COMPONENT LOCATION
Component Location - Adjustment
Scheme 170
| Item Number | Description |
|---|---|
| 1 | Memory switch pack |
| 2 | Head restraint motor |
| 3 | Pump, lumbar support, squab bolster supports and back massage cells |
| 4 | Pump, lumbar support and squab bolster supports |
| 5 | Pump and lumbar support (4-way support shown, 2-way similar) |
| 6 | Seat slide motor |
| 7 | Squab recline motor |
| 8 | Cushion tilt motor |
| 9 | Cushion extension motor |
| 10 | Seat control module |
| 11 | Seat height motor |
| 12 | Seat switch pack (16 and 18 way) |
| 13 | Seat switch pack (8, 10 and 12 way) |
Component Location - Heated Seats
Scheme 171
| Item Number | Description |
|---|---|
| 1 | Rear seat cushion heater element |
| 2 | Rear seat squab heater element |
| 3 | Rear right-hand (RH) seat heater module |
| 4 | Rear left-hand (LH) seat heater module |
| 5 | Front passenger seat heater module |
| 6 | Driver seat heater module |
| 7 | Front seat cushion heater element |
| 8 | Front seat squab heater element |
Component Location - Climate Seats
Scheme 172
| Item Number | Description |
|---|---|
| 1 | Rear seats climate control module |
| 2 | Rear seat squab climate module |
| 3 | Rear seat squab pad assembly |
| 4 | Rear seat cushion pad assembly |
| 5 | Rear seat cushion climate module |
| 6 | Front seats climate control module |
| 7 | Front seat cushion climate module |
| 8 | Front seat cushion pad assembly |
| 9 | Front seat squab pad assembly |
| 10 | Front seat squab climate module |
