Specifications
| Component | Nm |
|---|---|
| Bolt M12 - Jurid flexible coupling to transmission flange | 75-88 |
| Bolt M10 - Driveshaft to final drive unit flange | 51-69 |
TORQUES SPECIFICATIONS
The one-piece aluminum driveshaft incorporates a flexible (Jurid) drive coupling at the transmission flange, a sliding joint aft of the transmission and a Hookes joint at the differential.
The drive couplings and sliding joint allow for variations in the driveshaft alignment due to the relative movement of components.
Scheme 1
Example
- Using a torque wrench 330 mm (0,33 m) long and an adaptor 50mm (0,05 m) long, calculate as follows for a specified torque of 60Nm: RS = (0,33 x 60) / (0,33 + 0,05) = 52,1Nm
