp through 90° to allow the connector to pass through the aperture, tilt it slightly and fully remove it.
  3. Disconnect the harness connector and remove the lamp.
  4. If required, remove the bulb holder and replace the bulb.
  1. Installation is the reverse of removal. Install the new lamp so that the face marked 'REAR' is towards the rear of the vehicle; failure to do this will make the lamp very difficult to remove.

Scheme 7

Scheme 7: Removal
Scheme 7: Removal

Scheme 8

Scheme 8
Scheme 8
  1. Power front seat fully forward.
  2. Carefully withdraw interior lamp assembly from headlining (Scheme 6): Removing Interior Lamp Assembly From Headlining
  3. Disconnect harness multiplug and remove lamp assembly. (Scheme 7): Disconnecting Harness Multiplug
  1. Ensure that interior lamp finisher is correctly positioned on headlining.
  2. Position lamp assembly at headlining and connect harness multriplug.
  3. Install lamp assembly in finisher.
  4. Return front seat to original position.

Scheme 9

Scheme 9: Removal
Scheme 9: Removal

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Open glovebox lid.
  2. Carefully release and remove plastic lens from glovebox light. (Scheme 8): Removing Plastic Lens From Glovebox Light
  3. Remove bulb from glovebox light.
  4. Release light/switch assembly retaining tangs and partially withdraw assembly from glovebox exterior. (Scheme 9): Releasing Light/Switch Assembly Retaining Tangs
  5. Position light/switch assembly for access, disconnect harness spade connectors and remove assembly from glovebox aperture. (Scheme 10): Disconnecting Harness Spade Connectors
  1. Position light/switch assembly at glovebox aperture and connect harness spade connectors.
  2. Install light/switch assembly in aperture, ensuring that retaining tangs are fully seated.
  3. Install bulb in light/switch assembly.
  4. Check that harness leads are not in contact with the bulb glass.
  5. Install plastic lens on light/switch assembly.
  6. Close glovebox lid.

Scheme 12

Scheme 12: Removal
Scheme 12: Removal
  1. Remove the bulb from the glovebox lamp. With the glovebox lid open, carefully prise away the lens (1). Working through the lens aperture, carefully remove the bulb (2). (Scheme 11): Removing Bulb From Glovebox Lamp
  1. Installation is the reverse of removal.

Scheme 13

Scheme 13: Removal
Scheme 13: Removal

Scheme 14

Scheme 14
Scheme 14
  1. Open trunk lid.
  2. Using a thin plastic lever, carefully release lamp retaining tangs from trunk rear finisher. (Scheme 12): Releasing Lamp Retaining Tangs From Trunk Rear Finisher
  3. Withdraw lamp for access and disconnect harness. (Scheme 13): Disconnecting Harness
  1. Position lamp for access and connect harness multiplug.
  2. Install and fully seat lamp assembly on trunk rear finisher ensuring that retaining tangs correctly engage.
  3. Close trunk lid.

Scheme 15

Scheme 15: Removal
Scheme 15: Removal

Scheme 16

Scheme 16
Scheme 16
  1. Carefully prise the lamp from the luggage compartment trim panel. (Scheme 14): Removing Lamp From Luggage Compartment Trim Panel
  2. Remove the bulb. Squeeze the lens retaining lugs, located one each side of the bulb, and remove the lens (1). Remove the bulb (2). (Scheme 15): Removing Bulb
  1. Installation is the reverse of removal.

Scheme 17

Scheme 17: Removal
Scheme 17: Removal

Scheme 18

Scheme 18
Scheme 18
  1. Remove the roof console. Very carefully prise the console from the roof trim panel. (Scheme 16): Removing Roof Console
  2. Remove the bulb from the console. Remove the relevant bulb holder. Remove the bulb. (Scheme 17): Removing Bulb From Console
  1. Installation is the reverse of removal.

Scheme 19

Scheme 19: Removal
Scheme 19: Removal
  1. Remove the lamp from the roof. Carefully prise one side of the lamp assembly from the roof panel. Lower the lamp assembly.
  2. Remove the bulb from the roof lamp. Squeeze the lens retaining lugs, located one each side of the bulb, and remove the lens (1). Remove the bulb (2). (Scheme 18): Removing Bulb From Roof Lamp
  1. Installation is the reverse of removal.

Scheme 20

Scheme 20: Removal
Scheme 20: Removal

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Move sun visor to downward position and turn mirror cover upwards. (Scheme 19): Positioning Sun Visor
  2. Using a small screwdriver or similar thin blade, carefully release illumination lens lower tangs and remove both lenses from mirror assembly. (Scheme 20): Removing Both Lenses From Mirror Assembly
  3. Using a small screwdriver or similar thin blade, carefully release side tangs and remove mirror assembly from base. (Scheme 21): Removing Mirror Assembly From Base
  1. Ensure that bulbs, bulb holders and switch contactors are correctly positioned and seated.
  2. Position mirror assembly on base and press firmly at each side to fully engage tangs.
  3. Fit and fully seat mirror illumination lenses.
  4. Turn mirror cover downwards and reposition sun visor upwards.

Scheme 23

Scheme 23: Removal
Scheme 23: Removal

Scheme 24

Scheme 24
Scheme 24
  1. Rotate the sun visor down and open the vanity mirror flap.
  2. Remove the mirror/lens assembly. Use a flat screwdriver to very carefully prise the mirror / lens assembly from the visor. (Scheme 22): Removing Mirror/Lens Assembly
  3. Remove the bulb from the vanity mirror lamp(s). Remove the bulb(s) from the holder. (Scheme 23): Removing Bulb(s) From Holder
  1. Installation is the reverse of removal.
