Fuses & Circuit Breakers: Other Jaguar XJR III

Fuses & Circuit Breakers 6 illustrations ~115 words

ENGINE COMPARTMENT

The engine compartment fuse box is located on the right-hand side adjacent to the windscreen wash reservoir. (Scheme 1)

Scheme 1

Scheme 1: ENGINE COMPARTMENT
Scheme 1: ENGINE COMPARTMENT

Scheme 2

Scheme 2
Scheme 2
Fuse No.AmpsFuse Function
F15AFront ignition, UHEGO, fuel pump, rear ignition relay coils
F210AThrottle (petrol engine only)
F35ADSC ECU
F430APowerwash pump
F5Not used
F640AAir suspension compressor
F740ARight-hand front screen heater or wiper park zone heater
F820ARight-hand dipped beam
F920ALeft-hand dipped beam
F1015AHorns
F11Not used
F1210AEngine control module
F1310AFuel injectors
F1410APurge valve, EGR valve, DMTL, V6 intake manifold tuning valves (IMTV), MAFS, air filter solenoid, radiator fan controller
F15Not used
F1620ARight-hand main beam, left-hand main beam
F1710AEngine control module, transmission control module
F1815AFront fog lights, instrument cluster front fog status
F1925AStarter solenoid
F2030AABS module (pump)
F21Not used
F2215AABS module
F23Not used
F2420AIntercooler water pump (supercharged engines)
F25Not used
F2640AWiper system, front electronics module (FEM)
F275ASecondary air injection
F28Not used
F29Not used
F3015AIgnition coils
F3115ANot used
F3240ALeft-hand front screen heater
F3330AB bank heated oxygen sensors
F3430AA bank heated oxygen sensors
F3580ARadiator cooling fan

Engine Compartment Fuse Box

PASSENGER COMPARTMENT

The passenger compartment fuse box is located on the right-hand side trim panel in the footwell. (Scheme 3)

Scheme 3

Scheme 3: PASSENGER COMPARTMENT
Scheme 3: PASSENGER COMPARTMENT

Scheme 4

Scheme 4
Scheme 4
Fuse No.AmpsFuse Function
F110AClimate control unit, fan, screen heaters and wiper relay coils, smog sensor
F25ACruise control switch, adaptive cruise control
F35ARear outer seat, electrochromic mirror, driver seat heater, electric parkbrake, left-hand and right-hand HID lamps levelling, left-hand and right-hand seat belt switches, passenger seat heater switch, rear seat heater switchpack
F45AInstrument cluster
F5Not used
F6Not used
F75ACigar lighter, sunroof module, sunblind motor, electric parkbrake switch illumination, accessory relays (luggage compartment fuse box)
F85AInstrument cluster
F910ALeft-hand direction indicator and repeater
F105AGlove compartment door motor and lamps
F115ARadio muting (engine start), ignition feed
F1210AFront electronic module (FEM), passenger mirror
F1320ARear electronic module (REM), door locks
F1410ACourtesy light, footwell lamps, rain sensor, FEM, autolamp module
F155AECM, FEM, instrument cluster airbag fault lamp, instrument cluster ignition (run/start)
F165ADiagnostic connector
F175AABS module
F18Not used
F195AIgnition relay, ECM, REM, fuel pump relay, start relay
F205ATelephone transceiver, TV module, VICS (Japan), voice module, rear telematics
F21Not used
F22Not used
F23Not used
F245APATS transponder
F2510ARight-hand direction indicator and repeater, right-hand front lamp, left-hand and right-hand sunvisor lamps, left-hand and right-hand sidemarkers
F2615AScreenwash pump
F2710AACC module
F2810AClimate control modules (front and rear), driver's door module (DDM)
F2910AAirbag module, occupancy sensing module, passenger weight sensor
F30Not used
F3115ASunroof, phone transceiver
F325AFront/rear parking aid, trailer tow module, battery-backed sounder, voice module, telephone receiver
F335ATransmission control, J-gate, generator
F345ANavigation system
F3510ALeft-hand seat movement
F3640ALeft-hand seat movement
F3725ADriver window
F3815ARadio head unit
F395ATransit relay (removed before customer delivery)
F4010ASecurity LED, yaw rate sensor
F4120AIgnition switch
F4210AFEM, REM, DDM, clock
F435ADiagnostic connector
F445ABrake switch
F4510ARight-hand seat movement
F4625APassenger window
F475AInstrument pack
F4820AInstrument pack (steering column tilt and reach)
F4940ALeft-hand seat movement

Passenger Compartment Fuse Box

LUGGAGE COMPARTMENT

The luggage compartment fuse box is located in the trunk, situated behind the battery. Open the trunk floor panel to gain access to the fuse box. Remove the fuse box lid by pulling the retaining clips and pulling the lid upwards. (Scheme 5)

Scheme 5

Scheme 5: LUGGAGE COMPARTMENT
Scheme 5: LUGGAGE COMPARTMENT

Scheme 6

Scheme 6
Scheme 6
Fuse No.AmpsFuse Function
F1Not used
F2Not used
F3Not used
F4Not used
F540ARight-hand front seat
F610AAccessory connector
F740AFront blower motor
F810AHeater circuit water pump
F925ARear seat motors
F10Not used
F115ARear footwell lamps, grab handle lamps, overhead console map lamps
F1210AAir suspension
F1320AREM, rear seat heaters
F14Not used
F155ARight-hand stop and tail lamps
F1610ALuggage compartment lights, driver seat switch pack, rear switch seat pack, blower motor relay coil
F1710ALeft-hand rear fog, direction indicator and reversing lamps
F1810ANumber plate lamps, side marker lamps
F1930AHeated rear window
F2010AHeated door mirrors
F2125ARear seat motors
F2210AAccessory connector
F23Not used
F2425AFuel pump driver module
F2515AFront accessory socket
F2615ARear accessory socket
F2710ARear CD
F2825ALeft-hand rear window
F2910AVICS
F3010AGenerator, battery-backed sounder, transit relay
F3140ARight-hand front seat
F3230AElectric parkbrake actuator
F3320ARear electronic module (fuel pump)
F3430APower amplifier
F35Not used
F36Not used
F3710ATPMS Battery +
F38Not used
F39Not used
F4025ARight-hand rear window
F41Not used
F42Not used
F4315ARear cigar lighter
F4415AFront cigar lighter
F45Not used
F4610ARight-hand rear reverse, direction indicator and fog lights
F4720AFEM, front seat heater
F485AHigh mounted stop lamps
F495ALeft-hand stop and tail lamps
F50Not used
F5110ANavigation system
F5220ALuggage compartment lamps
F5320ARear fan motor
F5415AHeated steering wheel
F555ATPMS

Luggage Compartment Fuse Box
