CONTROL DIAGRAM
Note. A = Hardwired; D = High speed controller area network (CAN) bus.
Scheme 11
| Item Number | Description |
|---|---|
| 1 | Battery |
| 2 | BJB (battery junction box) (175 A megafuse x 2) |
| 3 | CJB (central junction box) |
| 4 | AJB (auxiliary junction box) |
| 5 | Electric steering column lock (all except NAS vehicles) |
| 6 | High speed CAN connection to other systems |
| 7 | Rake adjustment solenoid and potentiometer |
| 8 | Reach adjustment solenoid and potentiometer |
| 9 | Steering column adjustment motor |
| 10 | Instrument cluster |
| 11 | Steering column adjustment switch |
For additional information, Refer to Steering System - General Information information. .
Special Tools
211-326 Clockspring locking tool 501-106 Driver air bag module remover
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
Scheme 19
Scheme 20
Scheme 21
Scheme 22
- Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
- Make the SRS system safe.
- Remove the instrument panel lower trim panel. Refer to «Instrument Panel Lower Trim Panel»(ref-574770-S27488087262013082800000) information.
- Remove the steering column lower cowl. Remove the 2 screws. If installed, disconnect the steering column and foot pedal control switch electrical connector.
- Check the road wheels are in the straight ahead position, then remove the steering column universal joint upper clamp bolt.
- Release the steering column. Loosen but do not remove the 4 nuts.
- Remove the steering column upper cowl. Remove the 3 screws.
- Disconnect the upper steering column wiring harness connections. Disconnect the 6 electrical connectors. Release the 3 wiring harness clips.
- Disconnect the steering angle sensor electrical connector. Release the 3 clips.
- Remove the steering column. Remove the 4 nuts.
- Using the special tool, remove the driver air bag module. Rotate the steering wheel for access to slots. Carefully release the 2 clips. Disconnect the 3 electrical connectors.
- Remove the steering wheel. Disconnect the electrical connector. Loosen, but do not fully remove the bolt. Release the steering wheel from the spline. Remove the bolt. Release the electrical harness.
- Install the special tool to the clockspring.
- Remove the clockspring. Remove the 4 Torx bolts.
- Remove the steering angle sensor. Remove the 2 bolts. Remove the reluctor ring.
STEERING WHEEL
Special Tools
211-326 Clockspring locking tool
Scheme 23
Scheme 24
Scheme 25
- Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
- Make the SRS system safe.
- Remove the driver air bag module. Refer to «Driver Air Bag Module»(ref-574731-S05491284792013082800000) information.
- Remove the steering wheel. Disconnect the electrical connector. Loosen, but do not fully remove the bolt. Release the steering wheel from the spline. Remove the bolt. Release the electrical harness.
- Install the special tool to the clockspring.
- Remove the upshift and downshift paddle switches. Remove the Torx bolt. Release the assembly. Disconnect the electrical connector. Repeat the procedure and remove the opposite hand.
- Remove the steering wheel switch assembly. Remove the Torx bolt. Disconnect the electrical connectors. Repeat the procedure and remove the opposite hand.
- Remove the air bag housing. Remove the 4 Torx bolts. Release the electrical harness.
- Remove the air bag ground cable. Remove the Torx screw.
CLOCKSPRING
Special Tools
211-326 Clockspring locking tool
