Multifunction Electronic Modules (2003.5-2009): Removal & Installation Jaguar XJR III

Communication Devices 21 illustrations ~491 words

Installation

  1. To install, reverse the removal procedure.
  2. After installation of the module, download module configuration information to the new module. << MODULE CONFIGURATION >>

Removal

CAUTIONElectronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result.

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Remove the front seat. << SEATINGS >>
  2. Disconnect the electrical connectors.
  3. Remove the driver seat module (DSM). Release the retaining tang
  1. To install, reverse the removal procedure.

Scheme 6

Scheme 6: Removal
Scheme 6: Removal

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Prior to removal of the module, upload module configuration information to the Jaguar approved diagnostic system. This information needs to be downloaded into the new module once installed. << MODULE CONFIGURATION >>
  2. Disconnect the battery ground cable. << >>
  3. Remove the left-hand cowl side trim panel. << INTERIOR TRIM AND ORNAMENTATION >>
  4. Reposition the floor covering.
  5. Disconnect the electrical connectors.
  6. Remove the front electronic module (FEM).

Scheme 9

Scheme 9: Installation
Scheme 9: Installation
  1. To install, reverse the removal procedure. Tighten to 6 N.m.
  2. After installation of the module, download module configuration information to the new module. << MODULE CONFIGURATION >>

Scheme 10

Scheme 10: Removal
Scheme 10: Removal

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Prior to removal of the module, upload module configuration information to the Jaguar approved diagnostic system. This information needs to be downloaded into the new module once installed. << MODULE CONFIGURATION >>
  2. Disconnect the battery ground cable. << >>
  3. Remove the left-hand luggage compartment side trim panel. Remove the luggage compartment side trim retaining clip. Remove the luggage compartment side trim panel.
  4. Detach the module mounting bracket.
  5. Disconnect the CD changer electrical connectors.
  6. Disconnect the multifunction voice activated module electrical connectors.
  7. Remove the CD changer. Remove the CD changer retaining bolts.

Scheme 15

Scheme 15: Installation
Scheme 15: Installation

Scheme 16

Scheme 16
Scheme 16
  1. To install, reverse the removal procedure. Tighten to 8 N.m.
  2. After installation of the module, download module configuration information to the new module. << MODULE CONFIGURATION >>
  3. Tighten to 6 N.m.
  4. Tighten to 10 N.m.

Scheme 17

Scheme 17: Removal
Scheme 17: Removal

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Prior to removal of the module, upload module configuration information to the Jaguar approved diagnostic system. This information needs to be downloaded into the new module once installed. << MODULE CONFIGURATION >>
  2. Disconnect the battery ground cable. << >>
  3. Remove the right-hand luggage compartment side trim panel. Remove the luggage compartment side trim retaining clip. Remove the luggage compartment side trim panel.
  4. Disconnect the REM electrical connectors.
  5. Remove the REM.

Scheme 20

Scheme 20: Installation
Scheme 20: Installation
  1. To install, reverse the removal procedure. Tighten to 6 N.m.
  2. After installation of the module, download module configuration information to the new module. << MODULE CONFIGURATION >>

Scheme 21

Scheme 21: Removal
Scheme 21: Removal

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Prior to removal of the module, upload module configuration information to the Jaguar approved diagnostic system. This information needs to be downloaded into the new module once installed.
  2. Disconnect the battery ground cable. << >>
  3. Remove the rear seat. << SEATINGS >>
  4. Reposition the rear seat backrest insulator. Remove the retaining clips.
  5. Disconnect the RSM electrical connectors.
  6. Remove the RSM. Remove the securing nuts.

Scheme 24

Scheme 24: Installation
Scheme 24: Installation
  1. To install, reverse the removal procedure. Tighten to 6 N.m.
