Electronic Engine Controls (V8 5.0L Petrol): Removal & Installation Jaguar XK II facelift

Engine Control Systems 33 illustrations ~943 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Thermostat Housing - Vehicles With: Supercharger information.
  3. Refer to Thermostat Housing - Vehicles Without: Supercharger information.
  4. Torque: 10 Nm

INSTALLATION

  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 5

Scheme 5: REMOVAL
Scheme 5: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Thermostat Housing - Vehicles With: Supercharger information.
  3. Refer to Thermostat Housing - Vehicles Without: Supercharger information.
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Air Deflector information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to Powertrain Control Module (PCM) Long Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 10

Scheme 10: REMOVAL
Scheme 10: REMOVAL

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Air Deflector information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to Powertrain Control Module (PCM) Long Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 13

Scheme 13: REMOVAL
Scheme 13: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Air Deflector - 5.0L information.
  3. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Scheme 14

Scheme 14: REMOVAL
Scheme 14: REMOVAL

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. Refer to Battery Disconnect and Connect information.
  2. Torque: 10 Nm
  3. Torque: 10 Nm
  4. Torque: 6 Nm
  5. Torque: 7 Nm
  6. Torque: 9 Nm
  1. To install, reverse the removal procedure.
  2. Configure the engine control module (ECM) using the diagnostic tool.

Note. Removal steps in this procedure may contain installation details.

Scheme 19

Scheme 19: REMOVAL
Scheme 19: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Engine Cover - 5.0L information.
  3. Refer to Cooling System Draining and Vacuum Filling - Vehicles Without: Supercharger information.
  4. Lift the tang and rotate the engine coolant temperature (ECT) sensor counter-clockwise.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 20

Scheme 20: REMOVAL
Scheme 20: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Air Deflector - 5.0L information.
  3. Refer to Engine Oil Draining And Filling information.
  4. Torque: 11 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 21

Scheme 21: REMOVAL
Scheme 21: REMOVAL
  1. Refer to Battery Disconnect and Connect information.
  2. Refer to Intake Manifold information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 22

Scheme 22: REMOVAL
Scheme 22: REMOVAL
  1. Refer to Battery Disconnect and Connect information.
  2. Refer to Intake Manifold information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.
WARNINGRefer to Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions information.

Note. Removal steps in this procedure may contain installation details.

Scheme 23

Scheme 23
Scheme 23
  1. Refer to Fuel System Pressure Release - 5.0L information.
  2. Refer to Engine Cover - 5.0L information.
  3. Torque: 32 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 24

Scheme 24: REMOVAL
Scheme 24: REMOVAL

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Air Deflector information.
  4. Refer to Catalytic Converter information.
  5. Wrench, H02S (310-121) Torque: 48
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to Powertrain Control Module (PCM) Long Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 27

Scheme 27: REMOVAL
Scheme 27: REMOVAL

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Air Deflector information.
  4. Refer to Catalytic Converter RH information.
  5. Wrench, H02S (310-121) Torque: 48
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to Powertrain Control Module (PCM) Long Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 30

Scheme 30: REMOVAL
Scheme 30: REMOVAL
  1. Refer to Engine Cover - 5.0L information.
  2. Torque: 5 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to Powertrain Control Module (PCM) Short Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to Air Cleaner RH information.
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to Powertrain Control Module (PCM) Short Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 32

Scheme 32: REMOVAL
Scheme 32: REMOVAL
  1. Refer to Battery Disconnect and Connect information.
  2. Refer to Intake Manifold information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 33

Scheme 33: REMOVAL
Scheme 33: REMOVAL
  1. Refer to Battery Disconnect and Connect information.
  2. Refer to Intake Manifold information.
  3. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 34

Scheme 34: REMOVAL
Scheme 34: REMOVAL

Scheme 35

Scheme 35
Scheme 35
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Thermostat Housing - Vehicles With: Supercharger information.
  4. Refer to Thermostat Housing - Vehicles Without: Supercharger information.
  5. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to Powertrain Control Module (PCM) Short Drive Cycle Self-Test information.

Note. Removal steps in this procedure may contain installation details.

Scheme 36

Scheme 36: REMOVAL
Scheme 36: REMOVAL
  1. Refer to Battery Disconnect and Connect information.
  2. Raise and support the vehicle.
  3. Refer to Thermostat Housing - Vehicles With: Supercharger information.
  4. Refer to Thermostat Housing - Vehicles Without: Supercharger information.
  5. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to Powertrain Control Module (PCM) Short Drive Cycle Self-Test information.
